Century 610807-007 start capacitor, 189/227 MFD at 125 VACCentury Start Capacitor, 189/227 MFD, 125 VAC, 1-7/16" x 2-3/4", 610807-007 In stock$1699
Century 610807-007 start capacitor, 189/227 MFD at 125 VAC
Shop all Century Motors

Century Start Capacitor, 189/227 MFD, 125 VAC, 1-7/16" x 2-3/4", 610807-007

Ask a questionMPN 610807-007
$1699
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • 189/227 MFD The capacitance range stamped on the can, at 125 volts AC.
  • Start duty, not run duty A start capacitor works only during the first moment of startup, and it is a different part from a run capacitor.
  • Sized 1-7/16 x 2-3/4 inches Measure the old can before ordering, since capacitors are as much about fitting the housing as matching the rating.
  • Century part 610807-007 The factory replacement capacitor.
  • Common failure point A motor that hums but will not spin up is usually the start capacitor rather than the motor itself.
  • Cheapest fix on the pad Replacing the capacitor costs a fraction of replacing the motor, so it is always worth ruling out first.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Century Start Capacitor, 189/227 MFD, 125 VAC, 1-7/16" x 2-3/4", 610807-007, SKU AOS-601-7883. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Century Start Capacitor, 189/227 MFD, 125 VAC, 1-7/16" x 2-3/4", 610807-007
Century Motors

Century Start Capacitor, 189/227 MFD, 125 VAC, 1-7/16" x 2-3/4", 610807-007

$1699
Century 1-1/2 HP 3450 RPM 56Y Frame Square Flange Pool Pump Motor, 115/230V, B2854V1
Century Motors

Century 1-1/2 HP 3450 RPM 56Y Frame Square Flange Pool Pump Motor, 115/230V, B2854V1

$33999
Century VGreen Evo Variable Speed 1.65 THP Square Flange Pool Pump Motor, 230/115 V, 48Y Frame, EVQ165
Century Motors

Century VGreen Evo Variable Speed 1.65 THP Square Flange Pool Pump Motor, 230/115 V, 48Y Frame, EVQ165

$61999
Century 56Y Frame ODP Square Flange Pool & Spa Pump Motor 2HP 230V, B2855
Century Motors

Century 56Y Frame ODP Square Flange Pool & Spa Pump Motor 2HP 230V, B2855

$41199
Century 1.65 HP Square Flange Pool and Spa Pump Motor, 3450 RPM 48Y, Threaded Shaft, HSQ165
Century Motors

Century 1.65 HP Square Flange Pool and Spa Pump Motor, 3450 RPM 48Y, Threaded Shaft, HSQ165

$33999
Century 1 HP Square Flange Pool Pump Motor, 1 Phase, 60 Hz, 230/115 V, 3450 RPM, 56Y Frame, B2853V1
Century Motors

Century 1 HP Square Flange Pool Pump Motor, 1 Phase, 60 Hz, 230/115 V, 3450 RPM, 56Y Frame, B2853V1

$31999
Century 1 HP Pump Motor, 230/115 Volt, 3450 RPM, Round Flange, 56J Frame, ODP, UST1102
Century Motors

Century 1 HP Pump Motor, 230/115 Volt, 3450 RPM, Round Flange, 56J Frame, ODP, UST1102

$28799
Subtotal

Similar products

Other products people compare with this one.

