Stenner Pumps Injection Check Valve with 3/8 Inch Ferrule, UCINJ38 In stock$3199
Stenner Pumps Injection Check Valve with 3/8 Inch Ferrule, UCINJ38
$3199
FREE Delivery
Typically ships within 0 days This item ships directly from the manufacturer.
In stock
30 day returns · Easy, with prepaid labels provided
Quick overview
- Stenner part UCINJ38 The injection check valve with the 3/8 inch ferrule.
- Broad pump coverage Listed for the 45, 85, 100 and 170 Series adjustable and fixed pumps, plus SVP and BDF Series pumps.
- 3/8 inch ferrule Match the ferrule size to your tubing, since Stenner builds this valve in more than one size.
- Stops backflow The check keeps line pressure and treated water from pushing back up the feed tubing.
- The injection point This is the fitting that puts chemical into the pipe, so it takes the worst of the chemical and the pressure.
- Wear item Scale and a tired spring or seat make it drip or stick, and it is meant to be replaced.
Need a hand?
Bilingual support from pool professionals.
Frequently bought together
Current item
Stenner
Pumps Injection Check Valve with 3/8 Inch Ferrule, UCINJ38
$3199
Subtotal
Similar products
Other products people compare with this one.
Rola-Chem Injection Check Valve, PVC, 1/4" NPT, 521170$4099
Pentair Chemical Feeder Injection Check Valve, 522513Z$3699
Pentair Rainbow 1/4" Tube x Tube Check Valve with Compression Nuts, R172323$2599
Pentair Chlorine Valve .25 in. Tube Control Valve with Compression Nut, R172060Z$3199
Hayward CL Series Pool Chemical Feeder Check Valve and Inlet Fitting Adapter Assembly, CLX220EA$2599
Pentair Rainbow 1/2" Tube x Tube Check Valve, Spring Style, R172324$3899
King Technology Cap with O-Ring for 5400, 5430 and 5450 XL Pro and Mineral Hybrid In Ground Feeders, 01-22-9417$3899
Hayward Cover Screw with Washer and Cap, CLX200EGA$1799
Pentair 1/2" Drain Valve for Rainbow Chlorinators, R175009$2399
Rola-Chem 8" Tygon Pinch Tube Assembly with Clamp for RC301 Peristaltic Pump, 523250$2399
Rola-Chem 7/16 in. Plastic Tube Injection Fitting for Pro Series 300 Pump, 527159$2799
Pentair R172264XL Old Style Saddle Clamp for 3, 4 and 6 Inch Commercial Chemical Feeder Pipe$2199
Hayward Control Knob Assembly with O-Rings, CLX200PA$2999
Pentair R172022 Old Style Chlorine Control Valve$3299
Rola-Chem Premium Flex Tube with Clamp 13.25 in., 523114$3099
Rola-Chem Flex Tube With Clamp 13.25" | 523115$2599
Stenner 20' x 1/4" ROLL SUCTION/DISCHARGE TUBING BLACK | AK4002B$1999
CMP Clear Glass PowerClean Chlorinator Cover, 25280-109-200$3399
Pentair Rainbow Lock Ring R172214$2899
Hayward Cover O-Ring for CL200 Chlorinator, CLX200K$3899
Product details
The Stenner UCINJ38 is the injection check valve with a 3/8 inch ferrule. Stenner lists it for the 45, 85, 100 and 170 Series adjustable and fixed pumps, and for the SVP and BDF Series pumps.
Where it sits
The injection check valve is the last piece in the feed line, threaded into the pipe where the chemical goes in. Two jobs: it delivers the dose into the flow, and its internal check stops pressurized water from travelling back up the tubing toward the pump when the pump is idle.
