AquaStar 6" Sumpless Bulkhead Fitting with 1.5 " | 6E15T101AquaStar 6 in. Sumpless Bulkhead Fitting with 1-1/2 in. Extended MPT, White, 6E15T101 In stock$2499
AquaStar 6" Sumpless Bulkhead Fitting with 1.5 " | 6E15T101
Shop all AquaStar

AquaStar 6 in. Sumpless Bulkhead Fitting with 1-1/2 in. Extended MPT, White, 6E15T101

Ask a questionMPN 6E15T101
$2499
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Extended thread A 6 in. sumpless bulkhead with an extended 1-1/2 in. MPT thread.
  • Flush mount match Made for use with a flush mount 1-1/2 in. FPT fitting.
  • Not for 1022 adapters Does not fit 1022 female adapters.
  • Flow ratings 224 GPM at 6.3 fps on a 2 in. pipe, 177 GPM at 5.9 fps on a 1-1/2 in. floor pipe.
  • Parts listed A 6 in. round suction outlet cover, the bulkhead and four #8-32 x 1-1/4 in. flat head Phillips screws in 316 stainless steel.
  • VGB series Carries the trademarked VGB 2008 compliance button on an 11.4 square inch opening.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About AquaStar 6 in. Sumpless Bulkhead Fitting with 1-1/2 in. Extended MPT, White, 6E15T101, SKU API-251-1196. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item AquaStar 6 in. Sumpless Bulkhead Fitting with 1-1/2 in. Extended MPT, White, 6E15T101
AquaStar

6 in. Sumpless Bulkhead Fitting with 1-1/2 in. Extended MPT, White, 6E15T101

$2499
Hayward Cover O-Ring for SP0714T Vari-Flo XL Valve, SPX0714L
Hayward

Cover O-Ring for SP0714T Vari-Flo XL Valve, SPX0714L

$1899
Hayward Paralevel Startup Kit, 004-760-2921-00
Hayward

Paralevel Startup Kit, 004-760-2921-00

$5799
Hayward 1-1/2" Combo Hose Adapter for Filters, Pumps, Skimmers and Chlorine Feeders (2 Pack), SPX1091Z7
Hayward

1-1/2" Combo Hose Adapter for Filters, Pumps, Skimmers and Chlorine Feeders (2 Pack), SPX1091Z7

$899
Hayward Genuine OEM SP1082 Skimmer Basket, SPX1082CA
Hayward

Genuine OEM SP1082 Skimmer Basket, SPX1082CA

$2399
Paramount 6 Port Water Valve Module, 004-302-4408-00
Paramount

6 Port Water Valve Module, 004-302-4408-00

$35699
Hayward Auto-Skim Skimmer for Vinyl/Fiberglass Pools, 1.5" FPT, Square Lid, White, SP10841
Hayward

Auto-Skim Skimmer for Vinyl/Fiberglass Pools, 1.5" FPT, Square Lid, White, SP10841

$19299
Subtotal

Similar products

Other products people compare with this one.

