AquaStar Retrofit 4 in. Sumpless Bulkhead Fitting with 1-1/2 in. MPT, White, R415T101
30 day returns · Easy, with prepaid labels provided
Does it fit your equipment?
Your model:
Quick overview
- Retrofit 4 in. size A 4 in. sumpless bulkhead with a 1-1/2 in. MPT thread and a 5.2 square inch opening.
- HydroAir retrofit Also retrofits HydroAir 30-6906 and 30-6806 outlets.
- 1022 adapters Fits 1022 female adapters.
- Flow ratings Rated 56 GPM at 3.5 fps and 24.4 GPM at 1.5 fps on a floor or wall.
- VGB series Carries the trademarked VGB 2008 compliance button, with number 316 stainless steel screws.
- Pool types For single or multiple drain use in gunite, steel, vinyl, fiberglass and tile pools and spas.
Need a hand?
Similar products
Other products people compare with this one.
Hayward Main Drain Gasket, Set of 2, SPX1048DPAK2$2299
Hayward 7-7/8" Main Drain Frame, White, WGX1048B$1999
CMP 8" Galaxy Drain Cover with Screw Pack, White, 25507-100-000$1799
CMP 8" Galaxy Gunite Pool Main Drain Lid and Frame, Gray, 25531-001-000$2299
AquaStar 8" Black Round MoFlow Suction Outlet Cover and Mud Frame, 8MF102$2799
SuperPro 8" Round White Anti-Vortex Main Drain Frame and Grate, SG640-2310VC$2499
SuperPro 8" Round Gray Anti-Vortex Main Drain Frame and Grate, SG6402317 VC$1999
Hayward Main Drain Frame Screws, 8 Per Pack, SPX1039Z18$1699
Hayward Screw for use with WGX1048E, Set of 2, WGX1030Z1AM$1199
Waterway 8" Anti-Vortex Main Drain Cover, White, 645-2150 V$1699
CMP 8 Inch Galaxy Lid and Frame, Black, 25531-004-000$2599
AquaStar 6 in. Sumpless Bulkhead Fitting with 2 in. Slip Insider, White, 620SI101$2499
AquaStar 6 in. Sumpless Bulkhead Fitting with 1-1/2 in. Extended MPT, White, 6E15T101$2499
AquaStar 6 in. Sumpless Bulkhead Adapter, 1-1/2 in. Slip Insider, White, 615SI101$2499
Hayward Suction Outlet Drain Guard for 8 in. AV Drains, White, SP1048AVH$2599
AquaStar 6 in. Sumpless Bulkhead Fitting with 2 in. MPT and 1-1/2 in. Slip Socket, White, 620T15S101$2499
AquaStar 6" Sumpless Bulkhead Fitting with 2" Slip Insider (VGB Series) Black | 620SI102$2499
AquaStar 6" Sumpless Bulkhead Fitting with 1.5" MPT (for 1022) (VGB Series) Dark Gray | 615T105$2499
AquaStar 8 in. Star Anti-Entrapment Cover with Solid Riser Ring and Mud Frame, VGB Series, Dark Gray, A8R105$2999
AquaStar 8" White Round MoFlow Suction Outlet Cover and Mud Frame, 8MF101$3099
Product details
The AquaStar R415T101 is a white retrofit 4 inch sumpless bulkhead fitting with a 1-1/2 inch male thread, and it also retrofits HydroAir 30-6906 and 30-6806 outlets.
What it does
A bulkhead fitting connects a suction outlet to the pool plumbing through the pool shell. This retrofit version is sumpless with a 5.2 square inch opening, and its pipe connection is a 1-1/2 in. MPT thread. The VGB 2008 color code compliance button identifies the cover from the deck and from underwater.
Fit and compatibility
The R415T101 retrofits HydroAir 30-6906 and 30-6806 and fits 1022 female adapters. AquaStar designs it for single or multiple drain use in gunite, steel, vinyl, fiberglass and tile pools and spas. Flow is rated at 56 GPM at 3.5 fps and 24.4 GPM at 1.5 fps on a floor or wall.
What is included
The parts listed are a 4 in. suction outlet cover, the retro 4 in. sumpless bulkhead with 1-1/2 in. MPT and flat head Phillips screws in 316 stainless steel. Six adapter plates for other connections are sold separately. The polymer is UV-resistant, and AquaStar states that it meets or exceeds ANSI/APSP 16-2011 and NSF 50-2008.
| Brand | AquaStar |
|---|---|
| Manufacturer part number | R415T101 |
| UPC | 883612034799 |
| Type | Retrofit sumpless bulkhead fitting |
| Diameter | 4 in. |
| Color | White |
| Thread | 1-1/2 in. MPT |
| Opening | 5.2 square inch, sumpless |
| Flow rating | 56 GPM at 3.5 fps, 24.4 GPM at 1.5 fps, floor or wall |
| Material | UV-resistant engineered polymer |
| Retrofits | HydroAir 30-6906, HydroAir 30-6806 |
| Fits | 1022 female adapters |
| Includes | 4 in. suction outlet cover, retro 4 in. sumpless bulkhead, flat head Phillips screws, 316 stainless steel |
| Pool types | Gunite, steel, vinyl, fiberglass, tile pools and spas |
| Shipping weight | 0.05 lb |
| Ships | Parcel |
