S.R. Smith 1001530-BC LiftOperator CEC compliant BC version battery chargerS.R. Smith LiftOperator CEC Battery Charger, BC Version for PAL Pool Lifts, 1001530-BC$47569
S.R. Smith 1001530-BC LiftOperator CEC compliant BC version battery charger
Shop all S.R. Smith

S.R. Smith LiftOperator CEC Battery Charger, BC Version for PAL Pool Lifts, 1001530-BC

Ask a questionMPN 1001530-BC
$47569
FREE Delivery
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • BC version The CEC compliant charger, not the standard 1001530.
  • Fit Named in the parts lists for the CEC compliant PAL and PAL Hi/Lo and Spa.
  • Setup Select the lead acid battery type and 24 V before connecting it to the battery.
  • Status light Amber while charging, flashing green at 80 percent, steady green when full.
  • Battery Pairs with the BC battery 1001495-BC in the same parts lists.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About S.R. Smith LiftOperator CEC Battery Charger, BC Version for PAL Pool Lifts, 1001530-BC, SKU PSU-200425. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item S.R. Smith LiftOperator CEC Battery Charger, BC Version for PAL Pool Lifts, 1001530-BC
S.R. Smith

LiftOperator CEC Battery Charger, BC Version for PAL Pool Lifts, 1001530-BC

$47569
S.R. Smith Linak Battery Charger for aXs, PAL and Splash Lifts, 100-3500
S.R. Smith

Linak Battery Charger for aXs, PAL and Splash Lifts, 100-3500

$17999
S.R. Smith New Style Battery Charger for Multilift, PAL, Splash and aXs Pool Lifts, 1001530
S.R. Smith

New Style Battery Charger for Multilift, PAL, Splash and aXs Pool Lifts, 1001530

$17099
S.R. Smith Lift-Operator New Style Battery for multiLift, PAL, Splash! and aXs Pool Lifts, 1001495
S.R. Smith

Lift-Operator New Style Battery for multiLift, PAL, Splash! and aXs Pool Lifts, 1001495

$37299
S.R. Smith LiftOperator Intelligent 4-Button Control Box, 400-7000
S.R. Smith

LiftOperator Intelligent 4-Button Control Box, 400-7000

$58299
S.R. Smith Lift-Operator Old Style Battery for PAL, Splash! and aXs Pool Lifts, 100-2000
S.R. Smith

Lift-Operator Old Style Battery for PAL, Splash! and aXs Pool Lifts, 100-2000

$41899
S.R. Smith LiftLock2 Anchor Assembly, Cast 316L Stainless Steel, 300-6600L
S.R. Smith

LiftLock2 Anchor Assembly, Cast 316L Stainless Steel, 300-6600L

$43699
Subtotal

Similar products

Other products people compare with this one.

S.R. Smith LiftOperator 24 V CEC Compliant Battery, BC Version for Pool Lifts, 1001495-BC-R$45299 S.R. Smith 120-1100 24 V rotation motor for PAL2, Splash! and PAL pool lifts S.R. Smith 24 V Rotation Motor for PAL2, Splash! and PAL Pool Lifts, 120-1100$45267 S.R. Smith 500-5000A new construction anchor jig with four flush deck anchors S.R. Smith New Construction Anchor Jig with Anchors for ML300 Pool Lifts, 500-5000A$40468 S.R. Smith 400-7000-BC LiftOperator Intelligent 4 button control box, BC version S.R. Smith LiftOperator Intelligent 4 Button Control Box, BC Version, 400-7000-BC$52412 S.R. Smith LiftOperator Control Box Cover for S.R. Smith Pool Lifts, Tan, 910-1000T$9799 S.R. Smith 1001601 two button hand control for ML300 and multiLift pool lifts S.R. Smith 2 Button Hand Control for ML300 and multiLift Pool Lifts, 1001601$22406 S.R. Smith 160-2300A gray pool lift footrest with hardware S.R. Smith Pool Lift Footrest with Hardware for Splash!, aXs2 and PAL, Gray, 160-2300A$10861 S.R. Smith 100-4300-R LiftOperator four button hand control S.R. Smith 4-Button LiftOperator Hand Control, 100-4300-R$23699

Product details

The S.R. Smith 1001530-BC is the LiftOperator battery charger in the CEC compliant BC version. The parts lists for the CEC compliant PAL and PAL Hi/Lo and Spa name it, along with the matching BC battery 1001495-BC. It is also listed as 1001530-BC-R.

