King Technology 01-22-9446 control dial with O-ring for New Water 400 and 430King Technology Control Dial with O-ring for New Water 400, 430, 01-22-9446 In stock$3999
King Technology 01-22-9446 control dial with O-ring for New Water 400 and 430
Shop all King Technology

King Technology Control Dial with O-ring for New Water 400, 430, 01-22-9446

Ask a questionMPN 01-22-9446
$3999
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Genuine King Technology Part number 01-22-9446, the current factory dial.
  • O-ring included The dial comes with its O-ring, so the seal is replaced along with the dial.
  • Fits the 400 and 430 The in line and off line New Water systems currently sold.
  • Covers discontinued units Also listed for the discontinued New Water 600 and 630.
  • Supersedes 01-22-9440 It replaces the earlier control dial with O-ring and snap ring.
  • Restores the setting The dial is how you meter the system, so a cracked or slipping dial is worth changing before you chase water chemistry.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About King Technology Control Dial with O-ring for New Water 400, 430, 01-22-9446, SKU KTC-451-7855. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item King Technology Control Dial with O-ring for New Water 400, 430, 01-22-9446
King Technology

Control Dial with O-ring for New Water 400, 430, 01-22-9446

$3999
Jandy R0693900 TruClear PCB Cell Replacement Assembly for Pro Series Chlorine Generator
Jandy

R0693900 TruClear PCB Cell Replacement Assembly for Pro Series Chlorine Generator

$75499
Jandy Port Sensor Kit for 3 Port Cell with 16' Cable, R0452500
Jandy

Port Sensor Kit for 3 Port Cell with 16' Cable, R0452500

$24599
Hayward CL200EF In-Line Automatic Pool Chlorinator, 9 lb Chemical Feeder
Hayward

CL200EF In-Line Automatic Pool Chlorinator, 9 lb Chemical Feeder

$12499
Jandy R0984100 AquaPure Power Interface PCB, Large Backboard with Screws
Jandy

R0984100 AquaPure Power Interface PCB, Large Backboard with Screws

$23999
Jandy AquaLink AquaPure 3-Port 14-Blade Replacement Salt Cell Kit, 40K Gallons, 16' Cable, PLC1400
Jandy

AquaLink AquaPure 3-Port 14-Blade Replacement Salt Cell Kit, 40K Gallons, 16' Cable, PLC1400

$1,39500
Jandy AquaPure PureLink 3-Port 14-Blade 1400 Replacement Salt Cell Kit for 40,000 Gallon Pools, R0452400
Jandy

AquaPure PureLink 3-Port 14-Blade 1400 Replacement Salt Cell Kit for 40,000 Gallon Pools, R0452400

$1,22900
Subtotal

Similar products

Other products people compare with this one.

Zodiac R0502300 large collar with o-ring for Nature2 Fusion sanitizers Zodiac Large Collar with O-ring, R0502300$5299 King Technology Spa Frog @Ease 01-14-3256 floating hot tub sanitation system King Technology Spa Frog @Ease Floating Sanitation System, 01-14-3256$5795 Web Price DEL Ozone 9-0770-01 Eclipse ozone check valve and 10 ft tubing assembly DEL Ozone Eclipse Ozone Check Valve and 10 ft Tubing Assembly, 9-0770-01$3199 Zodiac R0502400 small collar with o-ring for Nature2 Fusion Zodiac Small Collar with O-Ring for Nature2 Fusion, R0502400$2899 Nature2 R0586300 quad ring for the Zodiac Nature2 Fusion large collar Nature2 Quad Ring for Zodiac Nature2 Fusion, Large Collar, R0586300$2499 King Technology 01-14-3258 @ease floating SmartChlor cartridge, 3 pack King Technology @Ease Floating SmartChlor Cartridge, 3 Pack, 01-14-3258$5795 Web Price CMP R0991100 DEL injector tube adapter CMP R0991100 DEL Injector Tube Adapter$4499 King Technology Spa Frog Floating System with mineral and bromine cartridge holder King Technology Spa Frog Floating System, 01-14-3883$4499 King Technology 01-22-1458 control dial with O-rings for Pool Frog 25K King Technology Control Dial with O-rings, 25K Pool Frog, 01-22-1458$2999 PoolRx 332001 +Plus blue and white booster with silver for 7.5K to 20K gallon pools PoolRx +Plus Blue/White Booster (with silver) for 7.5K to 20K Gallon Pools, 332001$4299
Nature2 W13073 o-ring for the two piece locking ring cap Nature2 O-Ring for 2 Piece Locking Ring Cap, W13073$4399 Pentair 523375 BioShield union assembly for models 522935 to 522937 Pentair BioShield Union Assembly for Models 522935 to 522937, 523375$5699 King Technology Spa Frog Mineral Cartridge for Floating or Spa Inline System | 01-14-3812 King Technology Spa Frog Mineral Cartridge for Floating or Spa Inline System | 01-14-3812$3895 Web Price King Technology FROG Filter Mate mineral hot tub sanitizer cartridge, order code 01-14-3712 King Technology FROG Filter Mate Mineral Hot Tub Sanitizer for Filter Cartridges, Up to 600 Gallons, 01-14-3712$4095 Web Price Delta Ultraviolet replacement UV bulb 1000-2668 Delta Ultraviolet Replacement UV Bulb for E, ES, EP, EA-3H and EA-4H-5 Models, 1000-2668$2999 Pentair 523383 Bioshield UV seal kit Pentair Bioshield UV Seal Kit, 523383$6299 Zodiac R0586200 tab feeder o-ring for the Nature2 Fusion sanitizer Zodiac Tab Feeder O-Ring for Nature2 Fusion, Qty 2, R0586200$1499 Pentair 523031 BioShield UV sterilizer o-ring service kit Pentair BioShield UV O-Ring Service Kit, 523031$6899 Neptune Benson 1/2 psi pressure switch for a Delta UV unit Neptune Benson Pressure Switch 1/2 PSI, 70-02315$7699 DEL Ozone 9-0150E installation kit for Eclipse series ozone systems DEL Ozone Installation Kit, Eclipse Series, 9-0150E$7799

Product details

Part 01-22-9446 is the King Technology control dial with its O-ring, for the New Water 400 and 430 systems. It is also listed for the discontinued New Water 600 and 630.

