Intermatic 143T135 DPST relay with 240 VAC coil, rated 3 HPIntermatic DPST Relay with 240 VAC Coil, 3 HP, for Pool and Spa Pump Control, 143T135 In stock$7499
Intermatic 143T135 DPST relay with 240 VAC coil, rated 3 HP
Shop all Intermatic

Intermatic DPST Relay with 240 VAC Coil, 3 HP, for Pool and Spa Pump Control, 143T135

Ask a questionMPN 143T135
$7499
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • DPST switching Two poles open and close together, so one relay switches two circuits at the same moment.
  • 240 VAC coil Pulls in on a 240 volt AC control signal; Intermatic sells 120 VAC, 24 VAC and 24 VDC coil versions as separate parts.
  • Rated 3 HP Intermatic gives the 143T135 a 3 HP rating for motor and pump control.
  • Pool and spa part Intermatic files it with its pool and spa motor control accessories, for residential and commercial equipment.
  • Genuine Intermatic Factory part 143T135, UPC 078275046498, with an ivory body of metal and plastic.
  • 1-year limited warranty Intermatic covers the relay with a 1-year limited warranty.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Intermatic DPST Relay with 240 VAC Coil, 3 HP, for Pool and Spa Pump Control, 143T135, SKU INT-301-1501. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Intermatic DPST Relay with 240 VAC Coil, 3 HP, for Pool and Spa Pump Control, 143T135
Intermatic

DPST Relay with 240 VAC Coil, 3 HP, for Pool and Spa Pump Control, 143T135

$7499
Intermatic 24-Hour 208-277V Mechanical Time Switch, DPST, Mechanism Only, T104M
Intermatic

24-Hour 208-277V Mechanical Time Switch, DPST, Mechanism Only, T104M

$9299
Intermatic Freeze Protection Thermostat, 178T24
Intermatic

Freeze Protection Thermostat, 178T24

$7099
Intermatic 24HR Panel Mount Timer 240V, PB914N66
Intermatic

24HR Panel Mount Timer 240V, PB914N66

$5999
Intermatic On/Off Trippers Set, 156T1978A
Intermatic

On/Off Trippers Set, 156T1978A

$1199
Intermatic Heavy Duty 15 Amp Outdoor Timer, P1121
Intermatic

Heavy Duty 15 Amp Outdoor Timer, P1121

$5499
Intermatic PX100 Safety Transformer, 100W, Steel Enclosure, Beige
Intermatic

PX100 Safety Transformer, 100W, Steel Enclosure, Beige

$12540
Subtotal

Similar products

Other products people compare with this one.

Intermatic AG3000 three mode surge protective device in an outdoor enclosure Intermatic AG3000 Surge Protective Device, 3-Mode, 120/240 VAC, Outdoor$9199 Intermatic PS3000 surge protector for pool and spa equipment Intermatic PS3000 Surge Protector for Pool and Spa Equipment, 120/240V$11599 Intermatic PX50 50 watt pool and spa safety transformer in a beige steel enclosure Intermatic 50 Watt Pool and Spa Safety Transformer, Input 120V, Output 12, 13, 14 Volt, Beige Steel Enclosure, PX50$13899 Intermatic PX600 600 watt pool and spa safety transformer in beige steel enclosure Intermatic 600 Watt Pool and Spa Safety Transformer, Beige Steel Enclosure, PX600$33299 Intermatic T40004RT3 load center with 300 W transformer and T104M time switch mechanism Intermatic 100 A Load Center with 300 W Transformer and T104M Mechanism, 8-Breaker Spaces, T40004RT3$36399 Intermatic T30004R 100 A pool and spa load center with T104M mechanism Intermatic 100 A Load Center with T104M Mechanism, 8-Breaker Spaces, T30004R$28572 Web Price Intermatic 21T156A 3 inch standoff spacer, four pack Intermatic 3" Standoff Spacer, 4 Pack, 21T156A$1899 Intermatic 300W | 120V to 12V Transformer | PX300 Intermatic 300W | 120V to 12V Transformer | PX300$15699 Intermatic 100W 120V to 12V Transformer Stainless Housing | PX100S Intermatic 100W 120V to 12V Transformer Stainless Housing | PX100S$17199 Intermatic T30000R5 100 amp load center subpanel with eight breaker spaces Intermatic 100 Amp Load Center Subpanel, 8-Breaker Spaces, T30000R5$11099
Intermatic 300W 120V to 12 13 or 14V Transformer | PX300S Intermatic 300W 120V to 12 13 or 14V Transformer | PX300S$23799 Intermatic DUAL BOX W/SINGLE T104M 208-277V TIMER | T10004R Intermatic DUAL BOX W/SINGLE T104M 208-277V TIMER | T10004R$26699

Product details

The Intermatic 143T135 is a double pole, single throw (DPST) relay with a 240 VAC coil and a 3 HP rating. Intermatic lists it as a pool and spa accessory for motor and pump control, for residential and commercial equipment.

What it does

A relay lets a small control signal switch a larger load. When 240 VAC reaches the coil of the 143T135, both poles close at the same moment, so a single relay can switch two circuits together. That is how a 240 volt load such as a pump motor is usually switched, with one pole on each hot leg. When the coil loses power, both poles open again.

Choosing the right relay

Coil voltage is the first thing to match. Intermatic builds this DPST, 3 HP relay in four coil versions: 143T135 at 240 VAC, 143T136 at 120 VAC, 143RC151 at 24 VAC and 143T145A at 24 VDC. A coil fed the wrong voltage will either fail to pull in or overheat, so read the label on the relay you are replacing before you order.

