Gecko 92200300 volute O-ring for Aqua-Flo Flo-Master XP and XP2 pumpsGecko Volute O-Ring for Aqua-Flo Pumps, 92200300 In stock$1399
Gecko 92200300 volute O-ring for Aqua-Flo Flo-Master XP and XP2 pumps
Shop all Gecko

Gecko Volute O-Ring for Aqua-Flo Pumps, 92200300

Ask a questionMPN 92200300
$1399
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Correct size 6-1/2" inside diameter with a 3/32" cross section, the size the Aqua-Flo volute takes.
  • Seals the volute Sits between the volute and the pump housing so the wet end holds pressure.
  • Aqua-Flo wet ends Listed against the Aqua-Flo Flo-Master XP and XP2 series pump parts.
  • Cheap insurance An O-ring costs a fraction of the prime and water lost to a weeping wet end.
  • Replace on reassembly Standard practice is a new O-ring any time the pump comes apart, rather than reusing a compressed one.
  • Gecko supplied Sold under Gecko, the company behind the Aqua-Flo pump line.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Gecko Volute O-Ring for Aqua-Flo Pumps, 92200300, SKU AQF-101-0300. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Gecko Volute O-Ring for Aqua-Flo Pumps, 92200300
Gecko

Volute O-Ring for Aqua-Flo Pumps, 92200300

$1399
Gecko 91694251 Impeller for 2.5 HP XP2 Pumps
Gecko

91694251 Impeller for 2.5 HP XP2 Pumps

$3499
Gecko Impeller for 2 HP XP2 Pump, 91694200
Gecko

Impeller for 2 HP XP2 Pump, 91694200

$3499
Gecko O-Ring Volute 251 FMCP/TMCP | 92200270
Gecko

O-Ring Volute 251 FMCP/TMCP | 92200270

$1299
Gecko Geko O-Ring 230 | 92200210
Gecko

Geko O-Ring 230 | 92200210

$1099
Gecko Aqua-Flo 2" 2.5HP XP2E 48 Frame Wet End | 91041825-000
Gecko

Aqua-Flo 2" 2.5HP XP2E 48 Frame Wet End | 91041825-000

$9699
Gecko Aqua-Flo Flo-Master HP 1.5HP Wet End | 91040720-000
Gecko

Aqua-Flo Flo-Master HP 1.5HP Wet End | 91040720-000

$9099
Subtotal

Similar products

Other products people compare with this one.

Aqua-Flo 92830070 wear ring for Flo-Master XP2 pumps Aqua-Flo Wear Ring for Flo-Master XP2, 92830070$1599 Aladdin B-33 5 inch pump strainer basket Aladdin Replacement Pump Strainer Basket for Sta-Rite, Premier and Aqua-Flo Pumps, 5 in., B-33$1108 Aladdin O-329-9 bronze pump volute o-ring, 5 inch I.D. Aladdin Bronze Pump Volute O-Ring for Pentair Pumps, 5 in. I.D., 3/32 in. Thickness, O-329-9$799 Pentair LA415 rubber volute O-ring for the Letro booster pump Pentair Volute O-Ring for Letro Booster Pump, LA415$899 Hayward SPX1600T rubber housing gasket for Super Pump and Max-Flo pumps Hayward Housing Gasket for Super Pump and Max-Flo Pumps, SPX1600T$1374 Hayward SPX1500P strainer cover O-ring for Power-Flo pumps Hayward O-Ring, Strainer Cover for Power-Flo Pump, SPX1500P$1999 Pentair 39010000 impeller screw o-ring for American Products Ultra-Flow pumps Pentair Impeller Screw O-Ring for Ultra-Flow Pumps, 39010000$799 Pentair 350103 o-ring for OptiFlo pool pumps Pentair O-Ring for OptiFlo Pumps, 350103$1199 SuperPro O-76-9 o-ring for the Hayward Max-Flo pump strainer cover SuperPro O-Ring for Hayward® Max-Flo® Pump and Strainer Cover, SPX0125T, O-76-9$1099 Gecko Geko O-Ring Volute 158 FMHP | 92200090 Gecko Geko O-Ring Volute 158 FMHP | 92200090$1099
Sta-Rite 35505-1437 trap lid o-ring for ABG series pool and spa pumps Sta-Rite Trap Lid O-Ring for ABG Series Pool and Spa Pumps, 35505-1437$899 Hayward SPX5500H Power-Flo Matrix strainer housing o-ring Hayward Power-Flo Matrix Strainer Housing O-Ring, SPX5500H$1999 Polaris R0537000 drain plug with o-ring for the PB4-60 booster pump Polaris Drain Plug with O-Ring for PB4-60, R0537000$1599 Waterway 805-0436 pump lid o-ring for 6 inch trap cover Waterway O-Ring for 6" Trap Cover, 805-0436$799 Hayward SPX5500K Power-Flo Matrix strainer cover o-ring Hayward OEM Power-Flo Matrix Strainer O-Ring, SPX5500K$999 Hayward SPX1700FGV pipe plug with gasket for Hayward pumps Hayward Drain Plug with Gasket for Pool Pumps, SPX1700FGV$1099 Waterway 805-0256 pump volute faceplate o-ring Waterway Pump Volute Faceplate O-Ring, 805-0256$999 Sta-Rite C35-43 motor vibration pad for Max-E-Pro pumps Sta-Rite Motor Pad for Max-E-Pro Pumps, C35-43$1499 Pentair 356173Z seal plate o-ring for the 3HP IntelliFlo3 pool pump Pentair Seal Plate O-Ring for 3HP IntelliFlo3 Pool Pump, 356173Z$1399 Speck 2920341220 casing o-ring for Model 433 pool pump Speck O-Ring for Model 433 Pool Pump Casing, 2920341220$1420

Product details

This is the volute O-ring for Aqua-Flo pumps, Gecko part 92200300. It measures 6-1/2 inches inside diameter with a 3/32 inch cross section and is listed against the Flo-Master XP and XP2 series wet ends.

