PoolTux King99 16 x 32 ft Mesh Safety Cover with Center Step, Tan, 20 Year Warranty, CSPTTMP16321PoolTux King99 16 x 32 ft Mesh Safety Cover with Center Step, Tan, CSPTTMP16321$1,81973
PoolTux King99 16 x 32 ft Mesh Safety Cover with Center Step, Tan, 20 Year Warranty, CSPTTMP16321
Shop all Pooltux

PoolTux King99 16 x 32 ft Mesh Safety Cover with Center Step, Tan, CSPTTMP16321

Ask a questionMPN CSPTTMP16321
$1,81973
FREE Delivery
Typically ships within 10 days This item ships directly from the manufacturer.
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Fits A 16 x 32 ft rectangle with the step centered on one long side.
  • Step panel 8 ft wide and 4 ft back at the water line.
  • Panel 18 x 34 ft, about a foot of overlap onto the deck on each side.
  • In the box Flush mount brass anchors and collars, commercial grade stainless steel springs, an installation rod, a tamping tool and a storage bag.
  • Tension Tension-Tech springs let the cover be pulled up tight and hold it there as the fabric moves.
  • Warranty 20 years limited, the first 5 full.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About PoolTux King99 16 x 32 ft Mesh Safety Cover with Center Step, Tan, CSPTTMP16321, SKU PT-IG-300104. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item PoolTux King99 16 x 32 ft Mesh Safety Cover with Center Step, Tan, CSPTTMP16321
Pooltux

PoolTux King99 16 x 32 ft Mesh Safety Cover with Center Step, Tan, CSPTTMP16321

$1,81973
Coverstar A1100 Slider Assembly for Detachable Rope, 403 and 801A Under Guide
Coverstar

A1100 Slider Assembly for Detachable Rope, 403 and 801A Under Guide

$7699
Coverstar H1070 Double Ball Bearing Rope Pulley, Stainless Steel
Coverstar

H1070 Double Ball Bearing Rope Pulley, Stainless Steel

$2799
Coverstar Complete Control Switch Assembly, A0605
Coverstar

Complete Control Switch Assembly, A0605

$22499
Little Giant Adapter Fitting for 3/4", APCP-1700, 177343
Little Giant

Adapter Fitting for 3/4", APCP-1700, 177343

$2099
Anderson Winter Duck Plug Check Valve, Fits 1.5 in. PVC, WDP150
Anderson Manufacturing

Anderson Winter Duck Plug Check Valve, Fits 1.5 in. PVC, WDP150

$1499
Coverstar 100 ft PowerFlex Rope with Semi-Rigid Tab, C6100
Coverstar

100 ft PowerFlex Rope with Semi-Rigid Tab, C6100

$19099
Subtotal

Similar products

Other products people compare with this one.

