Raypak Genuine OEM Bypass Valve Assembly Kit In stock$5699
Quick overview
- Genuine Raypak OEM Factory part number 016194F, supplied by Raypak Inc.
- Complete assembly kit Sold as the bypass valve assembly rather than as loose pieces.
- Valve type: bypass The internal valve that governs how much water routes through the heat exchanger.
- Why the bypass matters It balances flow so the exchanger sees the right volume, protecting it from both starvation and excess flow.
- Confirm the part number Raypak uses different bypass assemblies across its heater ranges, so match 016194F to your model parts list.
- Related heater controls Raypak also lists the pressure relief valve, the hi-limit control and the unitherm governor separately.
Similar products
Other products people compare with this one.
Product details
The Raypak 016194F is the genuine OEM bypass valve assembly kit for Raypak pool heaters, supplied by Raypak Inc. as a complete assembly rather than as loose components.
What the bypass valve does
Inside a Raypak heater, the bypass valve decides how much of the incoming water actually passes through the heat exchanger and how much goes around it. That balance is what keeps the exchanger working in its intended range across different pump speeds and plumbing setups. When the valve sticks, leaks or breaks, the heater loses that control, and the exchanger takes the consequences.
Before you order
Raypak uses different bypass assemblies across its heater ranges, and the available information does not list which models take this one. Check 016194F against the parts list for your heater. If the heater is old enough to need a bypass valve, it is worth looking at the pressure relief valve, the hi-limit control and the unitherm governor at the same time, all of which Raypak sells as separate parts.
| Brand | Raypak |
|---|---|
| Manufacturer part number | 016194F |
| UPC | 840891039266 |
| Type | Bypass valve assembly kit |
| Valve type | Bypass |
| Manufacturer | Raypak Inc. |
| Shipping weight | 0.3 lb |
| Ships | Parcel |
