Unicel Cartridge, 35 SQFT 5CH-35 In stock$4299
Quick overview
- 35 square feet of media The rated filter area of the 5CH-35 cartridge.
- Threaded 1-1/2 inch MPT end Screws into the housing rather than sitting on a standpipe, which is typical of small spa and portable systems.
- Compact 8 inch body Measures 5-5/8 inch outside diameter by 8 inch long.
- Listed for J.E.M. and Maax Unicel lists the filter manufacturers as J.E.M./Majestic Ind. and Maax Spas.
- Unicel build quality Unicel is the reference cartridge line most service techs cross-reference against.
- Measure before you order Cartridges are matched by diameter, length and end fitting, so check all three against the old element.
Similar products
Other products people compare with this one.
Product details
The Unicel 5CH-35 is a 35 square foot replacement filter cartridge measuring 5-5/8 inch in outside diameter by 8 inch long, with a 1-1/2 inch MPT threaded fitting on the end.
Matching the cartridge
Three numbers decide whether a cartridge fits: outside diameter, overall length, and the end configuration. This one threads in on a 1-1/2 inch male pipe thread rather than dropping over a standpipe, which is the arrangement used on many compact spa and small system filters. Unicel lists it against filters from J.E.M./Majestic Ind. and Maax Spas.
Getting the life out of it
Rinse the pleats out at every cleaning, and soak the element periodically to lift the oils and scale that a hose cannot reach. When a soaked and rinsed cartridge still runs the pressure up quickly, the media is loaded past recovery and the element is due for replacement.
| Brand | Unicel |
|---|---|
| Manufacturer part number | 5CH-35 |
| UPC | 678285250016 |
| Type | Filter cartridge |
| Square Footage | 35 |
| Outside Diameter | 5-5/8" |
| Length | 8" |
| Fitting | 1-1/2" MPT |
| Filter Manufacturer | J.E.M./Majestic Ind., Maax Spas |
| Shipping weight | 2 lb |
| Ships | Parcel |
