Praher TM-12-L 1-1/2 inch 6-way multiport backwash valvePraher 1-1/2" 6-Way Multiport Valve, TM-12-L In stock$14099
Praher TM-12-L 1-1/2 inch 6-way multiport backwash valve
Shop all Praher

Praher 1-1/2" 6-Way Multiport Valve, TM-12-L

Ask a questionMPN TM-12-L
$14099
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Six way multiport Six port positions on one valve body, selected by the handle.
  • Praher built Praher makes the valve as the replacement for the original on the filters it serves.
  • 1-1/2 inch Sized for 1-1/2 inch plumbing.
  • Sta-Rite Cristal-Flo This is the backwash valve for the Cristal-Flo sand filter.
  • Fits well beyond Sta-Rite Also used on the Baker Hydro III, Cooper and Millenium, W Cooper Ranger RS series, Waterway Smartclean and the Speck Aquaswim AS-250.
  • Stops the leak past the ports A worn multiport passes water between positions, which sends dirty water back to the pool during backwash.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Praher 1-1/2" 6-Way Multiport Valve, TM-12-L, SKU PRA-06-212. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Praher 1-1/2" 6-Way Multiport Valve, TM-12-L
Praher

1-1/2" 6-Way Multiport Valve, TM-12-L

$14099
Praher Key Hub Assembly 2" White, E-50-S2
Praher

Key Hub Assembly 2" White, E-50-S2

$8399
Praher Valve, 2" Multiport Kit, SM2-PP3
Praher

Valve, 2" Multiport Kit, SM2-PP3

$33699
Praher 2" ABS Clamp-Down Top Mount Multiport Valve for Sand or DE Filter, TM-22-PB
Praher

2" ABS Clamp-Down Top Mount Multiport Valve for Sand or DE Filter, TM-22-PB

$17899
Pentair 2" Spider Gasket, E-12-S2
Praher

Pentair 2" Spider Gasket, E-12-S2

$1799
Waterway 2" Top Mount Valve Clamp TM-22-L
Praher

Waterway 2" Top Mount Valve Clamp TM-22-L

$17699
Praher ABS Clamp-Down Top Mount Multiport Valve for 1-1/2 in. Triton Filters, TM-12-CFC
Praher

ABS Clamp-Down Top Mount Multiport Valve for 1-1/2 in. Triton Filters, TM-12-CFC

$11199
Subtotal

Similar products

Other products people compare with this one.

Hayward SP0714T Vari-Flo XL 1.5 in. top mount multiport valve kit, front view Hayward SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit$15899 Pentair 262506 HiFlow 1.5 in. six way clamp style multiport valve Pentair Genuine OEM HiFlow Valve 1.5 in. 6-Way Clamp Style, 262506$20399 Hayward SP0710X62 Vari-Flo 1.5 in. side mount multiport valve for Pro Series sand filters Hayward® Vari-Flo 1.5" Side Mount Multiport Valve for Sand Filters, SP0710X62$18899 CMP 27515-154-000 multiport valve, replacement for Hayward Vari-Flo SP0714T CMP Generic Multiport Valve Replacement for Hayward Vari-Flo SP0714T, 27515-154-000$13199 Waterway WVS003 1-1/2 in. top mount multiport valve for 2002 and later sand filters Waterway 1-1/2" Top Mount Multiport Valve (2002 & After), WVS003$11499 Pentair 272422 valve top assembly for 2 in. Hi-Flow valve Pentair Valve Top Assembly 2", 272422$20899 Hayward SP0710XALL Vari-Flo XL 1.5 inch multiport valve kit Hayward Vari-Flo XL Multi-Port Valve Kit 1.5", SP0710XALL$16699 Hayward SP0410X602S 2 inch push pull slide valve kit Hayward 2" Push Pull Slide Valve Kit, SP0410X602S$14799 CMP 27502-154-000 top mount multiport valve for Pentair sand filters CMP Top Mount Multi-Port Valve 1.5" FPT Clamp Style for Pentair Sand Filters 262506, 27502-154-000$12799 Jacuzzi DVK-6 dial valve kit, bolt on style, part 39258800R Jacuzzi DVK-6 Dial Valve Kit, Bolt On Style, 39258800R$15799
Pentair 263085 2 in. TA Tagelus clamp style backwash multiport valve without union Pentair 2 in. TA Tagelus Clamp Style Backwash Multiport Valve without Union, 263085$24999 Hayward SPX0710X32 Vari-Flo 1.5 in. side mount multiport valve for S200 and S240 sand filters Hayward Vari-Flo 1.5 in. Multiport Valve (S200 and S240), SPX0710X32$27299 Sta-Rite 14971-TM-22-L 2 inch multiport valve kit for T-240BP and T-300BP sand filters Sta-Rite 2" Multiport Valve Kit for T-240BP and T-300BP, 14971-TM-22-L$34599 Pentair 262525 two inch top mount multiport valve with unions for sand filters Pentair 2" FPT Top Mount TA60 SD80 Multiport Valve with Unions, 262525$36499 Hayward SPX0715X32 2 inch Vari-Flo multiport control valve assembly Hayward 2" Multiport Valve, SPX0715X32$39599 Waterco 2290820 3 inch sand filter multiport valve with plumbing Waterco 3" Sand Filter Multiport Valve with Plumbing, 2290820$50599 Pentair 263052 push pull valve with 8 inch center spacing and 2 inch unions Pentair Push Pull Valve 8" Center, 263052$21799 Hayward SP071621 2 in. Vari-Flo top mount multiport valve, front view Hayward 2" Vari-Flo Top Mount Valve, SP071621$22899 Jandy 8034 Neverlube 2-in-1 backwash valve Jandy Neverlube Backwash Valve, 2-in-1, 8034$23599 Hayward SP071620T 2 in. top mount backwash valve with clamp for Pro Series S310T and S310T2 Hayward 2" Top Mount Backwash Valve with Clamp, Fits Pro Series Sand Filters S310T / S310T2, SP071620T$25399

