Pentair Genuine OEM DPST 20 Amp Relay Kit, RLYLX

Ask a questionMPN RLYLX
$13799
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Genuine Pentair Factory part RLYLX, not an equivalent relay sourced elsewhere.
  • 20 ampere rating Pentair lists it as a 20-Ampere power relay.
  • DPST Double pole, single throw, so it switches both legs of a circuit at once.
  • Compool systems Supplied as the additional power relay replacement kit for Compool pool and spa automation control systems.
  • Add or replace Sold as a kit, so it covers both a failed relay and a circuit being added to an existing panel.
  • A common failure point Relays are the moving part in an automation panel, and a circuit that no longer switches is usually the relay before it is the board.
