Waterway WVS003 1-1/2 in. top mount multiport valve for 2002 and later sand filtersWaterway 1-1/2" Top Mount Multiport Valve (2002 & After), WVS003 In stock$11799
Waterway WVS003 1-1/2 in. top mount multiport valve for 2002 and later sand filters
Shop all Waterway

Waterway 1-1/2" Top Mount Multiport Valve (2002 & After), WVS003

Ask a questionMPN WVS003
$11799
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Seven positions Full function top mount backwash valve for Waterway sand filters.
  • 1-1/2 in. ports Matches the 1.5 in. plumbing on these filters.
  • 2002 and after For filters built from 2002 on. Earlier filters take a different valve kit.
  • Fits the Waterway range TWM, Clearwater, Carefree and Baquapure sand filters.
  • Also sold under other names Rec Warehouse 4742-010, Baquapure 111960, Premium Blue, Cyclone, Sparko, Eco Kleer, Aquastar Blue Star and Aqua Coastal.
  • Wrench not included The 505-1970 removal wrench is sold separately.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Waterway 1-1/2" Top Mount Multiport Valve (2002 & After), WVS003, SKU WWP-06-408. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Waterway 1-1/2" Top Mount Multiport Valve (2002 & After), WVS003
Waterway

1-1/2" Top Mount Multiport Valve (2002 & After), WVS003

$11799
Waterway Lock Ring, Pro Clean Plus, 550-0701B
Waterway

Lock Ring, Pro Clean Plus, 550-0701B

$9299
Waterway Tank Body, Crystal Water, Gray, with Label, 550-4407
Waterway

Tank Body, Crystal Water, Gray, with Label, 550-4407

$43537
Waterway Crystal Water Tank O-Ring, 805-0000
Waterway

Crystal Water Tank O-Ring, 805-0000

$3399
Waterway Filter Collar Valve Wrench, 505-1970
Waterway

Filter Collar Valve Wrench, 505-1970

$1999
Waterway Tank Lid with Lock Ring, Pro Clean Plus 125/150 sq ft, 550-0621
Waterway

Tank Lid with Lock Ring, Pro Clean Plus 125/150 sq ft, 550-0621

$26299
Waterway Diverter Spider Gasket, 711-1910B
Waterway

Diverter Spider Gasket, 711-1910B

$2699
Subtotal

Similar products

Other products people compare with this one.

Hayward SP0714T Vari-Flo XL 1.5 in. top mount multiport valve kit, front view Hayward SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit$15899 Praher TM-12-CFC ABS clamp-down top mount multiport valve for Pentair Triton filters Praher ABS Clamp-Down Top Mount Multiport Valve for 1-1/2 in. Triton Filters, TM-12-CFC$11199 CMP 27502-154-000 top mount multiport valve for Pentair sand filters CMP Top Mount Multi-Port Valve 1.5" FPT Clamp Style for Pentair Sand Filters 262506, 27502-154-000$12799 CMP 27515-154-000 multiport valve, replacement for Hayward Vari-Flo SP0714T CMP Generic Multiport Valve Replacement for Hayward Vari-Flo SP0714T, 27515-154-000$13199 Praher TM-12-L 1-1/2 inch 6-way multiport backwash valve Praher 1-1/2" 6-Way Multiport Valve, TM-12-L$14099 Hayward SP0710XALL Vari-Flo XL 1.5 inch multiport valve kit Hayward Vari-Flo XL Multi-Port Valve Kit 1.5", SP0710XALL$16699 Hayward SP0410X602S 2 inch push pull slide valve kit Hayward 2" Push Pull Slide Valve Kit, SP0410X602S$14799 Jacuzzi DVK-6 dial valve kit, bolt on style, part 39258800R Jacuzzi DVK-6 Dial Valve Kit, Bolt On Style, 39258800R$15799 Pentair 262525 two inch top mount multiport valve with unions for sand filters Pentair 2" FPT Top Mount TA60 SD80 Multiport Valve with Unions, 262525$36499 Hayward SP0710X62 Vari-Flo 1.5 in. side mount multiport valve for Pro Series sand filters Hayward Vari-Flo 1.5" Side Mount Multiport Valve for Sand Filters, SP0710X62$19399
Hayward SP071621 2 in. Vari-Flo top mount multiport valve, front view Hayward 2" Vari-Flo Top Mount Valve, SP071621$22799 Hayward SP071620T 2 in. top mount backwash valve with clamp for Pro Series S310T and S310T2 Hayward 2" Top Mount Backwash Valve with Clamp, Fits Pro Series Sand Filters S310T / S310T2, SP071620T$26199 Pentair 261186 top-mount clamp style valve for 1-1/2 inch plumbing Pentair Valve 1-1/2" Top-Mount Clamp Style, 261186$27099 Pentair 261185 2 in. top mount clamp on multiport valve for Tagelus sand filters Pentair 2" Top Mount, Clamp on Complete Valve, 261185$33299 Jandy R0745700 2 in. top mount multiport valve with clamp for the SFTM24-2.0 sand filter Jandy 2 in. Top Mount Multi-Port Valve, R0745700$35799 Pentair 272422 valve top assembly for 2 in. Hi-Flow valve Pentair Valve Top Assembly 2", 272422$21599 Pentair 263085 2 in. TA Tagelus clamp style backwash multiport valve without union Pentair 2 in. TA Tagelus Clamp Style Backwash Multiport Valve without Union, 263085$25799 Hayward SPX0710X32 Vari-Flo 1.5 in. side mount multiport valve for S200 and S240 sand filters Hayward Vari-Flo 1.5 in. Multiport Valve (S200 and S240), SPX0710X32$28099 Praher SM2-PP3 2 inch side mount multiport valve kit for Pac-Fab Triton sand filters Praher Valve, 2" Multiport Kit, SM2-PP3$33699 Sta-Rite 14971-TM-22-L 2 inch multiport valve kit for T-240BP and T-300BP sand filters Sta-Rite 2" Multiport Valve Kit for T-240BP and T-300BP, 14971-TM-22-L$34599

