Pentair MicroBrite Color LED pool light EC-620425, 12 volt, 14 watt, with 100 ft cord
Shop all Pentair

Pentair MicroBrite Color LED Pool Light 12 Volt, 14 Watt with 100' Cord, EC-620425

Ask a questionMPN EC-620425
$61900
FREE Delivery
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Color changing LED dynamic color and uniform light output from a compact 12 volt LED fixture.
  • No niche required installs in a standard 1.5 in. pool wall fitting, so no niche or housing to set.
  • Just 3.5 in. long small enough for narrow walls, tight spaces and water as shallow as 4 in.
  • 100 ft cord long enough to reach the transformer and junction box on most pool layouts without splicing.
  • 14 watts at 12 volts low power draw compared with incandescent, rated for about 10 times the life.
  • Retrofit friendly a straightforward upgrade for pools with older lighting or fiber optic systems.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Pentair MicroBrite Color LED Pool Light 12 Volt, 14 Watt with 100' Cord, EC-620425, SKU AMP-30-1321. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Pentair MicroBrite Color LED Pool Light 12 Volt, 14 Watt with 100' Cord, EC-620425
Pentair

MicroBrite Color LED Pool Light 12 Volt, 14 Watt with 100' Cord, EC-620425

$61900
CMP Pool Light Adapter Repair Ring, 25549-500-000
CMP

Pool Light Adapter Repair Ring, 25549-500-000

$5299
Pentair GloBrite to MicroBrite Niche Adapter, 618040
Pentair

GloBrite to MicroBrite Niche Adapter, 618040

$2799
J&J Electronics PureWhite Pro LED Spa Lamp, 120V Cool White Equivalent to 100W, LPL-M2-CW-120, 46710
J&J Electronics

PureWhite Pro LED Spa Lamp, 120V Cool White Equivalent to 100W, LPL-M2-CW-120, 46710

$6699
Blue Square Vivid 360 Warm White LED Spa Bulb 12V 20W, VLB2500-WW
Blue Square

Vivid 360 Warm White LED Spa Bulb 12V 20W, VLB2500-WW

$7199
FX Luminaire SP 20W LED Path Light, Copper, 12 in Riser, SPLED20W12RCU
FX Luminaire

SP 20W LED Path Light, Copper, 12 in Riser, SPLED20W12RCU

$14599
Subtotal

Similar products

Other products people compare with this one.

Pentair Amerlite EC-602128 500W 120V inground pool light with stainless steel facering Pentair Amerlite Pool Light for Inground Pools with Stainless Steel Facering, 500W 120V 50' Cord, EC-602128$43900 Web Price J&J Electronics 25014P VU Retro-P RGBW nicheless LED pool light with 100 ft cord J&J Electronics VU Retro-P Replacement Nicheless LED Color RGBW Pool Light, 100' Cord, 25014P$49599 S.R. Smith Treo FLED-C-TR LED pool light dimensions drawing S.R. Smith Treo 5W LED Color Changing RGB Light, 80' Cord, FLED-C-TR$39199 Hayward AstroLite W3SP0583L100 500W 120V underwater pool light with 100 ft cord and plastic trim ring Hayward AstroLite Series, 500W/120V, 100 Ft Cord, Plastic Trim Ring, W3SP0583L100$50900 S.R. Smith Treo FLED-C-TR-30 RGB LED pool light with 30 ft cord S.R. Smith RGB Treo LED Pool Light 12V, 30' Cord, FLED-C-TR-30$33099 Pentair MicroBrite Color LED pool and spa light 620426 with 150 ft cord, 12V 14W Pentair MicroBrite Color LED Light with 150' Cord, 12V 14W, 620426$56299 Pentair 602183 IntelliBrite Architectural Series white LED pool light Pentair IntelliBrite Architectural Series White LED Pool Light Fixture, 120V 300W Equivalent 100' Cord, 602183$86999 Pentair 620424 MicroBrite Color LED pool light, 12V 14W with 50 ft cord Pentair MicroBrite Color LED Light with 50 ft Cord, 12V 14W, 620424$46099 J&J Electronics 25022 incandescent inground pool light fixture, 500W 120V with 100 ft cord J&J Electronics Incandescent Inground Pool Light Fixture, 500W 120V 100' Cord, TPL-P120-500-100, 25022$35299 J&J Electronics 21075 PureWhite LED pool light, 120V cool white, 500W with 100 ft cord J&J Electronics PureWhite LED Pool Light HI Series, 120V Cool White, 500W 100 ft Cord, LPL-F3W-120-100-P, 21075$74499
J&J Electronics 21101 PureWhite LED spa light, 120V cool white, with 100 ft cord J&J Electronics PureWhite LED Spa Light, 120V Cool White, 100W Equivalent, 100' Cord, LPL-S1W-120-100-P, 21101$58699 Hayward W3LACUS11100 ColorLogic 320 LED accent light with 100 ft cord Hayward ColorLogic 320 LED Accent Light 12V, 100 ft Cord, W3LACUS11100$62900 Web Price Blue Square VLPP3030-P Vivid 360 multi-color LED pool light with plug kit, 12V 30W Blue Square Multi-Color Vivid 360 Pentair LED Pool Light with Plug Kit 12V 30W, VLPP3030-P$79199 Pentair MicroBrite warm white LED pool light with 100 ft cord Pentair MicroBrite Color and White LED Pool Light, Warm White, 100 ft Cord, EC-620457$52900 Web Price Pentair EC-602230 white LED spa light, IntelliBrite Architectural Series, 120V with 100 ft cord Pentair 100' 120V White Spa IntelliBrite Architectural Series Light, EC-602230$87900 Web Price J&J Electronics PureWhite LED pool light, SwimQuip series, 120V with 50 ft cord J&J Electronics PureWhite LED Pool Light SwimQuip Series, 120V Cool White 500W 50' Cord, LPL-F3W-120-50-PSQ, 21053$73899 J&J Electronics 25013 ColorSplash VU nicheless RGB-W LED pool and spa light J&J Electronics ColorSplash VU Nicheless RGB-W Series LED Pool and Spa Light Fixture, 20W 12V 50' Cord, LPL-R2CW-12-50, 25013$38099 Pentair MicroBrite EC-620429 white LED pool and spa light with 100 foot cord Pentair MicroBrite White Pool and Spa LED Light, 12V 100' Cord, EC-620429$48900 Web Price Pentair EC-602224 IntelliBrite Architectural Series warm white spa light Pentair 100' 120V Warm White Spa IntelliBrite Architectural Series Light, EC-602224$82899 PAL Lighting Evenglow 64-EGN-80 multi-color nicheless LED pool and spa light PAL Lighting Evenglow Multi-Color Nicheless LED Pool and Spa Light, 7W 12V 80' Cord with Plug, 64-EGN-80$38499

