Paramount 005-302-3570-00 in-floor valve module clampParamount In-Floor Valve Module Clamp, Hydra Valve, 005-302-3570-00 In stock$6199
Paramount 005-302-3570-00 in-floor valve module clamp
Shop all Paramount

Paramount In-Floor Valve Module Clamp, Hydra Valve, 005-302-3570-00

Ask a questionMPN 005-302-3570-00
$6199
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Paramount 005-302-3570-00 The factory replacement clamp for the in-floor valve module.
  • For the Hydra Valve Listed as the valve module clamp used with the Paramount Hydra Valve.
  • In-floor cleaning system part Belongs to the water valve that cycles the floor heads.
  • Sold on its own A single replacement clamp, not the complete valve module.
  • Serviceable in place Replacing the clamp avoids pulling the whole valve module when only the clamp has failed.
  • Genuine Paramount The OEM part rather than a generic band clamp.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Paramount In-Floor Valve Module Clamp, Hydra Valve, 005-302-3570-00, SKU PMT-201-603. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Paramount In-Floor Valve Module Clamp, Hydra Valve, 005-302-3570-00
Paramount

In-Floor Valve Module Clamp, Hydra Valve, 005-302-3570-00

$6199
Aladdin Magic Lube 1 oz. O-Ring Lubricant, 630
Aladdin

Magic Lube 1 oz. O-Ring Lubricant, 630

$699
Boss Clear Silicone Sealant Tube, 3 oz., PLB103C
American Granby

Boss Clear Silicone Sealant Tube, 3 oz., PLB103C

$1499
Deck-O-Seal Deck-O-Shield Waterfall & Stone Sealer, 1 Gallon, 3460210
Deck-O-Seal

Deck-O-Shield Waterfall & Stone Sealer, 1 Gallon, 3460210

$11699
Aladdin Magic Lube 5 oz. O-Ring Lubricant, 631
Aladdin

Magic Lube 5 oz. O-Ring Lubricant, 631

$1499
Skimlite 6000 Snaplite Series Button Lock Pole, 8' to 16', 2-Piece, 6016
Skimlite

6000 Snaplite Series Button Lock Pole, 8' to 16', 2-Piece, 6016

$14599
Pentair Sand Vac, 542090
Pentair

Sand Vac, 542090

$17399
Subtotal

Similar products

Other products people compare with this one.

The PoolMan Stain Eraser tile and plaster cleaner, pole mounted stain removal block The PoolMan Stain Eraser Tile and Plaster Cleaner, 11036$3199 Pentair Rainbow Leaf Master R211046 leaf eater pool vacuum on a pole Pentair Rainbow Leaf Master, R211046$7799 ecoOne ECO-8014 hose filter that purifies up to 40,000 gallons of water ecoOne Hose Filter, Purifies up to 40,000 Gallons of Water, ECO-8014$5799 Paramount PV-3 head removal tool with plastic handle, part 004-627-5452-00 Paramount PV-3 Head Removal Tool, 004-627-5452-00$4699 Blue Square 1130499 Q360 in-floor cleaning system water valve lid with o-ring Blue Square Manufacturing Q360 Infloor Valve Lid with O-Ring, 1130499$5699 Paramount 004-552-5452-00 PCC2000 step nozzle tool with plastic handle Paramount PCC2000 Step Nozzle Tool with Plastic Handle, 004-552-5452-00$3799 Pool Tool 125 main drain suction mat, 12 inch flexible PVC with stainless steel hook Pool Tool Inc. Main Drain Suction Mat, 125$5199 Paramount RetroJet installation tool 004-652-5422-00 Paramount RetroJet Installation Tool, 004652542200$4099 Pentair 236671 non-venturi internal retro-head in white Pentair Nonventuri Internal Retro Head, White, 236671$5899 Hayward SP1056T hydrostatic relief valve install and removal tool Hayward Hydrostatic Relief Valve Tool, SP1056T$4599
Pentair A&A 540189 LeafVac lid assembly Pentair A&A LeafVac Lid Assembly, 540189$9099 Paramount 004652495401 white RetroJet nozzle for bayonet Caretaker 99 heads Paramount White RetroJet for Bayonet Caretaker 99 Nozzle, 004652495401$6599 Hayward Paramount PV3 nozzle 004627506001 with twist lock cap, white Hayward Paramount PV3 Nozzle with Twist Lock Cap, White, 004627506001$9199 Hayward SP022310 Bobby 10 in disposable hose filter Hayward 10" Bobby Reusable Start-Up Filter, SP022310$5299 Hayward SP022320 Bobby 20 inch disposable fill hose filter attached to a fill hose Hayward Bobby Disposable Fill Hose Filter 20", SP022320$6699 Paramount PCC2000 gray popup head step nozzle 004-552-5032-02 Paramount PCC2000 Popup Head Step Nozzle, Gray, 004-552-5032-02$9199 Pentair 230330 Pool Valet high flow retro-fit replacement head in white Pentair Pool Valet High Flow Retro-Fit Replacement Head, White, 230330$6499 Pentair 154512Z 6 inch flanged valve wrench for 1-1/2 inch MultiPort valves Pentair Flanged Valve Wrench 6", 154512Z$3599 Hayward SP3100T Super II pump strainer lid removal tool Hayward Pump Lid Removal Tool for Select Super II Series Pool Pumps, SP3100T$3699 Pool Tool Inc. 141 closed impeller cleaning kit Pool Tool Inc. Closed Impeller Cleaning Kit, 141$3299

Product details

The Paramount 005-302-3570-00 is the complete band clamp, with knob and nut, that holds the valve shells together on a Paramount in-floor water valve, and it is listed for use with the Hydra Valve.

