Irritrol RD900-INT-R, Rain Dial R Series 9 Station Indoor Controller

Irritrol RD900-INT-R Rain Dial R Series 9 Station Indoor Controller

Irritrol RD900-INT-R Rain Dial R Series, 9-Station Indoor Controller The RD900-INT-R is a 9-station Rain Dial R Series controller in an indoor cabinet. On the Rain Dial-R line the INT-R indoor unit uses an external plug-in transformer, so it mounts in a garage or utility room off a standard outlet. Programming and electrical Spec Value Stations 9 Programs 3 independent programs Start times 3 per program (9 starts total) Station run times 1 to 59 min (1-min steps) or 1 to 5.9 hr (6-min steps) Power in / out 120 VAC 60 Hz in; 24 VAC 1.25 A out Output limits 0.5 A max per station; 1.0 A max to valves incl. master valve / pump start Warranty 5-year Indoor or outdoor Choose the INT-R indoor cabinet when the controller sits inside. Mounting on an exterior wall? Step up to the RD900-EXT-R outdoor , which puts the transformer inside a weather-resistant key-lock cabinet. Smaller site? The RD600-INT-R 6-station indoor is the same platform with fewer zones. Sensors and remotes A sensor bypass switch lets you wire a RainSensor and cut it out for testing. The line is Climate Logic (CL-100) and SMRT Logic ready, and takes the CRR / R-100-KIT remote.