GLI Secur-A-Pool blue mesh safety cover for an 18 x 36 ft rectangle pool, 20-1836RE-SAP-BLU GLI Secur-A-Pool Mesh Safety Cover for 18 x 36 ft Rectangle Pools, Blue, 20-1836RE-SAP-BLU$1,22699 GLI Secur-A-Pool blue mesh safety cover for an 18 x 36 ft rectangle pool with 4 x 8 ft CES, 20-1836RE-CES48-SAP-BLU GLI Secur-A-Pool Mesh Safety Cover with 4 x 8 ft CES for 18 x 36 ft Rectangle Pools, Blue, 20-1836RE-CES48-SAP-BLU$1,28999 GLI Mesh Safety Cover for 18 x 36 ft Rectangle Pools, Green, 4 x 8 ft CES, 20-1836RE-CES48-SAP-GRN$1,28999 GLI Secur-A-Pool blue mesh safety cover for a 16 x 32 ft rectangle pool with 4 x 8 ft CES, 20-1632RE-CES48-SAP-BLU GLI Secur-A-Pool Mesh Safety Cover with 4 x 8 ft CES for 16 x 32 ft Rectangle Pools, Blue, 20-1632RE-CES48-SAP-BLU$1,15799 GLI Mesh Safety Cover for 16 x 32 ft Rectangle Pools, Green, 4 x 8 ft CES, 20-1632RE-CES48-SAP-GRN$1,15399 GLI Secur-A-Pool blue mesh safety cover for a 20 x 40 ft rectangle pool, 20-2040RE-CES48-SAP-BLU GLI Mesh Safety Cover for 20 x 40 ft Rectangle Pools, Blue, 4 x 8 ft CES, 20-2040RE-CES48-SAP-BLU$1,42599 Pooltux Royal Green Mesh Rectangular Safety Cover | CSPTGME20401 PoolTux Royal 20 x 40 ft Mesh Safety Cover with Center End Step, Green, CSPTGME20401$1,14599 Pooltux Royal Blue Mesh Rectangle Safety Cover | CSPTBME16320 PoolTux Royal 16 x 32 ft Mesh Safety Cover, Blue, CSPTBME16320$86199 Coverstar A1153 under track rope slider assembly, retrofit, set of 2 Coverstar Slider Assembly, UG Retro, Set of 2, A1153$8099 Coverstar E2000 115V sealed stainless steel automatic pool cover motor Coverstar E2000 115V Sealed Stainless Steel Motor$1,38399
Poolguard MWUG Ultra Gizzmo skimmer freeze protection device for in ground pools Poolguard Gizzmo Ultra, 16" Length, 1.5" to 2.0", for In-Ground Pools, MWUG$2099 Coverstar A1932 13 in. stainless steel adjustable walk-on lid bracket with mounting base Coverstar 13 in. Stainless Steel Adjustable Walk-on Lid Bracket with Mounting Base, A1932$19699 Coverstar C4062 semi rigid 3 inch tab for detachable rope Coverstar Tab Semi Rigid for Detach Rope 418, C4062$1499 Coverstar A0996 stainless steel guide feed with hardware for 403 and 801 series under guide systems Coverstar Guide Feed with Hardware for 403/801 Series Under Guide System, Stainless Steel, A0996$5499 Coverstar A0041 3 in. white leading edge block insert assembly Coverstar Single CS1800/CS3000/Eclipse UG 3 in. Leading Edge White Block Insert Assembly, A0041$10499 Horizon HV9X10 floating spa cover on the water, with close up of the material Horizon 9 ft x 10 ft Floating Spa Cover, HV9X10$28799 Hayward 004-302-1672-00 2 in. winter plug, 6 pack Hayward Winter Plug, 6 Pack, 004-302-1672-00$13999 Coverstar A1071 2-piece stainless steel guide feed assembly for automatic pool covers Coverstar 2-Piece Stainless Steel Guide Feed Assembly without Mounting Hardware, A1071$6199 Little Giant 101375 volute with lip, front pump housing for cover pumps Little Giant Volute with Lip For Cover Pump, 101375$2699 Coverstar M9886 stop block slider for 805 wheel assembly and STD TG 403 Coverstar Stop Block Slider for Wheel Assembly 805, STD TG 403, M9886$1999

Product details

This tan King99 panel fits a 16 x 32 ft rectangular pool with the step in the middle of one long side. The cover itself is 18 x 34 ft, cut a foot larger on each side so the edge lands on the deck where the anchors go, and the step section is 8 ft wide by 4 ft back at the water line.

  • Tan mesh, self draining, so rain and snowmelt reach the pool instead of the fabric.
  • Straps on a 5 ft grid, each one under a Tension-Tech spring that holds the tension.
  • Flush mount brass anchors and collars, which do not corrode and adjust with a hex key.
  • Chafing strips along the edge protect the webbing and the coping from each other.
  • Packed with the installation rod, tamping tool and a storage bag for the summer.

Nothing here has to be bought separately to get the cover on the pool. The anchors tamp level into concrete or paver decking, the rod hooks each spring so you can stretch the strap without fighting it, and the springs go on doing the work afterward as the fabric loosens and tightens with the weather. A tighter install is also a stronger one, since tension is what lets the cover carry a load. Deck has to run all the way around the pool for any of it to hold. The warranty is 20 years limited, 5 full.

Specifications
Brand PoolTux
Series King99
Part number CSPTTMP16321
Pool size 16 x 32 ft rectangle
Cover size 18 x 34 ft
Step Center step
Step area 8 ft wide, 4 ft back at the water line
Material Mesh, self draining
Strap spacing 5 x 5 ft
Hardware Flush mount brass anchors and collars, stainless steel springs
Included tools Installation rod, tamping tool, storage bag
Warranty 20 year limited, first 5 years full

