S.R. Smith Pool Lift Footrest with Hardware for Splash!, aXs2 and PAL, Gray, 160-2300A In stock$10861
S.R. Smith Pool Lift Footrest with Hardware for Splash!, aXs2 and PAL, Gray, 160-2300A
30 day returns · Easy, with prepaid labels provided
Quick overview
- Fit Named in the Splash! parts lists, the aXs2 list as Footrest Kit (Gray), and the CEC compliant PAL lists.
- Floats up The footrest is removable and floats upward to prevent damage if the seat is lowered too far.
- Mounting Fastens to the bottom of the seat with screws and thumbnuts.
- Color Gray, with the mounting hardware included.
- Not for PAL2 The PAL2 parts lists show a different footrest, 160-2700A.
Need a hand?
Similar products
Other products people compare with this one.
S.R. Smith 24 V Rotation Motor for PAL2, Splash! and PAL Pool Lifts, 120-1100$45267
S.R. Smith LiftOperator 24 V CEC Compliant Battery, BC Version for Pool Lifts, 1001495-BC-R$45299
S.R. Smith 4-Button LiftOperator Hand Control, 100-4300-R$23699
S.R. Smith LiftOperator Intelligent 4 Button Control Box, BC Version, 400-7000-BC$52412
Product details
The S.R. Smith 160-2300A is the gray footrest, with its mounting hardware, for the seat on Splash!, aXs2 and PAL pool lifts.
Where it fits
The part number appears in the parts lists for the Splash!, Splash! 300, Splash! Hi/Lo and Spa, Splash! Extended Reach and Extended Reach Hi/Lo. The aXs2 list names it as the Footrest Kit (Gray), and the CEC compliant PAL and PAL Hi/Lo and Spa lists include it too. The PAL2 is different: its lists call for footrest 160-2700A.
How it works
S.R. Smith makes the footrest removable, and it floats upward to prevent damage if the seat is lowered too far. In the aXs2 assembly steps it attaches with two screws and two thumbnuts through the holes on the bottom of the seat. If a footrest has cracked or gone missing, this replaces it without changing the seat.
From Pool School
Pool Lift Battery, Maintenance and Winter StorageCharging, swapping and storing the battery, what fails first, and winter storage. Read Which Pool Lift Fits Your PoolEnter the setback, draft and wall height. See which lifts reach your water. ReadWhere this part goes
16
Key 16 on the S.R. Smith Splash! Pool LiftFits every model in the drawing.See it on the diagramAll S.R. Smith Splash! Pool Lift Parts 24 parts and the drawing
27
Key 27 on the S.R. Smith aXs2 Pool LiftFits every model in the drawing.See it on the diagramAll S.R. Smith aXs2 Pool Lift Parts 23 parts and the drawing
| Brand | S.R. Smith |
|---|---|
| Model | Foot Rest |
| Manufacturer part number | 160-2300A |
| Fits | Splash!, aXs2, PAL |
| Type | Seat footrest with hardware |
| Color | Gray |
| Material | Roto-molded plastic |
| Mounting | Screws and thumbnuts through the bottom of the seat |
| Not for | PAL2, which uses footrest 160-2700A |
| Shipping weight | 3.95 lb |