What it does

The control dial is the adjustment on the front of the unit, the setting that decides how much water passes through the cartridge and therefore how the system treats the pool. It takes every adjustment the owner makes over a season, and it seals against the body through the O-ring behind it. When the dial cracks, will not hold its setting, or weeps around the shaft, the whole system stops doing what its setting says it is doing.

Supersession

This part number replaces the earlier 01-22-9440. The old number was listed as the dial with an O-ring and a snap ring, while the current part is listed as the dial with the O-ring, so hold onto the snap ring from your existing assembly if there is one.

Specifications
Brand King Technology
Manufacturer part number 01-22-9446
UPC 722906094401
Type Control dial with O-ring
Fits New Water 400, New Water 430, and the discontinued New Water 600 and 630
Replaces 01-22-9440, control dial with O-ring and snap ring
Shipping weight 0.15 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from King Technology

King Technology 01-22-9411 cap with o-ring for Perform-Max in ground feeder King Technology Cap with O-ring for Perform-Max In Ground Feeder, 01-22-9411$5199 King Technology Spa Frog @Ease 01-14-3256 floating hot tub sanitation system King Technology Spa Frog @Ease Floating Sanitation System, 01-14-3256$5795 Web Price King Technology 01-22-9417 cap with o-ring for in ground feeders King Technology Cap with O-Ring for 5400, 5430 and 5450 XL Pro and Mineral Hybrid In Ground Feeders, 01-22-9417$3899 King Technology Perform-Max Model 940 in ground in-line chemical feeder King Technology Perform-Max Model 940 In Ground In-Line Feeder, 01-05-0940$13399 King Technology Frog Jump Start Spa Shock King Technology Frog Jump Start Spa Shock, 01-14-6012$3199 King Technology Pool Frog Model 5400 in-line system for in ground pools up to 40,000 gallons King Technology Pool Frog Model 5400 In-Line System, Up to 40,000 Gallons, 01-01-5480$51095 Web Price King Technology Perform-Max Model 960 in ground off-line chemical feeder King Technology Perform-Max Model #960 In Ground Off-Line Feeder, 01-05-0960$15999 King Technology New Water Model 400 in-line chlorine cycler for in ground pools King Technology New Water Model 400 In-Line Cycler for In Ground Pools, 01-01-0400$15799 King Technology 01-22-9426 body o-ring for Perform-Max 940 and 960 feeders King Technology Body O-ring for Perform-Max 940 and 960 (Before 1992), 01-22-9426$2899 King Technology 01-14-3258 @ease floating SmartChlor cartridge, 3 pack King Technology @Ease Floating SmartChlor Cartridge, 3 Pack, 01-14-3258$5795 Web Price
King Technology Perform-Max Model 920 above ground in-line feeder King Technology Perform-Max Model #920 Above Ground In-Line Feeder, 01-05-0920$12999 King Technology Spa Frog cartridge refill kit with bromine and mineral cartridges King Technology Spa Frog Cartridge Refill Kit, 714429$8680 Web Price King Technology 01-22-1456 control dial O-ring set for above ground cyclers King Technology Control Dial O-ring Set for Above Ground Cyclers 120, 920, 6100, 7800, 01-22-1456$1199 King Technology Pool Frog Bac Pac chlorine cartridge, 2.2 lbs King Technology Pool Frog Bac Pac 2.2 lbs, 01-03-5880$2995 King Technology Pool Frog 6100 in-line mineral sanitizing system King Technology Pool Frog 6100 In-line System, 1563240$26995 Web Price King Technology Spa Frog Floating System with mineral and bromine cartridge holder King Technology Spa Frog Floating System, 01-14-3883$4499 King Technology New Water Model 120 in-line cycler for above ground pools King Technology New Water Model 120 In-Line Cycler for Above Ground Pools, 01-01-0120$19699 King Technology Pool Frog in ground mineral reservoir cartridge King Technology Pool Frog In Ground Mineral Reservoir, 01-12-5462$14895 Web Price King Technology 01-22-1458 control dial with O-rings for Pool Frog 25K King Technology Control Dial with O-rings, 25K Pool Frog, 01-22-1458$2999 King Technology 01-14-3350 Frog @ease test strips King Technology Frog @ease Test Strips, 01-14-3350$1095

Questions and answers

What people ask about this product, answered by our pool techs.

Which systems does this dial fit?
The New Water 400 and 430, and the discontinued New Water 600 and 630.
Does the O-ring come with it?
Yes. It is listed as the control dial with O-ring.
I have part 01-22-9440. Is this the right replacement?
Yes. 01-22-9446 replaces 01-22-9440. Note that the older number was listed as the dial with an O-ring and a snap ring, so keep your existing snap ring if your dial uses one.
Why would the dial need replacing?
It is the one part you handle every time you adjust the system. Dials crack at the hub, lose their detent or slip on the shaft, and the O-ring behind them hardens with age.
Ask your own question