From Pentair

Your trusted source for all things pool. Pentair

Pentair equipment

Pentair SuperFlo VS 1.5 HP Variable Speed Pool Pump, EC-342001 Pentair MasterTemp 400 Natural Gas Pool Heater, EC-462028 Pentair Clean & Clear Plus 420 sq ft Cartridge Pool Filter, EC-160301 Pentair IntelliConnect Control & Monitoring System with Wi-Fi, EC-523317
Shop Pentair equipment

Genuine Pentair parts

Pentair Genuine OEM Seal Kit for WhisperFlo and IntelliFlo Pool Pumps, 356198 Pentair Genuine OEM High Flow Manual Air Relief Valve, 98209800 Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400 Pentair Genuine OEM MasterTemp/Max-E-Therm 6-Button Control Board Kit, 461105Z
Shop Pentair parts
Pool lighting: a backyard pool and spa lit in blue and green at nightPool water treatment: three people floating on rings in clear blue water, seen from abovePool cleaners: a toddler in flower sunglasses laughing in a yellow ring, held by her mother
Pentair makes pumps, filters, heaters, salt chlorinators, cleaners, lighting and automation for pools and spas.Shop all Pentair

Product details

The Pentair MicroBrite Color is a compact 12 volt LED light for pools and spas, supplied here with a 100 ft cord. It delivers color changing light with even coverage from a fixture just 3.5 in. long, and it mounts in a standard 1.5 in. pool wall fitting, so there is no niche to set and no large housing to work around.

Light where a niche will not fit

Because it needs only a wall fitting, the MicroBrite goes into places a conventional pool light cannot: step risers, sun shelves, swim outs and water features. Pentair rates it for water as shallow as 4 in., which covers most tanning ledges. On a new build that means lighting can be planned into the details of the shell rather than limited to the main wall.

Retrofit and efficiency

For an existing pool with older incandescent or fiber optic lighting, the MicroBrite is a clean upgrade path. It draws 14 watts at 12 volts and is rated for about 10 times the life of an incandescent lamp, so running cost and lamp changes both drop.

Before you order

This is a 12 volt light and needs a 12 volt transformer. Check the conduit run from the fitting to the junction box; this version carries a 100 ft cord, and Pentair also makes the EC-620457 MicroBrite in warm white with the same cord length if you want fixed white output alongside the color units.

