Raypak 100-10000635 100K inlet temperature sensor for the Crosswind V heat pumpRaypak 100K Inlet Temperature Sensor for Crosswind V Heat Pump, 100-10000635$11799
Raypak 100-10000635 100K inlet temperature sensor for the Crosswind V heat pump
Shop all Raypak

Raypak 100K Inlet Temperature Sensor for Crosswind V Heat Pump, 100-10000635

Ask a questionMPN 100-10000635
$11799
Out of stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Raypak 100-10000635 The factory 100K inlet temperature sensor for the Crosswind V.
  • Inlet position Reads the water temperature entering the heat pump, which is where the control logic starts.
  • For the Crosswind V Built for the Crosswind V heat pump, not a generic thermistor.
  • Feeds the diagnostics The Crosswind V reports its status and faults from what its sensors tell it, so a bad reading becomes a bad fault code.
  • Genuine Raypak Ordered by Raypak part number, so the resistance curve and connector match the original.
  • A common cause of odd behavior A drifting inlet sensor can make the unit short cycle or refuse to run even when the water is fine.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Raypak 100K Inlet Temperature Sensor for Crosswind V Heat Pump, 100-10000635, SKU RAY-151-0228. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Raypak 100K Inlet Temperature Sensor for Crosswind V Heat Pump, 100-10000635
Raypak

100K Inlet Temperature Sensor for Crosswind V Heat Pump, 100-10000635

$11799
Raypak Heat Pump Digital Control Board 9350/9353 5450-8450, 100-10000347
Raypak

Heat Pump Digital Control Board 9350/9353 5450-8450, 100-10000347

$29699
Raypak 100K Temp Sensor Kit, 9350/9353 and 5450-8450 Heat Pumps, H000329
Raypak

100K Temp Sensor Kit, 9350/9353 and 5450-8450 Heat Pumps, H000329

$10299
Raypak Water Flow Switch for Crosswind Pool Heaters, 018146F
Raypak

Water Flow Switch for Crosswind Pool Heaters, 018146F

$13599
Raypak Water Unions and O-Ring for Crosswind Pool Heaters, 018155F
Raypak

Water Unions and O-Ring for Crosswind Pool Heaters, 018155F

$15199
Raypak Water Pressure Switch for Model 5100, 6100, 5100ti Pool Heater, H000025
Raypak

Water Pressure Switch for Model 5100, 6100, 5100ti Pool Heater, H000025

$4899
Raypak 5450/6450/8450 Heat Pump Switch Decal Membrane, H000326
Raypak

5450/6450/8450 Heat Pump Switch Decal Membrane, H000326

$8299
Subtotal

Similar products

Other products people compare with this one.

Raypak H000078 low pressure switch for heat pump pool heaters Raypak H000078 Low Pressure Switch for 2350, 3350, 4350, 5350, 6350 and 8350 Heat Pumps$6799 Raypak H000043 50 amp contactor for model 5100, 6100 and 5100Ti pool heaters Raypak 50 Amp Contactor for Model 5100, 6100, 5100Ti Pool Heaters, H000043$6299 Raypak H000077 12 ton TX valve for R8350 and P8350 heat pump pool heaters Raypak 12 Ton TX Valve for R8350/P8350 Heat Pump Pool Heater, H000077$35999

Product details

Raypak 100-10000635 is the 100K inlet temperature sensor for the Crosswind V pool heat pump. It is the genuine Raypak part, matched to the resistance curve and connector the control board expects.

What the inlet sensor does

The heat pump decides what to do based on the water temperature coming in. That reading drives whether the unit calls for heat, how it stages, and what it puts on the display. The Crosswind V leans on that information heavily for its status reporting and diagnostics, so when the sensor drifts the unit does not simply run a little off, it starts reporting faults that have nothing to do with the real problem.

Before you swap it

Check the obvious things first. Confirm flow through the unit is good, the filter is clean and the plumbing is not restricted, since a starved heat pump produces temperature complaints of its own. If the reported inlet temperature does not agree with a thermometer in the water, replace the sensor.

Specifications
Brand Raypak
Manufacturer part number 100-10000635
UPC 840328459568
Part type Pool Heater Part
Type 100K inlet temperature sensor
Position Inlet
Fits Raypak Crosswind V heat pump
Shipping weight 0.35 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Raypak

A technician with a tool belt beside Raypak heaters at a pool. Designed to perform, built to last. Raypak

Raypak heaters

Raypak Pool Heater, 399K BTU, Natural Gas, Digital Ignition, Copper Heat Exchanger, 0-2000 Ft. Elevation, P-R406A-EN-C, 009219 Raypak 266K BTU Natural Gas Pool Heater, Digital Ignition, Copper Heat Exchanger, 0-2000 Ft. Elevation, P-R266A-EN-C, 009217 Raypak Crosswind V Heat Pump, 138,000 BTU, with Titanium Heat Exchanger and Digital Controls, TWPH-8550EHT08 Raypak 156A 150K BTU Above Ground Pool and Spa Heater, Digital Controls, Electronic Ignition, Natural Gas, 0-4999 ft Elevation, 014784
Shop Raypak heaters