Why the BC version

Since January 2, 2018, S.R. Smith lifts bound for California use the CEC compliant BC versions of the LiftOperator battery, charger and control box, and those BC parts do not interchange with the standard LiftOperator parts. The standard charger, 1001530, is the one in the PAL2, Splash! and aXs2 parts lists. Check the lift serial number before you order a battery, charger or control box.

Using the charger

Before you connect it, make sure the lead acid battery type and 24 V are selected. A steady amber light means the battery is charging, a flashing green light means it is 80 percent charged, and a steady green light means it is full and ready. A full charge takes up to twelve hours. If the amber light keeps flashing, the battery voltage is too low or the charger is not connected properly; alternating green and amber means reversed polarity or a battery that may be defective.

Battery care

Charge daily, and do not let the battery run flat. Whenever the battery is off the lift or the lift is idle, keep it on this charger. The battery cannot be overcharged. Keep it within 41 to 104 F.

From Pool School

Pool Lift Battery, Maintenance and Winter StorageCharging, swapping and storing the battery, what fails first, and winter storage. Read Which Pool Lift Fits Your PoolEnter the setback, draft and wall height. See which lifts reach your water. Read
Specifications
Brand S.R. Smith
Model Battery Charger
Manufacturer part number 1001530-BC
Fits PAL
Type LiftOperator battery charger, CEC compliant BC version
Battery setting Lead acid, 24 V
Charge time Up to 12 hours
Matching battery 1001495-BC
Not interchangeable with Standard charger 1001530
Also listed as 1001530-BC-R
Shipping weight 1 lb

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From S.R. Smith

A white diving board at the edge of a backyard pool. Pool better. S.R. Smith

S.R. Smith lighting

S.R. Smith Treo 5W LED Color Changing RGB Light, 80' Cord, FLED-C-TR S.R. Smith 60W 6 Amp Single Zone LED Light Control Power Tower, PT-6001 S.R. Smith RGB Treo LED Pool Light 12V, 30' Cord, FLED-C-TR-30 S.R. Smith WIRTRAN Control System with 3 Treo Color LED | 3TR-WIRTRAN
Shop S.R. Smith equipment

S.R. Smith parts

S.R. Smith Cantilever Steel Jump Stand with Jig, Radiant White, 69-209-001 S.R. Smith 6' White Spring Assembly for 606 Cantilever Jump Stand, 69-209-026 S.R. Smith 5W Replacement RGB LED Lamp, 12VAC, FLED-LAU-C S.R. Smith 18" Commercial Mounting Kit, 67-209-903-SS
Shop S.R. Smith parts
Pool slides: a curved slide set into a rock waterfall beside a backyard poolDiving boards: a white diving board over a backyard pool
S.R. Smith makes pool slides, diving boards, ladders, rails, in-pool furniture and pool lighting.Shop all S.R. Smith

Customer reviews

Questions and answers

What people ask about this product, answered by our pool techs.

What is the difference between the 1001530-BC and the 1001530 charger?
Since January 2, 2018, S.R. Smith lifts bound for California use the CEC compliant BC versions of the LiftOperator battery, charger and control box, and those BC parts do not interchange with the standard LiftOperator parts. The 1001530 is the standard charger in the PAL2, Splash! and aXs2 parts lists.
Which lifts list the 1001530-BC?
The CEC compliant PAL and PAL Hi/Lo and Spa parts lists. Check the lift serial number before you order a battery, charger or control box.
What do the charger lights mean?
Flashing amber means the charger has power; if it keeps flashing, the battery voltage is too low or the battery is not connected. Steady amber is charging, flashing green is 80 percent, and steady green is full. Alternating green and amber means reversed polarity or a timed out charge on a battery that may be defective.
Can I leave the battery on this charger?
Yes. S.R. Smith says the battery can and should be left on the charger when not in use, and that it cannot be overcharged.