Product details

The Praher TM-12-L is a 1-1/2 inch six way multiport valve. It is the backwash valve for the Sta-Rite Cristal-Flo sand filter, and it turns up on a long list of other filters besides.

What the valve does

Everything a sand filter can do, it does through the multiport. The handle picks the port position and the valve sends water where that position calls for. When the internals wear, water starts passing between positions instead of following the one you selected, and the usual symptom is dirty water going back to the pool during a backwash.

What it fits

Beyond the Sta-Rite Cristal-Flo, the same valve is used on the Baker Hydro III, Cooper and Millenium sand filter, the W Cooper Ranger RS Series sand filters, the Waterway Smartclean sand filter and the Speck Aquaswim AS-250. Match the valve size at your filter first: this is the 1-1/2 inch version.

Before you order

The clamp assembly and its o-ring are a separate Praher part. If the old clamp has been on the filter for years it is worth replacing at the same time, since it is the piece holding the new valve to the tank.

Specifications
Brand Praher
Manufacturer part number TM-12-L
Type 6-way multiport valve
Function Backwash valve
Size 1-1/2 inch
Fits Sta-Rite Cristal-Flo
Also fits Baker Hydro III/ Cooper & Millenium sand filter, W Cooper Ranger RS Series sand filters, Waterway Smartclean sand filter, Speck Aquaswim AS-250
Shipping weight 2 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Praher

Praher E-50-S2 key hub assembly, 2 inch, white Praher Key Hub Assembly 2" White, E-50-S2$8399 Praher 200-010 2 inch single union ball valve, socket by socket Praher 2" Single Union Blocked Ball Valve Skt/Skt, 200-010$3799 Praher SM2-PP3 2 inch side mount multiport valve kit for Pac-Fab Triton sand filters Praher Valve, 2" Multiport Kit, SM2-PP3$33699 Praher OV3-1500U 1-1/2 inch 3 port valve with unions Praher 3 Port Valve, 1-1/2" with Union, OV3-1500U$5499 Praher TM-22-PB 2 inch ABS clamp-down top mount multiport valve Praher 2" ABS Clamp-Down Top Mount Multiport Valve for Sand or DE Filter, TM-22-PB$17899 Praher 150-100 1-1/2 inch white slip by slip union Praher 1-1/2" Slip by Slip Union, 150-100$1399 Praher 200-903 two inch slip by male pipe thread PVC union Praher 2" Slip x MIP Union, 200-903$1599 Pentair E-12-S2 2 inch spider gasket for multiport valves Pentair 2" Spider Gasket, E-12-S2$1799 Praher OV2-2010 two port CPVC slip socket valve Praher 2" x 2.5" 2-Port CPVC Valve, OV2-2010$7099 Waterway TM-22-L clamp for 2 inch top mount sand filter valve Waterway 2" Top Mount Valve Clamp TM-22-L$17699
Praher E-50-S1 key cover assembly, 1-1/2 inch, white Praher Key Cover Assembly 1-1/2 Inch, White, E-50-S1$7999 Pentair 12L-CLP clamp assembly with o-ring Pentair 12L-CLP Clamp Assembly with O-ring$2799 Praher 200-100 2 inch slip by slip PVC union Praher 2" S x S Union, 200-100$1399 Praher TM-12-CFC ABS clamp-down top mount multiport valve for Pentair Triton filters Praher ABS Clamp-Down Top Mount Multiport Valve for 1-1/2 in. Triton Filters, TM-12-CFC$11199 Praher SM1-HP2 ABS pre-plumbed side mount multiport valve for DE filters Praher ABS Pre-Plumbed Side Mount Multiport Valve for DE Filters, 1-1/2 in. FIP, SM1-HP2$10999

Questions and answers

What people ask about this product, answered by our pool techs.

What size plumbing does this valve take?
1-1/2 inch. It is the 1-1/2 inch six way multiport, so check the pipe size at your filter before ordering.
Which filters does it fit?
The Sta-Rite Cristal-Flo, and it is also used on the Baker Hydro III, Cooper and Millenium sand filter, W Cooper Ranger RS Series sand filters, the Waterway Smartclean sand filter and the Speck Aquaswim AS-250.
Is the clamp and o-ring included?
No. The 12L-CLP clamp assembly with o-ring is a separate Praher part, so order it alongside the valve if the old clamp or its o-ring is worn.
Is this an original valve or an aftermarket one?
Praher makes it as the replacement backwash valve for the filters listed, so it is the part those filters were built around.
