SuperPro O-176A-9 five spoke valve seat gasket, 5-5/16 in., for Hayward Vari-Flo valvesSuperPro Valve Seat Gasket 5 Spoke (5-5/16"), O-176A-9 In stock$799
SuperPro O-176A-9 five spoke valve seat gasket, 5-5/16 in., for Hayward Vari-Flo valves
Shop all Aladdin

SuperPro Valve Seat Gasket 5 Spoke (5-5/16"), O-176A-9

Ask a questionMPN O-176A-9
$799
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Replaces SPX0710XD the seat gasket for the Hayward® 1-1/2 in. Vari-Flo multiport valve.
  • Five spoke matches the five position web of the Vari-Flo diverter seat.
  • 5-5/16 in. outside diameter with a 3/4 in. center hole.
  • Fits SP0710X, SP0711 and SP0712 valves the 1-1/2 in. top mount Vari-Flo family.
  • Aftermarket by SuperPro a lower cost alternative to the Hayward® branded gasket.
  • Stops the bypass a worn spider gasket lets water leak between positions, which shows up as water at the waste line while filtering.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About SuperPro Valve Seat Gasket 5 Spoke (5-5/16"), O-176A-9, SKU ALA-601-4664. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item SuperPro Valve Seat Gasket 5 Spoke (5-5/16"), O-176A-9
Aladdin

SuperPro Valve Seat Gasket 5 Spoke (5-5/16"), O-176A-9

$799
SuperPro Tank O-Ring Compatible with Select Hayward® Filters, O-429-9
Aladdin

SuperPro Tank O-Ring Compatible with Select Hayward® Filters, O-429-9

$1499
SuperPro Generic 2" Diverter Gasket, G-417-9
Aladdin

SuperPro Generic 2" Diverter Gasket, G-417-9

$1299
SuperPro Generic Tank O-Ring 20-7/8" ID (7/16" Thick), O-497-9
Aladdin

SuperPro Generic Tank O-Ring 20-7/8" ID (7/16" Thick), O-497-9

$2199
SuperPro 18" Tank O-Ring, O-184-9
Aladdin

SuperPro 18" Tank O-Ring, O-184-9

$1499
Super-Pro O-Ring, U9-228A/CX900F, O-240-9
Aladdin

Super-Pro O-Ring, U9-228A/CX900F, O-240-9

$1099
SuperPro O-Ring O-231-9
Aladdin

SuperPro O-Ring O-231-9

$399
Subtotal

Similar products

Other products people compare with this one.

