Jandy Stealth, PlusHP & FloPro Pump Parts

47 products

Read the whole model number off the pump before ordering an impeller, because the letter after SHP or PHP changes it. In Jandy's Stealth parts list an SHPF1.0 and an SHPM1.5 take the same R0807202 kit, as do an SHPF1.5 and an SHPM2.0. The FloPro and VS FloPro use their own body, lid and impellers, while the ePump is built on the Stealth's body, lid and backplate. Jandy lists the 5/8 inch R0479400 shaft seal for all of them.

Which Stealth do you have?

The model is on the label: SHPF is full rated and SHPM max rated, then the horsepower. A -2 after it, as in SHPF1.0-2, is the two speed, with the same impeller.

Jandy Stealth Pump exploded parts diagram with numbered keys123456789101112131415161718192021222324
Numbers are the manufacturer's own.

Motor and hardwareJandy by model, speed and phase

Jandy by model is not sold on Active yet.

Backplate kitJandy R0445200, R0445201

Jandy Back Plate Kit, R0445200

Jandy OEMWith hardware, o-ring and shaft seal

$18399 In stock

Impeller kitJandy R0807204, R0807203, R0807202, R0807201, R0807200, R0807205, R0807207, R0445302-06

Jandy .75 HP FR SHP/PHP Impeller Kit with Screw and O-Ring, R0807203

Jandy OEM

$6099 In stock
Jandy Impeller Kit for Stealth SHPF/SHPM and PlusHP PHPF/PHPM Pumps, R0807202

Jandy OEM

$6099 In stock
Jandy 1.5 HP FR SHP/PHP Impeller Kit with Screw and O-Ring, R0807201

Jandy OEM

$5999 In stock
Jandy SHP Stealth and PHP Impeller Kit, 2 HP Full Rated, R0807200

Jandy OEM

$5899 In stock
Jandy 3 HP SHP Impeller Kit with Screw and O-Ring, R0807205

Jandy OEM

$5899 In stock

DiffuserJandy R0445400, R0445401

Jandy 0.5 HP to 3 HP Diffuser with O-Ring and Hardware, R0445400

Jandy OEMWith o-ring and hardware

$7899 In stock

Shaft seal, carbon and ceramicJandy R0479400

Jandy Mechanical Seal, 5/8" ID, R0479400

Jandy OEM

$3499 In stock
SuperPro Jandy SHPF and SHPM Series Viton Seal Kit, GOKIT82V-9

KitSeal and gasket kit

$4999 In stock

Pump bodyJandy R0445601

Jandy Pump Body for Stealth SHPF/SHPM Pumps, R0445601

Jandy OEM

$38199 In stock

Motor mounting footJandy R0445700

Jandy R0445700 is not sold on Active yet.

Lid with locking ring and sealJandy R0445800

Jandy Lid & Locking Ring Assembly with O-Ring, R0445800

Jandy OEM

$11799 In stock

Pressure test o-ring, blueJandy R0479000

Jandy Blue Pressure O-Ring, R0479000

Jandy OEM

$2399 In stock

Debris basketJandy R0445900

Jandy R0445900 is not sold on Active yet.

Drain plug with o-ringJandy R0446000

Jandy Drain Plug with O-Ring (Set of 2), R0446000

Jandy OEMSet of two

$2099 In stock

Tail piece, o-ring and coupling nutJandy R0446101, R0446102

Jandy 2" x 2.5" Pump Unions, 0.75 HP to 2.5 HP, R0446101

Jandy OEM2 by 2-1/2 in., set of two

$5599 In stock
Jandy 2-1/2" Slip x 3" Spigot Pump Unions, 3 HP, R0446102

Jandy OEM2-1/2 by 3 in., set of two

$5699 In stock

Lid seal and lid o-ringJandy R0446200

Jandy Lid Seal, R0446200

Jandy OEM

$3299 In stock

Backplate o-ringJandy R0446300

Jandy O-Ring, Backplate, R0446300

Jandy OEM

$1899 In stock

Tail piece o-ringJandy R0446400

Jandy O-Ring, Tail Piece (Set of 2), R0446400

Jandy OEMSet of two

$1599 In stock

Diffuser and impeller hardwareJandy R0446500, R0446501

Jandy Diffuser and Impeller Hardware O-Ring Kit, R0446500

Jandy OEM

$3699 In stock

Backplate bolts and washersJandy R0446600

Jandy R0446600 is not sold on Active yet.

Motor bolts and washersJandy R0446700

Jandy R0446700 is not sold on Active yet.

Motor foot screwsJandy R0446800

Jandy R0446800 is not sold on Active yet.

Motor, 5 HP three phase TEFCJandy R0479105

Jandy R0479105 is not sold on Active yet.

