Pentair 154493 O-108 closure o-ring, 5-3/4 inch inside diameterPentair Genuine OEM O-Ring Closure, 5-3/4" ID, 154493 O-108 In stock$1099
Pentair 154493 O-108 closure o-ring, 5-3/4 inch inside diameter
Shop all Pentair

Pentair Genuine OEM O-Ring Closure, 5-3/4" ID, 154493 O-108

Ask a questionMPN 154493 O-108
$1099
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Genuine Pentair The factory closure o-ring, not a generic seal cut to size.
  • 5-3/4 inch inside diameter Sized to the filter closure it seals against.
  • 1/8 inch thickness The cross section that gives the closure its squeeze.
  • Tagelus and Triton II Listed as the replacement closure o-ring for those Pentair filter models.
  • Two references on the part Carried as Pentair 154493 and as o-ring size O-108.
  • The usual leak fix A closure that weeps after the filter is opened almost always needs the o-ring, not more tightening.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Pentair Genuine OEM O-Ring Closure, 5-3/4" ID, 154493 O-108, SKU PAC-051-1899. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Pentair Genuine OEM O-Ring Closure, 5-3/4" ID, 154493 O-108
Pentair

Genuine OEM O-Ring Closure, 5-3/4" ID, 154493 O-108

$1099
Pentair Genuine OEM 2 in. Triton II Bulkhead Kit, 154714Z
Pentair

Genuine OEM 2 in. Triton II Bulkhead Kit, 154714Z

$15299
Pentair Genuine OEM 8-1/2" Triton II Buttress Thread Closure Kit, 154856Z
Pentair

Genuine OEM 8-1/2" Triton II Buttress Thread Closure Kit, 154856Z

$23499
Pentair Genuine OEM Manual Air Relief Assembly for Triton II, 273564Z
Pentair

Genuine OEM Manual Air Relief Assembly for Triton II, 273564Z

$9299
Pentair Triton II Buttress Thread Closure O-Ring, 152516Z
Pentair

Triton II Buttress Thread Closure O-Ring, 152516Z

$1199
Pentair Genuine OEM 2" Bulkhead O-Ring, 154492
Pentair

Genuine OEM 2" Bulkhead O-Ring, 154492

$1199
Pentair Lateral for Triton II TR40, TR50, TR60, Genuine OEM, 152290
Pentair

Lateral for Triton II TR40, TR50, TR60, Genuine OEM, 152290

$1499
Subtotal

Similar products

Other products people compare with this one.

Pentair 271094 threaded valve adapter kit for Triton II TR100C and TR140C sand filters, two adapters shown Pentair 1-1/2 in. Threaded Valve Adapter Kit for Triton II TR100C and TR140C Sand Filters, 271094$5699

Product details

This is the genuine Pentair closure o-ring, 5-3/4 inch inside diameter by 1/8 inch thick, listed as the replacement closure seal for Tagelus and Triton II filter models.

Two numbers, one part

Pentair carries it as 154493 and it also appears under the standard o-ring size O-108. Both point at the same seal, so either reference will get you here.

Where it sits

The closure o-ring is the seal between the filter body and its closure. It is compressed every time the filter is shut up, and it lives under full system pressure once the pump runs. That combination is what wears it out.

Fitting it properly

Clean the groove out before the new ring goes in, since old grit is a common cause of a fresh o-ring leaking. Use a lubricant suited to pool o-rings and seat it evenly. If a closure is weeping, the answer is a new ring rather than more force on the clamp.

Specifications
Brand Pentair
Manufacturer part number 154493 O-108
UPC 788379693459
Type Closure o-ring
Inside diameter 5-3/4 inch
Thickness 1/8 inch
Fits Pentair Tagelus and Triton II filter models
Part type Filter valve part
Listed in parts diagrams for Pentair PacFab Tagelus sand filter; Pentair Triton II TR40, TR50, TR60, TR100, TR140 sand filter; Pentair PacFab top mount and side mount 1-1/2 inch multiport valve; Pentair PacFab 6 way 1-1/2 inch Hi-Flo multiport valve
Shipping weight 0.2 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Pentair

Your trusted source for all things pool. Pentair

Pentair equipment

Pentair SuperFlo VS 1.5 HP Variable Speed Pool Pump, EC-342001 Pentair MasterTemp 400 Natural Gas Pool Heater, EC-462028 Pentair Clean & Clear Plus 420 sq ft Cartridge Pool Filter, EC-160301 Pentair IntelliConnect Control & Monitoring System with Wi-Fi, EC-523317
Shop Pentair equipment

Genuine Pentair parts

Pentair Genuine OEM Seal Kit for WhisperFlo and IntelliFlo Pool Pumps, 356198 Pentair Genuine OEM High Flow Manual Air Relief Valve, 98209800 Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400 Pentair Genuine OEM MasterTemp/Max-E-Therm 6-Button Control Board Kit, 461105Z
Shop Pentair parts
Pool lighting: a backyard pool and spa lit in blue and green at nightPool water treatment: three people floating on rings in clear blue water, seen from abovePool cleaners: a toddler in flower sunglasses laughing in a yellow ring, held by her mother
Pentair makes pumps, filters, heaters, salt chlorinators, cleaners, lighting and automation for pools and spas.Shop all Pentair

