Baker Hydro 00B8083 V-band clamp assembly for HRV filtersBaker Hydro V-Band Clamp Assembly HRV, 00B8083 In stock$9699
Baker Hydro 00B8083 V-band clamp assembly for HRV filters
Shop all Baker Hydro

Baker Hydro V-Band Clamp Assembly HRV, 00B8083

Ask a questionMPN 00B8083
$9699
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Clamp and nut included Supplied as an assembly, so the tightening hardware comes with it.
  • Sized 8-1/4 inch inside 8-1/4 inch inner diameter and 9 inch outer diameter.
  • Baker Hydro filter applications Listed for HRV side mount sand filters, Baker Hydro II top mount sand filters, and HRC-300 and HRC-400 cartridge filters.
  • Holds the filter halves together A V-band clamp is what keeps a split filter body sealed under pressure.
  • Not a part to improvise A clamp under pressure is a safety item, so it gets replaced with the right assembly rather than substituted.
  • Replace a corroded band Rust, a stretched band or a seized nut are all reasons to fit a new assembly rather than retighten the old one.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Baker Hydro V-Band Clamp Assembly HRV, 00B8083, SKU BAK-051-1491. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Baker Hydro V-Band Clamp Assembly HRV, 00B8083
Baker Hydro

V-Band Clamp Assembly HRV, 00B8083

$9699
Baker Hydro Control Plate Gasket, 00B7000
Baker Hydro

Control Plate Gasket, 00B7000

$1099
Baker Hydro HRV Valve Adapter, 31B0077
Baker Hydro

HRV Valve Adapter, 31B0077

$4899
Baker Hydro BULKHEAD ASSY 30" & 36" HRV | 31B9031
Baker Hydro

BULKHEAD ASSY 30" & 36" HRV | 31B9031

$9099
Baker Hydro Bulkhead Seal Gasket for 30 in. and 36 in. HRV Filters, 31B9036
Baker Hydro

Bulkhead Seal Gasket for 30 in. and 36 in. HRV Filters, 31B9036

$1999
Baker Hydro Air Relief Screen for HRV Sand Filters, 15B0074
Baker Hydro

Air Relief Screen for HRV Sand Filters, 15B0074

$899
Hayward SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit
Hayward

SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit

$15899
Subtotal

Similar products

Other products people compare with this one.

Jandy R0357500 filter clamp ring knob bolt assembly Jandy Clamp Ring Knob Bolt Assembly, R0357500$9599 Hayward CX3030H SwimClear cartridge filter lower piping assembly Hayward SwimClear Lower Piping Assembly, CX3030H$14199 Sta-Rite 24850-0105 air relief valve and pressure gauge assembly for System 3 filters Sta-Rite Valve and Gauge Assembly for System 3 Filters, 24850-0105$11099 Jandy R0465600 bulkhead assembly with o-ring for CV, CL, DEV and DEL filters Jandy Bulkhead Assembly with O-Ring for CV, CL, DEL and DEV Filters, R0465600$8199 Pentair 59052900Z locking ring assembly for Clean & Clear, Predator and EasyClean filters Pentair Locking Ring Assembly 59052900Z$11499 Hayward CXFDA200 filter diffuser assembly for the SwimClear C200S Hayward SwimClear Filter Diffuser Assembly C200S, CXFDA200$4899 Pentair 53108900Z spring barrel nut assembly for pool filter tank clamps Pentair Spring Barrel Nut Assembly, 53108900Z$4899 Sta-Rite 25021-0100Z System:3 elbow and bulkhead assembly Sta-Rite System:3 Elbow and Bulkhead Assembly, 25021-0100Z$11199 Jandy R0555100 outlet tube and elbow assembly with o-rings Jandy Outlet Tube and Elbow Assembly with O-Rings, R0555100$6199 Purex 70233 holding wheel assembly for the CFM315 cartridge filter Purex Holding Wheel Assembly for CFM315 Filter, 70233$7199
Pentair 170030 air bleed tube assembly for the 240 sq ft Clean and Clear Plus cartridge filter Pentair Genuine OEM Air Bleed Tube Assembly, 240 sq ft, 170030$5099 Pentair 170028 air bleed tube assembly for Clean and Clear Plus 420 filter Pentair Genuine OEM Air Bleed Tube Assembly 420 SQFT, 170028$4899 Hayward DEX2421J2 filter clamp bolt and nut set Hayward Clamp Bolt and Nut, DEX2421J2$4899 Pentair 190039 genuine OEM baffle bulkhead assembly Pentair Genuine OEM Baffle Bulkhead Assembly, 190039$10399 Waterway 550-7500 filter locknut assembly for the Clearwater II cartridge filter Waterway Clearwater II Filter Locknut Assembly 550-7500$8699 Pentair 178583 air bleed tube assembly for Clean and Clear 520 and Quad DE 100 filters Pentair Genuine OEM Air Bleed Tube Assembly 520 SQFT, 178583$5099 Pentair Black Manual Air Relief Assembly | 273550 Pentair Black Manual Air Relief Assembly | 273550$9399 Pentair Air Bleed Tube Assembly 320 Sq Ft | 170029 Pentair Air Bleed Tube Assembly 320 Sq Ft | 170029$5199 Hayward Outlet Elbow Assembly with O-Ring | DEX4820EA Hayward Outlet Elbow Assembly with O-Ring | DEX4820EA$9799 Hayward Key and Gasket Assembly SP0704 | SPX0704CA Hayward Key and Gasket Assembly SP0704 | SPX0704CA$5799