Hayward WGX1048E 8 inch anti-vortex main drain cover in white Hayward 8" Anti-Vortex Main Drain Cover, White, WGX1048E$3299 AquaStar 6HPHA101 6 inch hockey puck suction outlet cover, white AquaStar 6" Suction Outlet Cover with Screws, VGB Series, White, 6HPHA101$3499 Hayward SPX1048DPAK2 main drain gasket set of 2 Hayward Main Drain Gasket, Set of 2, SPX1048DPAK2$2299 AquaStar R8MF101 8 inch white round retrofit MoFlow suction outlet cover AquaStar 8" White Round Retrofit MoFlow Suction Outlet Cover, R8MF101$3499 Hayward WGX1048B white main drain suction outlet frame Hayward 7-7/8" Main Drain Frame, White, WGX1048B$1999 CMP 25507-100-000 8 inch white Galaxy drain cover with screw pack CMP 8" Galaxy Drain Cover with Screw Pack, White, 25507-100-000$1799 AquaStar 8MF101 8 inch white round MoFlow suction outlet cover with mud frame AquaStar 8" White Round MoFlow Suction Outlet Cover and Mud Frame, 8MF101$3099 CMP 25531-001-000 8 inch Galaxy gunite pool main drain lid and frame in gray CMP 8" Galaxy Gunite Pool Main Drain Lid and Frame, Gray, 25531-001-000$2299 AquaStar 10AVR103 10 inch round light gray anti-entrapment suction outlet cover AquaStar 10" Light Gray Round Anti-Entrapment Suction Outlet Cover, 10AVR103$3599 AquaStar 10AVR105 10 inch round dark gray anti-entrapment suction outlet cover with riser ring and mud frame AquaStar 10 Inch Dark Gray Round Anti-Entrapment Suction Outlet Cover, 10AVR105$3499
AquaStar 8MF102 8 inch black round MoFlow suction outlet cover with mud frame AquaStar 8" Black Round MoFlow Suction Outlet Cover and Mud Frame, 8MF102$2799 Waterway 640-2750 V complete main drain for vinyl liner pools with cover and sump Waterway Main Drain for Vinyl Liner Pools, 640-2750 V$3699 AquaStar A8R104 8 inch Star anti-entrapment cover with riser ring and mud frame, blue AquaStar 8" Star Anti-Entrapment Cover with Solid Riser Ring and Mud Frame, VGB Series, Blue, A8R104$3199 SuperPro SG6402317 VC 8 inch round gray anti-vortex main drain frame and grate SuperPro 8" Round Gray Anti-Vortex Main Drain Frame and Grate, SG6402317 VC$1999 SuperPro SG640-2310VC 8 inch round white anti-vortex main drain frame and grate SuperPro 8" Round White Anti-Vortex Main Drain Frame and Grate, SG640-2310VC$2499 Hayward SPX1039Z18 main drain frame screws, eight per pack Hayward Main Drain Frame Screws, 8 Per Pack, SPX1039Z18$1699 Hayward WGX1048EGR eight inch gray anti-entrapment VGB main drain cover Hayward 8" Anti-Entrapment VGB Drain Cover, Gray, WGX1048EGR$3199 Waterway Plastics 645-2150 V white 8 inch anti-vortex main drain cover Waterway 8" Anti-Vortex Main Drain Cover, White, 645-2150 V$1699 CMP 25531-004-000 Galaxy 8 inch lid and frame in black CMP 8 Inch Galaxy Lid and Frame, Black, 25531-004-000$2599 AquaStar 6" Sumpless Bulkhead Fitting with 2" Slip Insider | 620SI101 AquaStar 6 in. Sumpless Bulkhead Fitting with 2 in. Slip Insider, White, 620SI101$2499

Product details

The AquaStar 6E15T101 is a white 6 inch sumpless bulkhead fitting with a 1-1/2 inch extended male thread, made for use with a flush mount 1-1/2 inch female thread.

What it does

A bulkhead fitting connects a suction outlet to the pool plumbing through the pool shell. This one is sumpless, so it needs no separate sump, and it has an 11.4 square inch opening. The extended 1-1/2 in. MPT thread gives extra reach for a flush mount 1-1/2 in. FPT fitting.

Fit and compatibility

The 6E15T101 does not fit 1022 female adapters. AquaStar designs it for gunite, steel, vinyl, fiberglass and tile pools and spas; see the installation instructions for your pool type. Flow ratings are 224 GPM at 6.3 fps on a 2 in. floor or wall pipe, 177 GPM at 5.9 fps on a 1-1/2 in. floor pipe and 122 GPM at 3.4 fps on a 1-1/2 in. wall pipe.

What is included

The parts listed are a 6 in. round suction outlet cover with the VGB 2008 compliance button, the sumpless bulkhead and four #8-32 x 1-1/4 in. flat head Phillips screws in 316 stainless steel. Eight adapter plates for other connection types are sold separately. AquaStar states that the fitting meets or exceeds ANSI/APSP 16-2011 and NSF 50-2008.

Specifications
Brand AquaStar
Manufacturer part number 6E15T101
Type Sumpless bulkhead fitting
Diameter 6 in.
Color White
Thread 1-1/2 in. extended MPT
For use with Flush mount 1-1/2 in. FPT
Does not fit 1022 female adapters
Opening 11.4 square inch, sumpless
Flow, 2 in. floor or wall pipe 224 GPM at 6.3 fps
Flow, 1-1/2 in. floor pipe 177 GPM at 5.9 fps
Flow, 1-1/2 in. wall pipe 122 GPM at 3.4 fps
Material UV-resistant engineered polymer
Includes 6 in. round suction outlet cover, bulkhead, four #8-32 x 1-1/4 in. flat head Phillips screws, 316 stainless steel
Shipping weight 0.24 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from AquaStar