Before you install

Turn off power at the main panel before opening the control, and have the wiring done by a qualified person to national and local electrical codes. The relay has an ivory body of metal and plastic and carries the Intermatic 1-year limited warranty.

Specifications
Brand Intermatic
Manufacturer part number 143T135
UPC 078275046498
Type Relay, double pole single throw (DPST)
Coil voltage 240 VAC
Rating 3 HP
Applications Motor control, pump control
Market Residential and commercial pool and spa
Material Metal and plastic
Color Ivory
Other coil versions 143T136 (120 VAC), 143RC151 (24 VAC), 143T145A (24 VDC)
Warranty 1-year limited
Shipping weight 0.4 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Intermatic

Intermatic T104M 24-hour DPST mechanical time switch mechanism, 208-277V Intermatic 24-Hour 208-277V Mechanical Time Switch, DPST, Mechanism Only, T104M$9299 Intermatic 178T24 freeze protection thermostat with knob and wiring Intermatic Freeze Protection Thermostat, 178T24$7099 Intermatic PB914N66 24 hour panel mount timer, 240V Intermatic 24HR Panel Mount Timer 240V, PB914N66$5999 Intermatic 156T1978A on and off tripper set for T100 Series time clocks Intermatic On/Off Trippers Set, 156T1978A$1199 Intermatic T104P201 24 hour DPST mechanical time switch in plastic enclosure Intermatic 24-Hour DPST Mechanical Time Switch with Heater Protection, 208-277V, T104P201$17705 Intermatic PX100 100 watt pool and spa safety transformer in a beige steel enclosure Intermatic PX100 Safety Transformer, 100W, Steel Enclosure, Beige$12540 Intermatic P1121 heavy duty 15 amp outdoor plug-in timer Intermatic Heavy Duty 15 Amp Outdoor Timer, P1121$5499 Intermatic T30004R 100 A pool and spa load center with T104M mechanism Intermatic 100 A Load Center with T104M Mechanism, 8-Breaker Spaces, T30004R$28572 Web Price Intermatic PF1103MT freeze protection timer with thermostat, 120/240V mechanism Intermatic Freeze Protection Timer with Thermostat for 120/240V Applications, Mechanism, PF1103MT$26699 Intermatic PJB4175 four light pool and spa junction box Intermatic 4 Light Connection Pool & Spa Junction Box, PJB4175$6701 Web Price
Intermatic P1403ME electronic pump motor controller mechanism with seasonal adjustment Intermatic Electronic Pump Motor Controller with Seasonal Adjustment, 4-Circuit, Mechanism Only, P1403ME$26999 Intermatic T104P3 24-hour mechanical time switch in Type 3R plastic case Intermatic 24-Hour 208-277V Mechanical Time Switch, DPST, Type 3R Plastic Enclosure, T104P3$12299 Intermatic P1131 20 amp portable outdoor timer with twist-lock plug Intermatic 20A Timer with Twist-Lock Plug, P1131$11199 Intermatic RC2343PT four function air switch with 24 hour timer Intermatic 4 Function Air Switch with Timer, RC2343PT$33099 Intermatic T104R3 24 hour DPST mechanical time switch in Type 3R metal enclosure Intermatic 24-Hour 208-277V Mechanical Time Switch, DPST, Type 3R Metal Enclosure, T104R3$12799 Intermatic AG3000 three mode surge protective device in an outdoor enclosure Intermatic AG3000 Surge Protective Device, 3-Mode, 120/240 VAC, Outdoor$9199 Intermatic WG1573-10D 208/277 volt 60 Hz time clock motor Intermatic 208/277 Volt, 60 Hz Replacement Time Clock Motor, WG1573-10D$5099 Intermatic PS3000 surge protector for pool and spa equipment Intermatic PS3000 Surge Protector for Pool and Spa Equipment, 120/240V$11599 Intermatic 21T156A 3 inch standoff spacer, four pack Intermatic 3" Standoff Spacer, 4 Pack, 21T156A$1899 Intermatic T40004RT3 load center with 300 W transformer and T104M time switch mechanism Intermatic 100 A Load Center with 300 W Transformer and T104M Mechanism, 8-Breaker Spaces, T40004RT3$36399

Questions and answers

What people ask about this product, answered by our pool techs.

What does DPST mean on the Intermatic 143T135?
DPST stands for double pole, single throw. The Intermatic 143T135 has two poles that close together when its coil is energized, so one relay switches two circuits at once, and each pole is simply on or off.
Which coil voltage do I need?
Match the coil voltage printed on the relay you are replacing. The Intermatic 143T135 has a 240 VAC coil, and Intermatic sells the same DPST, 3 HP relay with a 120 VAC coil as 143T136, a 24 VAC coil as 143RC151 and a 24 VDC coil as 143T145A.
Will the 143T135 work in my Intermatic pool control?
Intermatic lists the 143T135 as a pool and spa accessory for motor and pump control, rated 3 HP with a 240 VAC coil. Before ordering, check that the relay in your control is also a DPST relay with a 240 VAC coil and a 3 HP rating.
How should the relay be installed?
Turn off power at the main panel before opening the control that holds the Intermatic 143T135. Intermatic calls for its pool controls to be installed by a qualified person following national and local electrical codes, and the same care applies when replacing the relay inside one.
