Air Supply of the Future Cyclone Pro 4128100 3HP pool line blower and liner vacAir Supply of the Future Cyclone Pro 3HP Pool Line Blower and Liner Vac, 120V 2-Stage for Winterizing Pools, 4128100 In stock$37196
Air Supply of the Future Cyclone Pro 4128100 3HP pool line blower and liner vac
Shop all Air Supply of the Future

Air Supply of the Future Cyclone Pro 3HP Pool Line Blower and Liner Vac, 120V 2-Stage for Winterizing Pools, 4128100

Ask a questionMPN 4128100
$37196 $399.99 7% OFF
FREE Delivery
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Two stage 3HP motor An 8.4 in. diameter bypass motor rated 14.0 amps at 120V delivers 140 CFM on open flow and 180 in. of water column sealed.
  • Winterizes deep pools Enough pressure to blow out the lines on a pool 9 ft deep, and enough flow to pull a vinyl liner back on a cold spring day.
  • 2 in. NPT inlet A stainless steel screen over the inlet keeps larger debris out of the motor.
  • 1.5 in. threaded outlet Connects to common PVC fittings, and a 1.5 in. threaded hose adapter ships in the box.
  • Service grade switch and cord A 20 amp rocker switch and a 6 ft grounded power cord, made for outdoor use.
  • Built to be carried Polycarbonate housing with a built in handle and rubber feet that hold it steady while it runs.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Air Supply of the Future Cyclone Pro 3HP Pool Line Blower and Liner Vac, 120V 2-Stage for Winterizing Pools, 4128100, SKU AIR-85-8418. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Air Supply of the Future Cyclone Pro 3HP Pool Line Blower and Liner Vac, 120V 2-Stage for Winterizing Pools, 4128100
Air Supply of the Future

Cyclone Pro 3HP Pool Line Blower and Liner Vac, 120V 2-Stage for Winterizing Pools, 4128100

$37196
Cover Butler Spa Cover Lifter, Black, CB-BLACK
Cover Butler

Spa Cover Lifter, Black, CB-BLACK

$16599
Laing Thermotech E5 Spa Circulation Pump with 4' Cord, 120/240V, 3/4" Barb, 10-0102-K
Hydro-Quip

Laing Thermotech E5 Spa Circulation Pump with 4' Cord, 120/240V, 3/4" Barb, 10-0102-K

$20199
Air Supply of the Future 2" Clear Check Valve for Blowers, 1112500
Air Supply of the Future

2" Clear Check Valve for Blowers, 1112500

$2899
Air Supply of the Future Silencer Air Blower, 2HP, 240V, 5.0 Amps, 6320241
Air Supply of the Future

Silencer Air Blower, 2HP, 240V, 5.0 Amps, 6320241

$23799
Balboa Slimline Escutcheon and Eyeball White 10-3955, 10-3955WHT
Hydro Air/itt Industries

Balboa Slimline Escutcheon and Eyeball White 10-3955, 10-3955WHT

$1499
Waterway Thread-in 5-Scallop Twin Roto Poly Storm Gunite Jet Internal, Gray, 229-8127
Waterway

Thread-in 5-Scallop Twin Roto Poly Storm Gunite Jet Internal, Gray, 229-8127

$2099
Subtotal

Similar products

Other products people compare with this one.