Wiring compartment and fan shroud kit, three phaseJandy R0895000

Jandy R0895000 is not sold on Active yet.

Motor, 5 HP single phase TEFCJandy R0445117

Jandy R0445117 is not sold on Active yet.

Fan shroud, single phaseJandy R1093000

Jandy R1093000 is not sold on Active yet.

Wiring compartment lid, single phaseJandy R1092900

Jandy R1092900 is not sold on Active yet.

Drawing and key numbers from Jandy's Stealth pump Installation and Operation Manual, H0573800, pages 15 to 17. Generic and kit parts sit at the key for the manufacturer's part they replace.

Skip to results list

Filters

47 items

Filter

About Jandy Stealth, PlusHP & FloPro Pump Parts

Parts for Jandy's Pro Series pumps, made by Zodiac: the Stealth (SHPF and SHPM), PlusHP (PHPF and PHPM), MaxHP (MHPM), FloPro (FHPM), VS FloPro and ePump, plus the WaterFeature and WaterFall pumps that share their parts. Impeller kits by horsepower, diffusers, mechanical seals, backplate kits, pump bodies, lids with locking rings, baskets, lid seals, unions and tailpieces, nearly all of them Jandy's own, with a SuperPro seal kit and a U.S. Seal shaft seal as the alternatives.

Motors are on pool pump motors and parts for every make of pump are on pump parts. Parts for the Polaris booster pump, which shares a 13/16 inch seal with early Stealth pumps, are on Polaris booster pump parts, and the rest of the brand is on Jandy.

Two Pool School guides go with these parts. After a new lid O-ring, basket or shaft seal, how to prime a pool pump gets the Stealth running again, with each manufacturer's time limit. And before ordering a motor for the Stealth, motor or whole pump has the tests that tell a failed motor from a jammed impeller.

Questions about Jandy Stealth, PlusHP & FloPro Pump Parts

Which impeller kit fits my Jandy Stealth SHPF or SHPM pump?

Match the full model number to Jandy's list, because each M model shares a kit with the F model a step smaller. R0807203 fits an SHPF.75 and an SHPM1.0, R0807202 an SHPF1.0 and an SHPM1.5, R0807201 an SHPF1.5 and an SHPM2.0, and R0807200 an SHPF2.0 and an SHPM2.5. Where Jandy lists a two speed -2 version, it takes the same kit as the single speed of that number. R0807205 is the SHPF3.0 kit, and every Stealth from .50 to 3.0 uses the R0445400 diffuser.

Why is my Jandy Stealth leaking water between the motor and the pump body?

Jandy's manual puts that down to a damaged or failed mechanical seal. Its current Stealth, PlusHP, FloPro and ePump manuals give one seal for every size, the 5/8 inch R0479400, and the R0445200 backplate kit includes it. The 13/16 inch R0445500 is listed here for Stealth pumps with a serial number before P08FF0001, so read the serial before ordering. The U.S. Seal PS-4231-OS is a generic 5/8 inch alternative.

Why are there air bubbles in my Jandy pump basket?

Air is getting into the system. Jandy's checklist: make sure the pool is at its normal level, then take off the lid, clear any debris from the lid o-ring seat and check the lid seal sits the right way; on a PlusHP the side with two ribs goes into the groove. Tighten the lid by hand, no tools. If bubbles remain, clean and refit both union o-rings on the suction side. Lid seals are R0446200 for the Stealth and ePump and R0449100 for the PlusHP and MaxHP; the FloPro lid o-ring is R0480200.

Which impeller and diffuser fit a Jandy FloPro or VS FloPro?

The FloPro takes impellers by horsepower: R0479602 for the 1 HP and the 1 HP two speed, R0479603 for 1.5 HP, R0479604 for 2 HP and R0479605 for 2.5 HP, with the R0479702 diffuser up to 1 HP and R0479701 from 1.5 HP. For the VS FloPro, Jandy lists the 0.85 HP VSFHP085 with R0479602 and R0479702, and the 1.65 HP VSFHP165 with R0479603 and R0479701. The Stealth and PlusHP use a different impeller series.

What base does a Jandy FloPro need to replace a Sta-Rite Max-E-Pro or Dura-Glas?

The small base it comes with plus the large base spacer, R0546400, which Jandy sells separately. Jandy's manual sets the FloPro's height by the pump it replaces: no base for a Hayward Super Pump, Pentair SuperFlo or Sta-Rite SuperMax; the small base for a Hayward Super II or a Jandy PlusHP or MaxHP; the small base with spacers for a Pentair WhisperFlo or Sta-Rite Dyna-Glas; and both bases for a Max-E-Pro, Max-E-Glas, Dura-Glas or Dura-Glas II.