Product details

The Baker Hydro 00B8083 is the V-band clamp assembly for HRV filters, supplied with both the clamp and the nut. It measures 8-1/4 inches inside and 9 inches outside.

What it holds together

A V-band clamp is what keeps a split filter body closed. The two halves of the tank meet on a seal, and the band draws them together evenly all the way around so the joint holds under system pressure. It is listed for Baker Hydro HRV side mount sand filters, Baker Hydro II top mount sand filters, and the HRC-300 and HRC-400 cartridge filters.

When to replace rather than retighten

Bands corrode, stretch and lose their shape, and nuts seize. Any of those is a reason to fit a new assembly. This is the part holding a pressure vessel shut, so it is not one to improvise around with generic hardware.

Specifications
Brand Baker Hydro
Manufacturer part number 00B8083
UPC 788379807702
Type V-band clamp assembly
Part type Pool filter part
Includes Clamp and nut
Inner diameter 8 1/4"
Outer diameter 9"
Also referenced as 70240
Fits Baker Hydro HRV side mount sand filters, Baker Hydro II top mount sand filters, HRC-300 and HRC-400 cartridge filters
Shipping weight 0.8 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Baker Hydro

Baker Hydro WC624070A replacement skimmer weir door with clips Baker Hydro Replacement Weir Door, WC624070A5.0 (1) $4999 Baker Hydro 51B1016 skimmer forming frame Baker Hydro Skimmer Forming Frame, 51B1016$3899 Baker Hydro 51B1019 pre-fab kit with faceplate, gasket, inserts and screws Baker Hydro Pre-Fab Kit with Inserts, 51B1019$9099 Baker Hydro 00B7000 control plate gasket, also listed as G-317 Baker Hydro Control Plate Gasket, 00B7000$1099 Baker Hydro 31B0077 HRV valve adapter, union connection Baker Hydro HRV Valve Adapter, 31B0077$4899 Baker Hydro BULKHEAD ASSY 30" & 36" HRV | 31B9031 Baker Hydro BULKHEAD ASSY 30" & 36" HRV | 31B9031$9099 Baker Hydro 31B9036 bulkhead seal gasket for 30 in. and 36 in. HRV sand filters Baker Hydro Bulkhead Seal Gasket for 30 in. and 36 in. HRV Filters, 31B9036$1999 Baker Hydro 15B0074 air relief screen for HRV series sand filters Baker Hydro Air Relief Screen for HRV Sand Filters, 15B0074$899

Questions and answers

What people ask about this product, answered by our pool techs.

What comes in the assembly?
The clamp and the nut.
What size is it?
8-1/4 inches inner diameter and 9 inches outer diameter.
Which filters is it listed for?
Baker Hydro HRV side mount sand filters, Baker Hydro II top mount sand filters, and the HRC-300 and HRC-400 cartridge filters.
Can I just retighten my old clamp?
Not if the band is corroded, stretched or the nut is seizing. This clamp holds a pressure vessel closed, so a band that is past its life gets replaced rather than cranked down harder.