AquaStar PLF35000 PipeLine cartridge filter AquaStar PipeLine Cartridge Filter for Pools up to 35,000 Gallons, PLF35000$1,00000 AquaStar DIV0101 2 in. x 1.5 in. white return diverter plate AquaStar 2 in. x 1.5 in. White Return Diverter Plate, DIV0101$1599 AquaStar PF35CART 250 sq ft replacement cartridge for the Pipeline PF35000 filter AquaStar Pipeline 250 sqft 31" Cartridge Filter Replacement, PF35CART$16199 AquaStar A10RCFR101 10 inch white universal round main drain cover with adapter kit AquaStar 10" Universal Round Main Drain Cover with Universal Adapter Kit, White, A10RCFR101$6399 AquaStar PF27CART 200 sq ft replacement cartridge for the PipeLine PF27000 filter AquaStar Pipeline 200 Sq Ft 24 in. Filter Cartridge Replacement, PF27CART$13799 AquaStar WAV9WR101 9 inch by 9 inch white Wave suction cover with frame and riser AquaStar 9" x 9" Wave Suction Cover with Frame and Riser, White, WAV9WR101$14499 AquaStar SKWD105 Flow Star skimmer weir plate assembly in dark gray AquaStar Flow Star Skimmer Weir, Dark Gray, SKWD105$2299 AquaStar 6HPHA101 6 inch hockey puck suction outlet cover, white AquaStar 6" Suction Outlet Cover with Screws, VGB Series, White, 6HPHA101$3499 AquaStar UNHT20 high temperature 2 inch threaded union AquaStar High Temperature 2" Threaded Union, UNHT20$2999 AquaStar SKZ214 ZarStar large skimmer basket AquaStar ZarStar Skimmer Basket, SKZ214$8299
AquaStar SKWD101 Flow Star skimmer weir plate assembly in white AquaStar Flow Star Skimmer Weir Plate, SKWD101$2399 AquaStar WAV18WRNF101 18 by 18 inch white Square Wave suction outlet cover set AquaStar 18" x 18" White Square Wave Suction Outlet Cover Set, WAV18WRNF101$30999 AquaStar 8MF101 8 inch white round MoFlow suction outlet cover with mud frame AquaStar 8" White Round MoFlow Suction Outlet Cover and Mud Frame, 8MF101$3099 AquaStar GV14 14 inch Gyro-Vac Flex multi directional pool vacuum head AquaStar 14" Gyro-Vac Flex Vacuum Head, GV14$18199 AquaStar R9MF101 9 inch square white MoFlow retrofit suction outlet cover AquaStar 9" Square White MoFlow Retrofit Suction Outlet Cover, R9MF101$7399 AquaStar 32CDFLNFK101 32 in. white channel drain flat grate suction outlet AquaStar 32 in. White Channel Drain Flat Grate Suction Outlet, Without Frame, 32CDFLNFK101$11399 AquaStar SK6 white skimmer basket with stainless steel handle AquaStar Skimmer Basket with Stainless Steel Handle, SK6$1899 AquaStar GV22 22 inch Gyro-Vac Flex vacuum head AquaStar 22" Gyro-Vac Flex Vacuum Head, GV22$28499 AquaStar 10AVR105 10 inch round dark gray anti-entrapment suction outlet cover with riser ring and mud frame AquaStar 10 Inch Dark Gray Round Anti-Entrapment Suction Outlet Cover, 10AVR105$3499 AquaStar R8MF101 8 inch white round retrofit MoFlow suction outlet cover AquaStar 8" White Round Retrofit MoFlow Suction Outlet Cover, R8MF101$3499

Questions and answers

What people ask about this product, answered by our pool techs.

What does the AquaStar 6E15T101 connect to?
It has an extended 1-1/2 in. male pipe thread and is made for use with a flush mount 1-1/2 in. FPT fitting. It does not fit 1022 female adapters.
Which pools can use the 6E15T101?
It is made for single or multiple drain use in gunite, steel, vinyl, fiberglass and tile pools and spas. Follow the installation instructions for your pool type.
What parts come with the 6E15T101?
The parts listed are a 6 in. round suction outlet cover, the VGB 2008 color code compliance button, the sumpless bulkhead with extended 1-1/2 in. thread and four #8-32 x 1-1/4 in. flat head Phillips screws.
What flow rates does the 6E15T101 allow?
AquaStar rates it at 224 GPM at 6.3 fps on a 2 in. pipe, 177 GPM at 5.9 fps on a 1-1/2 in. floor pipe and 122 GPM at 3.4 fps on a 1-1/2 in. wall pipe.