Specifications
Brand Pentair
Manufacturer part number EC-620425
UPC 788379887483
Type MicroBrite Color LED pool and spa light
Voltage 12 volt
Wattage 14 watt
Cord length 100 ft
Light length 3.5 in.
Mounting Standard 1.5 in. pool wall fitting, no niche required
Minimum water depth 4 in.
Rated life About 10 times an incandescent light
Companion light EC-620457 MicroBrite Warm White, 12 volt, 100 ft cord
Shipping weight 6.4 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Pentair

Pentair SuperFlo VS EC-342001 1.5 HP variable speed pool pump, front view Pentair SuperFlo VS 1.5 HP Variable Speed Pool Pump, EC-342001$1,48900 Pentair SuperFlo EC-348190 single speed pool pump, 1 HP, 115/230V Pentair SuperFlo 1 HP Single Speed Pool Pump, 115/230V, EC-348190$74800 Pentair WhisperFlo VS EC-011533 2.6 THP variable speed pool pump, top view Pentair WhisperFlo VS 2.6 THP Variable Speed Pool Pump, 115/208-230V, EC-011533$1,79900 Pentair 262506 HiFlow 1.5 in. six way clamp style multiport valve Pentair Genuine OEM HiFlow Valve 1.5 in. 6-Way Clamp Style, 262506$20999 Pentair EC-520556 IntelliChlor 110/220V power center Pentair 110/220V IntelliChlor Salt Chlorine Generator Power Center, EC-520556$79900 Web Price Pentair 523769 IntelliChlor Plus and LT replacement sensor board Pentair IntelliChlor Plus and LT Replacement Sensor Board, 523769$40499 Pentair 350305S 3.2 kW 10 pole variable speed motor for IntelliFloXF and IntelliFlo 2 VST pumps Pentair 3.2 kW IntelliFloXF VSF, VSF, VS+SVRS, i1, i2 Motor, 350305S$78199 Pentair 523735-EC IntelliChlor Plus40 salt chlorine generator cell Pentair IntelliChlor Plus40 Salt Chlorine Generator Replacement Cell, 40,000 Gallons, 523735-EC$1,81900 Web Price Pentair Rainbow 320 in-line chlorinator R171096, front view Pentair Rainbow 320 In-Line Chlorinator, R171096$14999 Pentair 190003 tank clamp kit with tension control for Clean and Clear Plus, FNS Plus and Quad DE filters Pentair Genuine OEM Clamp Kit with Tension Control, 190003$31099
Pentair IntelliChlor LT25 salt chlorine generator cell 523747-EC Pentair IntelliChlor LT25 Salt Chlorine Generator Cell, 25,000 Gallons, 523747-EC$1,15699 Pentair IntelliFlo VS+SVRS variable speed pool pump, EC-011057 Pentair IntelliFlo VS+SVRS Variable Speed Pool Pump, EC-011057$2,39900 Pentair 170145 cartridge pack for Sta-Rite System 3 S7M120, inner and outer cartridges Sta-Rite 170145 System 3 S7M120 Large and Small Cartridge Set, 25021-0200S and 25022-0201S$47999 Pentair 261055 SM-20-3 2 in. side mount multiport valve kit, front view Pentair 2 in. Multiport Valve Kit for Side Mount Sand Filters, SM-20-3, 261055$30899 Pentair 523770 IntelliChlor Plus replacement controller (HMI), black Pentair IntelliChlor Plus Controller Replacement (HMI), Black, 523770$39599 Pentair 261152 SM20-2 2 in. side mount multiport valve kit for DE filters Pentair 2" Valve Kit Multiport, Side Mount DE Filters SM20-2, 261152$30799 Pentair 357149 WhisperFlo and IntelliFlo volute housing replacement kit, front view Pentair WhisperFlo and IntelliFlo Volute Housing Replacement Kit, 357149$29699 Pentair 59023400 FNS Plus 48 sq ft complete DE grid assembly Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400$40599 Pentair Amerlite EC-602128 500W 120V inground pool light with stainless steel facering Pentair Amerlite Pool Light for Inground Pools with Stainless Steel Facering, 500W 120V 50' Cord, EC-602128$43900 Web Price Pentair 98209800 high flow manual air relief valve assembly with pressure gauge Pentair Genuine OEM High Flow Manual Air Relief Valve, 98209800$3999

Questions and answers

What people ask about this product, answered by our pool techs.

Do I need a light niche for this fixture?
No. The MicroBrite mounts in a standard 1.5 in. pool wall fitting, which is what makes it practical for steps, sun shelves, swim outs and water features where a full niche would not fit.
What voltage does it run on?
It is a 12 volt light drawing 14 watts. It needs a 12 volt transformer, such as the AMP-30-7013 12 to 14 volt 300 watt transformer, rather than a direct 120 volt feed.
How long is the cord?
This version ships with a 100 ft cord. Measure the conduit run from the wall fitting to the junction box before ordering so the cord reaches without a splice.
How shallow can it be installed?
Pentair rates it for water as shallow as 4 in., and the fixture itself is only 3.5 in. long, so it works in tanning ledges and step risers.