Genuine Raypak parts

Raypak Genuine OEM Protek Shield Module Assembly, 017960F Raypak Kit-PC 3-Wire Board Controller IID for 206A-408 Pool Heaters, 100-10000345 Raypak Genuine OEM Propane and Natural Gas Pilot, 002003F Raypak Genuine OEM 3/4" IID Pool Heater Natural Gas Electronic Valve, 003900F
Shop Raypak parts
Gas pool heaters: a red and black Raypak AVIA heaterHeat pumps: a Raypak Crosswind V heat pumpHeater parts: a technician with a tool belt in front of Raypak heaters
Raypak makes gas pool and spa heaters, heat pumps and electric heaters, with genuine replacement parts.Shop all Raypak

Customer reviews

More from Raypak

Raypak 100-10000347 heat pump digital control board Raypak Heat Pump Digital Control Board 9350/9353 5450-8450, 100-10000347$29699 Raypak 017960F Protek Shield module assembly for Raypak pool heaters Raypak Genuine OEM Protek Shield Module Assembly, 017960F$5199 Raypak Crosswind V 138,000 BTU pool heat pump TWPH-8550EHT08, quarter view Raypak Crosswind V Heat Pump, 138,000 BTU, with Titanium Heat Exchanger and Digital Controls, TWPH-8550EHT08$4,80000 Web Price Raypak 156A 150,000 BTU natural gas above ground pool and spa heater, part 014784 Raypak 156A 150K BTU Above Ground Pool and Spa Heater, Digital Controls, Electronic Ignition, Natural Gas, 0-4999 ft Elevation, 014784$2,49900 Web Price Raypak 003900F IID natural gas electronic combination valve Raypak Genuine OEM 3/4" IID Pool Heater Natural Gas Electronic Valve, 003900F$25199 Raypak WeatherKing TWPH-6560EHT01 118K BTU pool and spa heat pump Raypak WeatherKing 118K BTU Heat Pump 6560 with Powder-Coated Steel Cabinet and Digital Controls, TWPH-6560EHT01$3,39800 Web Price Raypak 100-10000345 Kit-PC 3-wire board controller IID for 206A-408 pool heaters Raypak Kit-PC 3-Wire Board Controller IID for 206A-408 Pool Heaters, 100-10000345$32499 Raypak 009219 Digital 399K BTU natural gas pool and spa heater, model P-R406A-EN-C Raypak Pool Heater, 399K BTU, Natural Gas, Digital Ignition, Copper Heat Exchanger, 0-2000 Ft. Elevation, P-R406A-EN-C, 009219$4,20000 Web Price Raypak 009217 P-R266A-EN-C 266K BTU natural gas digital pool heater, front view Raypak 266K BTU Natural Gas Pool Heater, Digital Ignition, Copper Heat Exchanger, 0-2000 Ft. Elevation, P-R266A-EN-C, 009217$3,17900 Web Price Raypak 014779 106A analog natural gas above ground pool heater Raypak Analog Natural Gas Above Ground Pool Heater 105,000 BTU, P-R106A-AN-C, 014779$1,99900 Web Price
Raypak 100-10000414 boiler burner 10-pack Raypak Boiler Burner 10-Pack, 100-10000414$4799 Raypak 017959F inlet/outlet header complete with ProTek Shield for 206A to 407A heaters Raypak Inlet/Outlet Header Complete with ProTek Shield, 017959F$40799 Raypak 002003F genuine OEM propane and natural gas pilot Raypak Genuine OEM Propane and Natural Gas Pilot, 002003F$8199 Raypak logo, placeholder image for the H000329 100K temp sensor kit Raypak 100K Temp Sensor Kit, 9350/9353 and 5450-8450 Heat Pumps, H000329$10299 Raypak 010394F burner tray with burners for the 406A pool heater Raypak Burner Tray with Burners for 406A Pool Heaters, 010394F$86999 Raypak 010060F copper tube bundle heat exchanger for 266A and 267A heaters Raypak Genuine OEM Copper Tube Bundle 266/267, 010060F$81599 Raypak 014931F cupro-nickel tube bundle for 266A polymer header heater Raypak 266A Polymer Cu-Ni Tube Bundle, 014931F$1,29299 Raypak E3T 11 kW 240V electric pool and spa heater, Ruud ELS-D-0011-1-Ti, part 017122 Raypak 11kW 240V E3T Electric Heater ELS-D-0011-1-Ti, 017122$1,15400 Web Price Raypak 019209F burner tray with LP burners, sea level, for heat exchanger models 399 and 406A Raypak Burner Tray with LP Burners Pro (Sea Level) for Heat Exchanger Models 399 and 406A, 019209F$37499 Raypak AVIA P-R404A-EN-N 399K BTU natural gas pool and spa heater Raypak AVIA 399K BTU Natural Gas Low NOx Pool Heater with WiFi, HD Nitek Tubing, 0-10,000 ft Elevation, P-R404A-EN-N, 018045$4,78000 Web Price

Questions and answers

What people ask about this product, answered by our pool techs.

Which sensor is this?
The inlet temperature sensor, the one reading water going into the Crosswind V heat pump. Raypak lists it as the 100K inlet sensor, part 100-10000635.
Will it fit any Raypak heat pump?
It is listed for the Crosswind V. Check your model and the sensor part number on the old probe before ordering.
Is it a genuine Raypak part?
Yes. It is the Raypak OEM sensor, part number 100-10000635.
Why would I replace a temperature sensor?
Sensors drift as they age. If the unit reports water temperatures that do not match a thermometer, short cycles, or throws a temperature related fault while the plumbing and flow are fine, the sensor is the usual suspect.