Century motor capacitor rated 161-193 MFD at 125V, BC161 Century Motor Capacitor 161-193 MFD 125V, 11914$1699 SuperPro 11914 start capacitor, 161/192 MFD at 125V SuperPro 125V Start Capacitor, 161/192 MFD, 11914$1599 Century 626531 terminal board for UST and USQ series motors Century Terminal Board for UST/USQ Series Motors, 626531$1199 Aladdin 6203-625 pool pump motor bearing with a 15.9 mm, 5/8 inch bore Aladdin Bearing #203-625, 15.9 mm (5/8"), 6203-625$1099 Century 628318-308 run capacitor, 30 MFD 370 VAC, for pool pump motors Century Run Capacitor, 30 MFD, 370 VAC, 1-3/4" x 2-7/8", 628318-308$5699 Century 628318-307 capacitor rated 25 MFD at 370 volts Century Capacitor 25 MFD 370V, 628318-307$3099 U.S. Seal RD-25-370 round run capacitor, 25 MFD 370V U.S. Seal Run Capacitor 25 MFD 370V Round, RD-25-370$2699 U.S. Seal 30 MFD 370 VAC run capacitor for pool pump motors U.S. Seal Run Capacitor, 30 MFD, 370vac, 5VR0303$2999 SuperPro 12717 round run capacitor, 30 MFD 370V SuperPro 30 MFD 370V Round Run Capacitor, 12717$3399 U.S. Seal RD-50-370 run capacitor, 50 MFD 370 volts U.S. Seal Run Capacitor 50 MFD 370V, RD-50-370$4099
SuperPro 12725 round run capacitor rated 50 MFD 370V SuperPro 50 MFD 370V Round Run Capacitor, 12725$4599 Century 629002-001 stationary single speed starter switch for A.O. Smith pump motors Century Stationary Single Speed Switch, 629002-001$3599 Century motor switch assembly for BN frame pool and spa motors Century OEM Motor Switch Assembly, 1576815$4999 Century 2517501-002 V-Green 270 automation adapter kit in black Century V-Green 270 Automation Adapter Kit, Black 2517501-002$16499 Century BN24V1 up rated 0.75 HP pool pump motor, 115v, 48Y frame Century Motor, Up Rated, .75 HP, 115v, Flex 48, BN24V1$21299 Century UST1072 up rated .75 HP pool pump motor, 115/230 V, 56J frame, front view Century Pump Motor, Up Rated, .75 HP, 3450 RPM, 115/230 V, 56J, Threaded Shaft, UST1072$25499 Century USQ1072 square flange 3/4 HP up-rate pool pump motor, 115/230V Century Square Flange Up-Rate Motor .75HP 115/230V USQ1072$26599 Century B227SE 3/4 HP 56J frame threaded shaft pool pump motor Century 56J Threaded UR .75 HP 115/230V Pool Pump Motor, B227SE$26999 Century Centurion Pro HSQ095 square flange pool pump motor, 0.95 THP 48Y Century Centurion Pro Square Flange Motor, 0.95 THP, 3450 RPM, 115/230 V, 48Y, Threaded Shaft, HSQ095$27499 Century B2846 square flange full rated pool and spa pump motor, 0.5 HP Century B2846 Square Flange Full Rated Pool and Spa Pump Motor, 0.5 HP$27599

Product details

Century 610807-007 is a motor start capacitor rated 189/227 MFD at 125 volts AC, in a can measuring 1-7/16 inches by 2-3/4 inches.

What a start capacitor does

Single phase motors cannot start turning on their own. The start capacitor gives the motor the phase shift it needs to break away from a standstill, then drops out of the circuit almost immediately. Because it lives a hard and brief electrical life on every start, it is one of the first components on a pool pump motor to fail.

Before you order

Match two things: the rating printed on the old can and its physical size, since the replacement has to fit under the same cover. Kill the power at the breaker before opening the motor, and treat a removed capacitor as still charged until you have discharged it.

Specifications
Brand Century
Manufacturer part number 610807-007
Type Start capacitor
Capacitance 189/227 MFD
Voltage 125 VAC
Dimensions 1-7/16" x 2-3/4"
Shipping weight 0.15 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

Questions and answers

What people ask about this product, answered by our pool techs.

What does 189/227 MFD mean?
It is the capacitance range of the unit, printed as a spread rather than a single number, which is normal for start capacitors.
Is this a start capacitor or a run capacitor?
Start. It is only in circuit for the instant the motor spins up. Run capacitors stay in circuit and are a different part.
What size is the can?
1-7/16 inches by 2-3/4 inches. Check yours against that before ordering, because the capacitor has to sit inside the existing cover.
My pump hums but will not start. Is this the part?
That symptom points at the start capacitor more often than anything else. Confirm the rating and can size on your old one match before ordering, and have the power off at the breaker before you open the motor.