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Pooltux

PoolTux King 24 ft round solid winter cover in silver on black PoolTux 24' Solid Round Winter Cover, 15 Year King Warranty, 1228ASBL$9999 PoolTux 30' round solid Ultra Premium winter cover for above ground pools PoolTux 30' Solid Round Ultra Premium Winter Cover, 25 Year Warranty, BB0030$19199 PoolTux King 30' x 50' solid rectangle winter cover, 15 year warranty PoolTux 30' x 50' Solid Rectangle Winter Cover, 15 Year King Warranty, 123555ISBL$21399 PoolTux BB1836R Ultra Premium solid rectangle winter cover for an 18 by 36 foot pool PoolTux 18'x36' Solid Rectangle Ultra Premium Winter Cover, 25 Year Warranty, BB1836R$15699 PoolTux King 20'x40' solid rectangle winter cover, silver on black PoolTux 20'x40' Solid Rectangle Winter Cover, 15 Year King Warranty, 122545ISBL$14099 PoolTux BB0024 24 ft solid round above ground winter pool cover PoolTux 24' Solid Round Above Ground Ultra Premium Winter Pool Cover, 25 Year Warranty, BB0024$14199 PoolTux BB1530 Ultra Premium solid oval winter cover for a 15x30 above ground pool PoolTux 15'x30' Solid Oval Ultra Premium Winter Cover, 25 Year Warranty, BB1530$12099 PoolTux CSPTBS16322 Emperor Solid 16 x 32 ft left step safety cover, blue PoolTux Emperor 16 x 32 ft Solid Safety Cover with Left Step, Blue, 20 Year Warranty, CSPTBS16322$2,34899 PoolTux BT2545R 25'x45' solid rectangle winter cover with 20 year Emperor warranty PoolTux 25'x45' Solid, Rectangle Winter Cover, 20 Yr. Emperor Warranty, BT2545R$27399 PoolTux ultra premium 30'x50' solid rectangle winter cover PoolTux Ultra Premium 30'x50' Solid Rectangle Winter Cover, 25 Year Warranty, BB3050R$28799
PoolTux round leaf guard net for 27 and 28 foot above ground pools PoolTux 27'/28' Round Leaf Guard, LN31A$13599 PoolTux BB1632R ultra premium solid rectangle winter cover for a 16'x32' in-ground pool PoolTux 16'x32' Solid Rectangle Ultra Premium Winter Cover, 25 Year Warranty, BB1632R$13799 PoolTux 30 ft round solid winter cover, silver on black PoolTux 30' Solid, Round Winter Cover, 15 Year King Warranty, 1234ASBL$13899 PoolTux WTB-1019 4 foot by 8 foot winter cover equalizer pillow PoolTux 4' x 8' Equalizer Pillow, WTB-1019$2799 PoolTux Royal solid blue winter cover for a 24 ft. round above ground pool PoolTux 24 ft. Round Solid Winter Cover, 10 Year Royal Warranty, 7728AGBLB$7199 PoolTux BB2545R 25' x 45' solid rectangle Ultra Premium winter pool cover PoolTux 25' x 45' Solid Rectangle Ultra Premium Winter Cover, 25 Year Warranty, BB2545R$24599 PoolTux BT2040R 20'x40' solid rectangle winter cover with 20 year Emperor warranty PoolTux 20'x40' Solid Rectangle Winter Cover, 20 Yr. Emperor Warranty, BT2040R$19999 PoolTux 8 ft double chamber pool cover water tube in blue 16 gauge vinyl PoolTux 1'x8' 16 Gauge Double Pool Cover Water Tube, WTB-1001$1599 PoolTux solid rectangle winter cover for an inground pool PoolTux 30'x50' Solid Rectangle Winter Cover, 8 Year Royal Warranty, 773555IU$18099 PoolTux Ultra Premium solid brown winter pool cover installed on an inground pool PoolTux 18'x40' Solid Rectangle Ultra Premium Winter Cover, 25 Year Warranty, BB1840R$16799

Questions and answers

What people ask about this product, answered by our pool techs.

What hardware comes with the cover?
Enough to install it: flush mount brass anchors with their collars, commercial grade stainless steel springs for the straps, a rod for hooking the springs during the install, a tamping tool for driving the anchors level with the deck, and a bag for storing the cover through the swim season.
What size pool does this fit?
A 16 x 32 ft rectangle with a center step. The panel is 18 x 34 ft, one foot larger on each side, which is the overlap that reaches the deck.
What size step will this cover?
A step up to 8 ft wide and 4 ft back at the water line, which is how the step section on this panel is cut. Measure your own step at the water line on both axes. Anything larger is outside what this cover is made to sit over.
How do the anchors fit into a concrete deck?
They drop into a drilled hole and tamp down until the top sits flush with the surface, so there is nothing to trip over once the cover is off. A hex key raises them when it is time to hook the springs and lowers them again in spring.