Why it wears out
Everything the pump feeds passes through this one fitting, so it takes the full strength of the chemical along with line pressure and, on hard water, scale. A valve that weeps at the pipe, will not hold a prime, or feels gritty when it seats has done its time. Match the ferrule size to your tubing before ordering, since the same valve is built in several sizes.
| Brand | Stenner Pumps |
|---|---|
| Manufacturer part number | UCINJ38 |
| UPC | 840034740844 |
| Type | Injection check valve |
| Ferrule size | 3/8 inch |
| Fits | 45, 85, 100 and 170 Series adjustable and fixed pumps; SVP and BDF Series pumps |
| Shipping weight | 0.1 lb |
| Ships | Parcel |
Request a quote
Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.
Customer reviews
Verified store reviews
SHOPPER APPROVED
See all reviews →
More from Stenner
Stenner Pumps 120V 50 GPD, 25 PSI 1/4 in. Adjustable 1-Head Classic Pump, 45MJL5A1STAA$48999
Stenner Pumps 1/4" Ferrule, 24 Pack, MCAK200$799
Stenner Pumps MCCVDB0 Check Valve Duckbill$1099
Stenner 45MFL5A1SUAA 120V 50 GPD 25 PSI .25" Fixed 1-Head Classic Pump$36099
Stenner Pumps QuickPro Roller Assembly for Classic, SVP and M128 Series Pumps, QP500-1$4799
Stenner Pumps MCDBINJ Injection Duckbill Check Valve with 1/4" Ferrule, 5 Pack$2499
Stenner Pumps Feed Rate Control with Shaft for Classic 45 and 85 Adjustable Pumps, FC5040D$31099
Stenner Pumps PMBRPL2 Rotor Assembly for 45, 85 and 170 Series Adjustable and Fixed Pumps$12999
Stenner Pumps Suction and Discharge Tubing, 1/4 in x 100 ft, White, AK4010W$7299
Stenner Pumps MCCP205 Pump Tube with 1/4 Inch Ferrule, #5 Santoprene$2499
Stenner Pumps #1 Santoprene Pump Tube with 1/4" Ferrules, 2 Pack, UCCP201$4599
Stenner Pumps Injection Check Valve with 1/4 Inch Ferrule, UCDBINJ$2699
Stenner Stennner Classic Series 170GPD 120V 1/4" W 170DMP5 Pump FXD 25PSI | 170FL5A1SUAA$55099
Stenner Classic Series 5GPD 120V 1/4" 85M1 Pump ADJ 25PSI | 85MJL1A1STAA$61899
Stenner Classic Series 50GPD 120V 3/8" 45M5 Pump ADJ 25PSI | 45MJL5A3STAA$50599
Stenner Classic Series 22GPD 120V 1/4" 45M3 Pump ADJ 25PSI | 45MJL3A1STAA$53099
Stenner Classic Series 85M5 Adjustable Chemical Feed Pump, 85 GPD, 25 PSI, 120V, 3/8 in. Tubing, 85MJL5A3STAA$50799
Stenner Classic Series 10GPD 120V 1/4" 45M2 Pump ADJ 25PSI | 45MJL2A1STAA$52099
Stenner Classic Series 85GPD 120V .25in 85M5 Pump | 85MJL5A1STAA$49599
Stenner Classic Series 3GPD 120V 1/4" 45M1 Pump ADJ 25PSI | 45MJL1A1STAA$53399
Questions and answers
What people ask about this product, answered by our pool techs.
Which Stenner pumps does this fit?
It is listed for the 45, 85, 100 and 170 Series adjustable and fixed pumps, and for the SVP and BDF Series pumps.
What size ferrule does it use?
3/8 inch. Check the tubing and ferrule on the pump you have, because the same valve is built in other sizes.
What does the injection check valve actually do?
It is the point where chemical enters the pipe, and its check keeps pressurized water from pushing back up the feed tubing when the pump is not running.
Why would I replace one?
A valve that drips, will not seat, or has scaled up stops metering cleanly. Since it sits directly in the chemical stream, it is treated as a service part.