Product details

The Waterway WVS003 is the seven position, 1-1/2 in. top mount multiport valve for Waterway sand filters built in 2002 and after. It is the backwash valve on the TWM, Clearwater, Carefree and Baquapure filters, and on the same filter sold under other names: Rec Warehouse 4742-010, Baquapure 111960, Premium Blue, Cyclone, Sparko, Eco Kleer, Aquastar Blue Star and Aqua Coastal.

Check the year

Waterway changed the valve in 2002. This one fits 2002 and later filters; a filter from 2001 or earlier takes a different valve kit. If you are not sure, look for the date on the tank before ordering.

Removal tool

The valve collar is meant to come off with the Waterway 505-1970 removal wrench, which is not included. Have it on hand before you start the swap.

Specifications
Brand Waterway
Manufacturer part number WVS003
UPC 806105186072
Type Top mount multiport valve
Port size 1-1/2 in.
Positions 7
Filter years 2002 and after
Fits Waterway TWM, Clearwater, Carefree, Baquapure sand filters; Rec Warehouse 4742-010; Baquapure 111960; Premium Blue, Cyclone, Sparko, Eco Kleer, Aquastar Blue Star, Aqua Coastal
Not included Removal wrench 505-1970
Shipping weight 7.5 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Waterway

A Waterway pump and filter on an equipment pad beside an infinity pool. Engineered for pool, spa and bath. Waterway

Waterway equipment

Waterway Power Defender Variable Speed Pump 1.65HP 230V, PD-165 Waterway 150 Sq. Ft. 1.5 HP 2 Speed Clearwater Cartridge Filter System, 522-5167-6S Waterway Complete Renegade Vinyl Skimmer, Wide Mouth, 9 in. Throat, White, 540-8500 Waterway 3/4 HP Booster Pump, SG3810430-1PDA
Shop Waterway equipment

Waterway parts

Waterway Renegade Pool Skimmer Basket, 542-3240 Waterway 6 in. Pump Trap Assembly, 2 in. x 2 in. Ports, 310-6600 Waterway Adjustable Spa Jet, Gunite, 210-3400 Waterway Poly Gunite Jet Assembly 1.5" x 2" Tee Body, 210-3700
Shop Waterway parts
Pool filters: a Waterway cartridge filter and pumpFittings and valves: a white Waterway PVC fitting
Waterway makes pumps, filters, skimmers, jets, valves and fittings for pools, spas and baths.Shop all Waterway