Pentair 271106 sight glass gasket for multiport valves Pentair M-Series Sight Glass Gasket, 271106$1099 Sta-Rite 14971-SM10E10 valve shaft O-ring for multiport filter valves Sta-Rite Valve Shaft O-Ring, 14971-SM10E10$499 Pentair 152501 adapter o-ring for the PacFab 2 in. multiport valve Pentair O-Ring Adapter for 2" Top Mount and Side Mount Valve, 152501$999 Pentair 152168Z multiport valve screw, M6 x 30mm stainless steel Pentair Multiport Valve Screw, M6 x 30mm, Stainless Steel, 152168Z$699 Aladdin O-384-9 valve to tank o-ring for Hayward sand filters Aladdin Valve to Tank O-Ring for Hayward® GM-400F and S140T Sand Filters, O-384-9$515 CMP 27515-154-991 replacement valve decal for the Hayward SP714T Vari-Flo XL backwash valve CMP Valve Decal Compatible with Hayward® SP714T Vari-Flo® XL Backwash Valve, 27515-154-991$799 Aladdin O-224-9 o-ring for a Jacuzzi 2 inch multiport valve Aladdin O-Ring for Jacuzzi 2 in. Multiport Valve, O-224-9$699 Hayward SPX0710XZ3 Vari-Flo valve cover o-ring, 5-1/2 in. inside diameter Hayward Cover O-Ring, 5-1/2" ID, SPX0710XZ3$599 Hayward SPX0710Z16 nylon handle washer for Vari-Flo multiport valves Hayward Nylon Washer, SPX0710Z16$499 Jacuzzi 13038203R sight glass deflector for DVK series dial valves Jacuzzi Sight Glass Deflector, 13038203R$1099
Sta-Rite 35505-1228 Swimquip diverter o-ring for multiport valves Sta-Rite Swimquip Diverter O-Ring, 35505-1228$499 Pentair 272505 plastic washer for PacFab multiport filter valves Pentair 272505 Plastic Washer, 2 Required$1099 Waterway 873-E17S1 sight glass filter valve part Waterway Sight Glass 873-E17S1$699 Purex 74927 compression screw, 1/4-20 by 5/8 inch Purex Compression Screw 1/4-20 x 5/8", 74927$499 Hayward SPX0710K 1/4 in. plastic pipe plug for Vari-Flo multiport valves Hayward 1/4 in. Plastic Pipe Plug for Vari-Flo Multiport Valves, SPX0710K$799 Pentair 98211400 brass plated stainless steel 1/4 inch-20 hex nut Pentair Brass Plated Stainless Steel 1/4 in.-20 Hex Nut for DE Filters and Multiport Valves, 98211400$799 Waterway 819-0010 lid screw for sand filter multiport valve Waterway Lid Screw for Sand Filter Multiport Valves, 1/4-20 x 1-1/2 in., 819-0010$626 Waterway 819-0005 stainless steel screw for single port filter valve Waterway Stainless Steel Screw for 50/100 sq ft Single Port Filter Valves, 8-32 x 7/16 in., 819-0005$699 Pentair 273077 white plastic plug for Sta-Rite 2 inch PVC slide multiport valve Pentair White Plastic Plug for Sta-Rite 2 in. PVC Slide Multiport Valves 261047 and 261165, 273077$999 Pentair 35817-0056 stainless steel short spring pin for Sta-Rite Swimquip slide valve Pentair Stainless Steel Short Spring Pin for Sta-Rite Swimquip Slide Valves, 1/8 in. x 9/16 in., 35817-0056$899

Product details

The SuperPro O-176A-9 is a five spoke spider gasket for the Hayward® 1-1/2 in. Vari-Flo multiport valve. It is an aftermarket replacement for Hayward® part SPX0710XD and fits the SP0710X, SP0711 and SP0712 valves.

Dimensions

Outside diameter is 5-5/16 in. and the center hole is 3/4 in. If your valve is the 2 in. Vari-Flo, it takes a larger 6-1/2 in. gasket instead, so measure before ordering.

The spider gasket is what seals the diverter against each port. When it hardens or lifts out of its groove, water bypasses to the waste line during filtering and the pool loses water. Replacing it restores the seal and is the usual first fix for a Vari-Flo valve that will not hold position cleanly.

Specifications
Brand SuperPro
Manufacturer part number O-176A-9
UPC 610377034920
Part type Filter valve part, spider gasket
Replaces Hayward® SPX0710XD
Fits Hayward® 1-1/2 in. Vari-Flo valves SP0710X, SP0711, SP0712
Spokes 5
Outside diameter 5-5/16 in.
Center hole inside diameter 3/4 in.
Shipping weight 0.1 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Aladdin

