Coates Temperature Control Thermostat TD103-77 CPH/PHS, 22002001 In stock$66⁹⁹

Coates 22002001 temperature control thermostat TD103-77 for CPH and PHS heaters

Coates Temperature Control Thermostat TD103-77 CPH/PHS, 22002001

Name: Coates Temperature Control Thermostat TD103-77 CPH/PHS, 22002001
Brand: Coates Heater
SKU: CHC-151-7580
Price: 66.99 USD
Availability: InStock

Ask a questionMPN 22002001

$66⁹⁹

In stock

Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

Genuine Coates part The factory temperature control thermostat, Coates part number 22002001.
Broad model coverage Used on all SHB Coates heaters and on the CE, CPH, PHS and 6ILS models.
Serial number matters On SHA and ST models it covers serial number 16140 and higher, so read the data plate before you order.
Switch detail Single pole, single throw, with two electrical hook ups, one of which carries two spade connectors.
Bulb and capillary A 5/16 in sensing bulb on a 12 in rubber coated capillary.
What it controls The thermostat decides when the heater fires and when it stops, so a failed one leaves the water cold or running past setpoint.