Air Supply of the Future Silencer air blower, 1HP 240V Air Supply of the Future Silencer Air Blower, 1HP, 240V, 2.5 Amps, 6310241$18699 SuperPro SUPER120020 quiet pool and spa air blower, 2 HP, 120V SuperPro Quiet Pool and Spa Air Blower, 2 HP, 120V, SUPER120020$33099 SuperPro SUPER240310 quiet pool and spa air blower, 1 HP 240V SuperPro Quiet Pool Spa Air Blower, 1 HP, 240V, SUPER240310$28799 Air Supply of the Future Astro Blower 1.5HP, 240V | 6715201 Air Supply of the Future Astro Blower 1.5HP, 240V | 6715201$22899 Air Supply of the Future Ultra 9000 Blower 1HP, 240V - 3910220F 3910231 | 3910220 Air Supply of the Future Ultra 9000 Blower 1HP, 240V - 3910220F 3910231 | 3910220$12499 Fuji Electric VFC400P-5T 1 hp regenerative commercial blower Fuji Electric 1 HP TEFC Commercial Blower, VFC400P-5T$1,09299 Cover Valet CVROCK-IT Cover Rock-It bar style spa cover lifter Cover Valet Cover Rock-It Bar Style Spa Cover Lifter, CVROCK-IT$19199 Life Essentials LST600 deluxe adjustable spa tray table Life Essentials Deluxe Adjustable Spa Tray Table, LST600$6799 Aqua-Flo 02607000-1010 Flo-Master FMCP center discharge 48-frame two speed pump Aqua-Flo Flo-Master FMCP, Center Discharge, 48-Frame 115V 1.0 HP .75 OPHP 2-Speed, 02607000-1010$40799 SuperPro SUPER120010 1 HP 120V quiet pool and spa air blower SuperPro 1 HP, 120V, Quiet Pool Spa Air Blower, SUPER120010$28299
CMP Spa Master 25580-090-000 white 2-1/2 inch gunite jet body with niche CMP Spa Master 2-1/2" White Gunite Jet Body with Niche, 25580-090-000$2699 SuperPro 25098-000-000 1 in. S white air control assembly for gunite and fiberglass spas SuperPro 1" S White Air Control Assembly for Gunite/Fiberglass Spa, 25098-000-000$2299 Waterway 210-6087 Polyjet standard adjustable deluxe internal, gray Waterway Polyjet Internal Standard Adjustable Deluxe, Gray, 210-6087$3599 Cover Valet CV250 spa cover lift Cover Valet Hydraulic Spa Cover Lift, CV250$24399 Waterway 229-8121 Poly Storm 5-scallop twin roto gunite jet internal, black Waterway Thread-in 5-Scallop Twin Roto Poly Storm Gunite Jet Internal, Black, 229-8121$1799 Hayward SPB151 spa air blower, 1.5HP 115V Hayward SPB151 Spa Air Blower 1.5HP 115V$28399 CMP 23315-030-200 Spa Master 1.5 inch jet internal pulsator in white and stainless steel CMP Spa Master 1.5" Gunite Jet Internal Pulsator, Stainless Steel/White, 23315-030-200$5299 Hayward SP1434PAKA Jet Air III body with 1-1/2 inch by 1-1/2 inch connections Hayward Jet Air III Body 1-1/2" x 1-1/2", SP1434PAKA$3099 CMP 25594-150-000 spa jet body assembly with 1-1/2 inch water and 1 inch air sockets CMP Spa Jet 1-1/2" Water by 1" Air, 25594-150-000$1699 Waterway 229-8120 5-scallop twin roto thread in Poly Storm gunite jet internals in white Waterway 5-Scallop Twin Roto Thread In Poly Storm Gunite Jet Internals, White, 229-8120$1799

Product details

The Cyclone Pro from Air Supply of the Future is a 3HP, two stage pool line blower built for two jobs: pushing the water out of plumbing, pumps and filters before a freeze, and pulling a vinyl liner tight against the walls during installation. On open flow it moves 140 CFM. Sealed against a closed line it builds 180 in. of water column, which is enough to clear a pool 9 ft deep.

Connections

The intake is 2 in. NPT, protected by a stainless steel screen so leaves and grit stay out of the 8.4 in. motor. The discharge is a 1.5 in. threaded fitting that mates with ordinary PVC adapters, and a 1.5 in. threaded hose adapter is packed in the box so most setups connect without a trip to the hardware store.

Built for service work

The housing is polycarbonate, redesigned to take daily use on a service route. A built in handle and rubber feet keep it planted on the deck, and the 20 amp rocker switch and 6 ft grounded cord are sized for the 14.0 amp, 120V motor. Homeowners closing one pool a year and technicians closing dozens get the same tool.