Customer reviews

More from Pentair

Pentair SuperFlo VS EC-342001 1.5 HP variable speed pool pump, front view Pentair SuperFlo VS 1.5 HP Variable Speed Pool Pump, EC-342001$1,48900 Pentair SuperFlo EC-348190 single speed pool pump, 1 HP, 115/230V Pentair SuperFlo 1 HP Single Speed Pool Pump, 115/230V, EC-348190$74800 Pentair WhisperFlo VS EC-011533 2.6 THP variable speed pool pump, top view Pentair WhisperFlo VS 2.6 THP Variable Speed Pool Pump, 115/208-230V, EC-011533$1,79900 Pentair 262506 HiFlow 1.5 in. six way clamp style multiport valve Pentair Genuine OEM HiFlow Valve 1.5 in. 6-Way Clamp Style, 262506$20999 Pentair EC-520556 IntelliChlor 110/220V power center Pentair 110/220V IntelliChlor Salt Chlorine Generator Power Center, EC-520556$79900 Web Price Pentair 523769 IntelliChlor Plus and LT replacement sensor board Pentair IntelliChlor Plus and LT Replacement Sensor Board, 523769$40499 Pentair 350305S 3.2 kW 10 pole variable speed motor for IntelliFloXF and IntelliFlo 2 VST pumps Pentair 3.2 kW IntelliFloXF VSF, VSF, VS+SVRS, i1, i2 Motor, 350305S$78199 Pentair 523735-EC IntelliChlor Plus40 salt chlorine generator cell Pentair IntelliChlor Plus40 Salt Chlorine Generator Replacement Cell, 40,000 Gallons, 523735-EC$1,81900 Web Price Pentair Rainbow 320 in-line chlorinator R171096, front view Pentair Rainbow 320 In-Line Chlorinator, R171096$14999 Pentair 190003 tank clamp kit with tension control for Clean and Clear Plus, FNS Plus and Quad DE filters Pentair Genuine OEM Clamp Kit with Tension Control, 190003$31099
Pentair IntelliChlor LT25 salt chlorine generator cell 523747-EC Pentair IntelliChlor LT25 Salt Chlorine Generator Cell, 25,000 Gallons, 523747-EC$1,15699 Pentair IntelliFlo VS+SVRS variable speed pool pump, EC-011057 Pentair IntelliFlo VS+SVRS Variable Speed Pool Pump, EC-011057$2,39900 Pentair 170145 cartridge pack for Sta-Rite System 3 S7M120, inner and outer cartridges Sta-Rite 170145 System 3 S7M120 Large and Small Cartridge Set, 25021-0200S and 25022-0201S$47999 Pentair 261055 SM-20-3 2 in. side mount multiport valve kit, front view Pentair 2 in. Multiport Valve Kit for Side Mount Sand Filters, SM-20-3, 261055$30899 Pentair 523770 IntelliChlor Plus replacement controller (HMI), black Pentair IntelliChlor Plus Controller Replacement (HMI), Black, 523770$39599 Pentair 261152 SM20-2 2 in. side mount multiport valve kit for DE filters Pentair 2" Valve Kit Multiport, Side Mount DE Filters SM20-2, 261152$30799 Pentair 357149 WhisperFlo and IntelliFlo volute housing replacement kit, front view Pentair WhisperFlo and IntelliFlo Volute Housing Replacement Kit, 357149$29699 Pentair MicroBrite Color LED pool light EC-620425, 12 volt, 14 watt, with 100 ft cord Pentair MicroBrite Color LED Pool Light 12 Volt, 14 Watt with 100' Cord, EC-620425$61900 Pentair 59023400 FNS Plus 48 sq ft complete DE grid assembly Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400$40599 Pentair Amerlite EC-602128 500W 120V inground pool light with stainless steel facering Pentair Amerlite Pool Light for Inground Pools with Stainless Steel Facering, 500W 120V 50' Cord, EC-602128$43900 Web Price

Questions and answers

What people ask about this product, answered by our pool techs.

What size is this o-ring?
5-3/4 inch inside diameter with a 1/8 inch thickness.
Why does it carry two part numbers?
Pentair lists it as 154493 and it also carries the standard o-ring size designation O-108. Both refer to the same seal.
Which filters does it fit?
It is the replacement closure o-ring for the Pentair Tagelus and Triton II filter models. It also appears in the PacFab multiport valve parts diagrams.
My filter leaks at the closure. Is this the fix?
Usually. A closure that weeps once the filter has been opened is normally down to an o-ring that has taken a set, been nicked, or dried out. Clean the groove, fit the new ring with a suitable lubricant, and do not rely on over tightening.
