Jacuzzi Diffuser 3/4-1HP FR/1.5HP UR In stock$37⁹⁹

Jacuzzi 06016703R pump diffuser for 3/4 to 1 HP full rated and 1.5 HP up rated pumps

Jacuzzi Diffuser 3/4-1HP FR/1.5HP UR

Name: Jacuzzi Diffuser 3/4-1HP FR/1.5HP UR
Brand: Optimus Pool Products L.l.c.
SKU: JAC-101-9002
Price: 37.99 USD
Availability: InStock

Ask a questionAPS # JAC-101-9002

In stock

$37⁹⁹

Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

Horsepower specific Made for 3/4 to 1 HP full rated pumps and 1.5 HP up rated pumps, so match your motor before ordering.
Magnum family Listed with the Jacuzzi Magnum, Magnum Plus, Force and Force 3 pumps.
Directs flow into the impeller The diffuser is what converts the impeller discharge into usable pressure and holds the seal plate geometry.
Genuine Jacuzzi Part 06016703R.
Check it during a seal job The diffuser is exposed every time the pump is opened for a shaft seal, and a cracked one is easy to miss.
Wear costs you flow A worn or broken diffuser drops pump performance even when the impeller and motor are fine.

Full description and specifications ↓