Where it sits

In-floor cleaning systems route water through a valve that sends flow to each group of cleaning heads. Paramount's owner's manual lists the valve as a top, a base, a replaceable module and this band clamp, which goes around the two shells and is drawn tight by a knob or a 7/16 inch nut on a threaded bolt.

Fitting it

Turn off all equipment including the pumps before you open the valve. To close it, place the clamp around the shells, start the knob or nut, and tighten it securely while gently tapping the clamp from opposite the knob around both sides. Be careful not to over tighten. Run the pump and look for leaks; if the valve leaks, shut the pump off and tighten the clamp more, and replace the base o-ring if it keeps leaking.

Before you order

This is the clamp on its own, not the shell or the module. The manual also lists the clamp knob (005-302-3600-00) and nut (005-302-0640-00) as separate parts, so if only the knob or nut is damaged you may not need the whole clamp.

Specifications
Brand Paramount
Manufacturer part number 005-302-3570-00
Type Valve module clamp
Application In-floor cleaning system water valve module
Used with Hydra Valve
Sold as Single replacement part
Includes Band clamp with knob and nut
Related parts Clamp knob 005-302-3600-00; clamp nut 005-302-0640-00; base o-ring 005-302-0100-00
Shipping weight 0.85 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Paramount

Paramount 004-302-4408-00 6 port water valve module for in-floor cleaning systems Paramount 6 Port Water Valve Module, 004-302-4408-00$35699 Paramount 005-152-4580-00 clear internal lid for the debris canister Paramount Debris Canister Internal Lid, 005-152-4580-00$6599 Paramount 004-302-4406-00 water valve 4 port module, 3+1 configuration Paramount Water Valve 4 Port Module 3+1, 004-302-4406-00$37699 Paramount 005-152-0120-00 o-ring for the Clear Canister lid Paramount Canister Lid O-Ring, 005-152-0120-00$5799 Paramount PV-3 head removal tool with plastic handle, part 004-627-5452-00 Paramount PV-3 Head Removal Tool, 004-627-5452-00$4699 Paramount 004652495401 white RetroJet nozzle for bayonet Caretaker 99 heads Paramount White RetroJet for Bayonet Caretaker 99 Nozzle, 004652495401$6599 Paramount 005-402-3834-00 replacement lamp for the Clear O3 system Paramount Clear O3 Replacement Lamp, 005402383400$14899 Paramount 004402388100 Clear O3 ozone generator, 120/240V Paramount Clear O3 Ozone Generator 120/240V, 004402388100$67999 Paramount 005-252-2087-01 retro VGB SDX hi-flow drain cover, white Paramount Retro VGB SDX Hi-Flow Drain Cover, White, 005-252-2087-01$5399 Paramount ClearO3 203V ozone oxidizer with 230V Ultra UV2 ultraviolet sanitizer Paramount ClearO3 203V Ozone Oxidizer and Ultra UV2 Ultraviolet Sanitizer, 1 UV-C Lamp, 230V, 006422003000$1,06899
Paramount RetroJet nozzle for the Pool Valet in floor cleaning system Paramount RetroJet Nozzle for Pool Valet, 006-502-4714-01$12199 Hayward 005761293400 Paralevel extension, 1 inch Hayward Paralevel Extension 1", 005761293400$5999 Paramount 005-302-4300-03 water valve top dome in black Paramount Water Valve Top Dome, Black, 005-302-4300-03$17999 Paramount 006422001000 Ultra UV2 and Clear O3 system, 120V 2 lamp Paramount Ultra UV2 and Clear O3 System, 120V, 2 Lamp, 006422001000$1,49899 Paramount Paralevel 004760290201 complete automatic pool and spa water leveler in white Paramount Paralevel Autofill, 004760290201$14499 Hayward 004402585000 Clear O3 start-up kit Hayward Clear O3 Start-Up Kit, 004402585000$20099 Paramount EDC equipment debris canister, complete with lid and basket Paramount EDC Equipment Debris Canister, 004152451600$44599 Hayward Paramount Ultra UV2 2 lamp 230V ultraviolet water sanitizer Hayward Ultra UV2 2 Lamp Water Sanitizer 230V, 004422202600$1,06199 Paramount 005-302-4132-03 black 6-port valve shell for 2 inch plumbing Paramount 6-Port Valve Shell, 2 Inch, Black, 005302413203$37799 Paramount RetroJet installation tool 004-652-5422-00 Paramount RetroJet Installation Tool, 004652542200$4099

Questions and answers

What people ask about this product, answered by our pool techs.

What is this clamp for?
It is the replacement clamp for the in-floor valve module used with the Paramount Hydra Valve.
Does it include the valve module?
No. This is the clamp on its own.
Is it a genuine Paramount part?
Yes, Paramount part number 005-302-3570-00.
Do I have to remove the whole valve to fit it?
The clamp is a serviceable piece of the valve module, so a failed clamp can be dealt with without replacing the module itself.
Ask your own question