Before you order

Plan on a standard 120V outlet and 1.5 in. plumbing at the point where you tie in. Winter plugs, blow through plugs and a duck plug check valve for the return lines round out a closing kit.

Specifications
Brand Air Supply of the Future
Manufacturer part number 4128100
UPC 616312764136
Motor Two stage bypass, 3 HP, 8.4 in. diameter
Voltage 120V
Amperage 14.0 A
Airflow 140 CFM open flow
Sealed pressure 180 in. water column
Inlet 2 in. NPT with stainless steel screen
Outlet 1.5 in. threaded
Switch 20 amp rocker
Power cord 6 ft grounded
Housing Polycarbonate with built in handle and rubber feet
Included 1.5 in. threaded hose adapter
Shipping weight 16.75 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Air Supply of the Future

Air Supply of the Future Silencer air blower, 2HP 240V, part 6320241 Air Supply of the Future Silencer Air Blower, 2HP, 240V, 5.0 Amps, 6320241$23799 Air Supply of the Future 1112500 clear PVC union check valve for blowers Air Supply of the Future 2" Clear Check Valve for Blowers, 1112500$2899 Air Supply of the Future Silencer air blower, 2.0 HP 120V, part 6320141 Air Supply of the Future Silencer Air Blower, 2.0HP, 120V, 11.0 Amps, 6320141$23099 Air Supply of the Future Silencer air blower, 1HP 240V Air Supply of the Future Silencer Air Blower, 1HP, 240V, 2.5 Amps, 6310241$18699 Air Supply of the Future Silencer air blower, 1.5HP 240V, part 6315241 Air Supply of the Future Silencer Air Blower, 1.5HP, 240V, 4.0 Amps, 6315241$17999 Air Supply of the Future Ultra 9000 spa blower, part 3910131, angled view Air Supply of the Future Ultra 9000 Blower, 1 HP 120V 6.0 Amps, 3910131$14299 Air Supply of the Future Silencer 1.5 HP 120V air blower Air Supply of the Future Silencer Air Blower, 1.5 HP, 120V, 8.0 Amps, 6315141$19299 Air Supply of the Future 2510231 spa air blower, 1 HP 240V Air Supply of the Future 1 HP 240V 2.4A Max Spa Air Blower 2510231$13899 Air Supply of the Future Astro Blower 1.5HP, 120V | 6715101 Air Supply of the Future Astro Blower 1.5HP, 120V | 6715101$18999 Air Supply of the Future Ultra 9000 Blower 1HP, 240V - 3910220F 3910231 | 3910220 Air Supply of the Future Ultra 9000 Blower 1HP, 240V - 3910220F 3910231 | 3910220$12499
Air Supply of the Future Astro Blower 1.5HP, 240V | 6715201 Air Supply of the Future Astro Blower 1.5HP, 240V | 6715201$22899 Air Supply of the Future Blower Motor | 1HP 240V 3.5 AMPS | 3010201 Air Supply of the Future Blower Motor | 1HP 240V 3.5 AMPS | 3010201$10699 Air Supply of the Future Pool Liner Inlet Tube 4in x 5ft Vac Hose | 440456 Air Supply of the Future Pool Liner Inlet Tube 4in x 5ft Vac Hose | 440456$7699

Questions and answers

What people ask about this product, answered by our pool techs.

How deep a pool can it winterize?
The 180 in. of sealed water column pressure is enough to clear the lines on a pool 9 ft deep.
What fittings does it connect to?
The inlet is 2 in. NPT behind a stainless steel screen. The outlet is 1.5 in. threaded, so it accepts standard PVC fittings, and a 1.5 in. threaded hose adapter is included.
Can I use it to set a vinyl liner?
Yes. The same blower doubles as a liner vac. The 140 CFM open flow pulls a liner back into the corners, even on a cold spring day when the vinyl is stiff.
What power does it need?
A standard 120V outlet. The motor draws 14.0 amps, the rocker switch is rated 20 amps and the grounded cord is 6 ft long.