Customer reviews

More from Waterway

Waterway 550-4407 Crystal Water filter tank body, gray, with label Waterway Tank Body, Crystal Water, Gray, with Label, 550-4407$43537 Waterway 310-6600 6 in. pump trap assembly with 2 in. x 2 in. ports, front view Waterway 6 in. Pump Trap Assembly, 2 in. x 2 in. Ports, 310-6600$7399 Waterway 550-0701B lock ring for Pro Clean Plus 125 and 150 sq ft filters Waterway Lock Ring, Pro Clean Plus, 550-0701B$9299 Waterway 522-5167-6S ClearWater II 150 sq. ft. cartridge filter system with 1.5 HP Hi-Flo II two speed pump Waterway 150 Sq. Ft. 1.5 HP 2 Speed Clearwater Cartridge Filter System, 522-5167-6S$92799 Waterway ClearWater II 520-5147-6S 100 sq ft cartridge filter system with 1.5 HP pump Waterway 100 SqFt ClearWater II Cartridge Filter System for Above Ground Pool 1.5HP, 520-5147-6S$76899 Waterway 542-3240 Renegade pool skimmer basket Waterway Renegade Pool Skimmer Basket, 542-3240$2199 Waterway 210-3700 poly gunite jet assembly with 1.5 inch by 2 inch tee body Waterway Poly Gunite Jet Assembly 1.5" x 2" Tee Body, 210-3700$2299 Waterway 210-3400 adjustable gunite spa jet Waterway Adjustable Spa Jet, Gunite, 210-3400$3099 Waterway 550-0621 tank lid with lock ring and pressure gauge for Pro Clean Plus 125 and 150 sq ft filters Waterway Tank Lid with Lock Ring, Pro Clean Plus 125/150 sq ft, 550-0621$26299 Waterway 218-1447 gray wall fitting escutcheon for vinyl liner pool returns Waterway Wall Fitting Escutcheon, Gray, for In-Ground Vinyl Liner Return Fittings, 218-1447$699
Waterway 229-8127 thread-in 5-scallop twin roto Poly Storm gunite jet internal in gray Waterway Thread-in 5-Scallop Twin Roto Poly Storm Gunite Jet Internal, Gray, 229-8127$2099 Waterway 805-0000 Crystal Water filter tank o-ring Waterway Crystal Water Tank O-Ring, 805-0000$3399 Waterway 400-4030 1-1/2 inch union, male pipe thread by female slip Waterway 1-1/2" x 1-1/2" S Union MPT, 400-4030$1699 Waterway 540-8500 Renegade wide mouth vinyl liner skimmer, 9 in. throat, white Waterway Complete Renegade Vinyl Skimmer, Wide Mouth, 9 in. Throat, White, 540-8500$16799 Waterway 640-1900 V 10 inch Tru Flo cover and frame in white Waterway 10" Tru Flo Cover and Frame, White, 640-1900 V$3999 Waterway 505-1970 filter collar valve wrench for split-nut threaded sand filters Waterway Filter Collar Valve Wrench, 505-1970$1999 Waterway 210-6090 Roto Deluxe Jet in white Waterway Roto Deluxe Jet, White, 210-6090$3399 Waterway 600-9600 valve lid diverter assembly with spider gasket Waterway Lid Diverter Assembly with Gasket, 600-9600$9999 Waterway 400-5080 2 in. union, male pipe thread by female slip Waterway 2" Union, Male Pipe Thread by Female Slip, 400-5080$1899 Waterway 640-4740 V universal grate, 12 in. x 12 in., white Waterway Universal Grate, 12 in. x 12 in., White, 640-4740 V$6899

Questions and answers

What people ask about this product, answered by our pool techs.

Which filters does it fit?
Waterway top mount sand filters from 2002 on: the TWM, Clearwater, Carefree and Baquapure, along with the same filter sold as Rec Warehouse 4742-010, Baquapure 111960, Premium Blue, Cyclone, Sparko, Eco Kleer, Aquastar Blue Star and Aqua Coastal.
My filter is from 2001 or earlier. Will this work?
No. Filters built in 2001 and prior use a different top mount valve kit. Check the year on your filter before ordering.
Do I need a special tool?
The valve collar comes off with the Waterway 505-1970 removal wrench, which is not included with the valve.
How many positions does it have?
Seven.
Ask your own question