Aladdin Magic Lube 630 PTFE o-ring lubricant, 1 oz. tube Aladdin Magic Lube 1 oz. O-Ring Lubricant$699 Aladdin GO-KIT32-9 seal and gasket kit for Pentair WhisperFlo and IntelliFlo pumps Aladdin Seal & Gasket Kit for Pentair WhisperFlo & IntelliFlo Pool Pumps, GO-KIT32-9$3499 Aladdin GO-KIT 71 seal kit for the old style Polaris PB4-60 booster pump Aladdin GO-KIT 71 Seal Kit for Polaris PB4-60 Booster Pump$1699 Aladdin Magic Lube 631 PTFE o-ring lubricant, 5 oz. tube Aladdin Magic Lube 5 oz. O-Ring Lubricant$1499 Aladdin Equipment Co. GO-KIT3-9 rebuild kit for the Hayward Super Pump: housing gasket, diffuser gasket, lid gasket and shaft seal Aladdin Equipment Co. Super Pump Rebuild Kit, GO-KIT3-9$1999 SuperPro GO-KIT2-9 rebuild kit for Hayward Super II pump: seals and gaskets SuperPro Super II Pump Rebuild Kit GO-KIT2-9$4499 SuperPro O-429-9 generic tank o-ring for Hayward filters, replaces DEX2400K SuperPro Tank O-Ring Compatible with Select Hayward® Filters, O-429-9$1499 Aladdin GO-KIT5-9 pump rebuild kit for Pentair PacFab Challenger pumps, shaft seal and o-rings Aladdin Go-Kit 5 Pump Rebuild Kit for Pentair PacFab Challenger Pumps, GO-KIT5-9$2499 SuperPro GO-KIT70 2 in. valve rebuild kit for Pentair PacFab multiport valves SuperPro 2 in. Valve Rebuild Kit, GO-KIT70$1999 SuperPro B-37 generic replacement skimmer basket for the S-10 Admiral skimmer SuperPro S-10 Admiral Skimmer Basket (Generic)$1999
SuperPro 271148 diverter spider gasket for 2 in. Pentair PacFab multiport valve SuperPro Generic 2" Diverter Gasket, G-417-9$1299 Aladdin APCKIT39 SP715 multiport valve repair kit, 2 inch, with spring Aladdin SP715 Multiport Valve Repair Kit 2" with Spring, APCKIT39$4699 Aladdin O-411-9 replacement o-ring, 5-1/4 in. inside diameter Aladdin O-Ring, 5-1/4" ID, O-411-9$399 Super-Pro GO-KIT3V-9 Viton gasket and o-ring seal kit for the Hayward Super Pump SuperPro Super Pump Seal Kit with Viton Seals, GO-KIT3V-9$3799 SuperPro O-497-9 generic tank o-ring, 20-7/8 inch ID by 7/16 inch thick SuperPro Generic Tank O-Ring 20-7/8" ID (7/16" Thick), O-497-9$2199 Aladdin Magic Lube II 5 oz tube of silicone lubricant and sealer, part 651 Aladdin Magic Lube II 5 oz$2299 SuperPro GO-KIT14-9 seal kit for Jacuzzi Magnum pumps SuperPro Jacuzzi Magnum Pump Seal Kit, GO-KIT14-9$2999 SuperPro O-184-9 18 inch tank o-ring for Pentair PacFab Nautilus DE filters SuperPro 18" Tank O-Ring, O-184-9$1499 SuperPro GO-KIT6-9 rebuild kit for Sta-Rite Max-E-Glas and Dura-Glas pumps SuperPro Max-E-Glas/Dura-Glas Pump Rebuild Kit, GO-KIT6-9$2299 Polaris O-299-9 bracket O-ring for the PB4-60 booster pump, also listed as P-95 Polaris Bracket O-Ring for PB4-60 Booster Pump, O-299-9$399

Questions and answers

What people ask about this product, answered by our pool techs.

Which valve does this fit?
The Hayward® 1-1/2 in. Vari-Flo top mount multiport valve, models SP0710X, SP0711 and SP0712. It is a replacement for Hayward® gasket SPX0710XD.
How do I confirm the size?
Measure the old gasket. This one is 5-5/16 in. across the outside with a 3/4 in. center hole and five spokes. The 2 in. Vari-Flo valve uses a larger 6-1/2 in. gasket.
Is this the Hayward® part?
No. It is a SuperPro aftermarket gasket made to replace the Hayward® SPX0710XD.
What are the signs my spider gasket is worn?
Water running out the waste line while the valve is in Filter, or the handle feeling loose between positions. Both point to the gasket no longer sealing against the diverter.