What it seals

The volute is the shaped housing the impeller spins inside. This O-ring is the seal between that volute and the rest of the wet end. When it hardens, flattens or tears, the pump pulls air past it instead of water, and the symptoms show up as a loss of prime, a rising air pocket in the pump lid, or a slow weep at the seam.

When to fit one

Any time the pump comes apart for an impeller, seal or wear ring job, a new volute O-ring goes back in. It is a small part next to the labor of pulling the pump twice.

From Pool School

How to Prime a Pool PumpFrom the breaker to a full pot, each manufacturer's time limit, and what to check when it won't catch prime. Read Replace the Pool Pump Motor or the Whole Pump?The manufacturers' tests first, what each repair replaces, and the federal motor rule. Read
Specifications
Brand Gecko
Manufacturer part number 92200300
Type Volute O-ring
Inside diameter 6-1/2"
Cross section 3/32"
Fits Aqua-Flo Flo-Master XP and XP2 series pumps
Shipping weight 1 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Gecko

Gecko 91694251 impeller for 2.5 HP XP2 pumps Gecko 91694251 Impeller for 2.5 HP XP2 Pumps$3499 Gecko 91694200 impeller for 2 HP XP2 pumps Gecko Impeller for 2 HP XP2 Pump, 91694200$3499 Gecko Aqua-Flo Flo-Master FMCP Center Discharge | 02615005-1010 Gecko Aqua-Flo Flo-Master FMCP Center Discharge | 02615005-1010$26799 Gecko Aqua-Flo Circ-Master CMCP | Center Discharge | 02593000-2010 Gecko Aqua-Flo Circ-Master CMCP | Center Discharge | 02593000-2010$26599 Gecko Wet End Assy Compl 2HP FMCP | 91040840-000 Gecko Wet End Assy Compl 2HP FMCP | 91040840-000$9099 Gecko Aqua-Flo 2" 2.5HP XP2E 48 Frame Wet End | 91041825-000 Gecko Aqua-Flo 2" 2.5HP XP2E 48 Frame Wet End | 91041825-000$9699 Gecko Aqua-Flo 2" 2HP XP2E 56FR Wet End | 91041920-000 Gecko Aqua-Flo 2" 2HP XP2E 56FR Wet End | 91041920-000$11399 Gecko Aqua-Flo Flo-Master HP 2HP Wet End 91040730 | 91040730-000 Gecko Aqua-Flo Flo-Master HP 2HP Wet End 91040730 | 91040730-000$9099 Gecko Aqua-Flo Flo-Master HP 1HP Wet End 91040700 | 91040700-000 Gecko Aqua-Flo Flo-Master HP 1HP Wet End 91040700 | 91040700-000$9099 Gecko Aqua-Flo Flo-Master HP 1.5HP Wet End | 91040720-000 Gecko Aqua-Flo Flo-Master HP 1.5HP Wet End | 91040720-000$9099
Gecko Aqua-Flo Flo-Master CP .75HP Wet End | 91040800-000 Gecko Aqua-Flo Flo-Master CP .75HP Wet End | 91040800-000$9899 Gecko Aqua-Flo Flo-Master CP 1HP Wet End 91040810 | 91040810-000 Gecko Aqua-Flo Flo-Master CP 1HP Wet End 91040810 | 91040810-000$9699 Gecko Geko O-Ring 230 | 92200210 Gecko Geko O-Ring 230 | 92200210$1099 Gecko Geko O-Ring Volute 158 FMHP | 92200090 Gecko Geko O-Ring Volute 158 FMHP | 92200090$1099 Gecko O-Ring Volute 251 FMCP/TMCP | 92200270 Gecko O-Ring Volute 251 FMCP/TMCP | 92200270$1299 Gecko Aqua-Flo 2" 3HP XP2E 48 Frame Wet End | 91041830-000 Gecko Aqua-Flo 2" 3HP XP2E 48 Frame Wet End | 91041830-000$11299 Gecko Aqua-Flo Flo-Master FMHP Offset Discharge | 02110000-1010 Gecko Aqua-Flo Flo-Master FMHP Offset Discharge | 02110000-1010$36699

Questions and answers

What people ask about this product, answered by our pool techs.

What size is this O-ring?
6-1/2 inches inside diameter with a 3/32 inch cross section.
Which pumps does it fit?
It is listed for Aqua-Flo Flo-Master XP and XP2 series pumps, where it seals the volute.
Should I replace it when I open the pump?
Yes. An O-ring takes a set once it has been compressed and heated for a season, and it rarely seals as well the second time. Fit a new one while the pump is apart.
Why is my pump losing prime?
A leaking volute or lid O-ring is one of the common causes, because the pump pulls air past the seal instead of water. A hairline weep at the seam when the pump runs is the giveaway.
