Hayward FDXLBVS1930 blower vacuum switch for Universal H-Series Low NOx heatersHayward Blower Vacuum Switch, FDXLBVS1930 In stock$4999
Hayward FDXLBVS1930 blower vacuum switch for Universal H-Series Low NOx heaters
Shop all Hayward

Hayward Blower Vacuum Switch, FDXLBVS1930

Ask a questionMPN FDXLBVS1930
$4999
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Genuine Hayward Factory part FDXLBVS1930, the OEM blower vacuum switch.
  • Proves the blower The switch confirms the combustion blower is drawing before the heater is allowed to fire.
  • Full Low NOx range Listed for H150FD, H200FD, H250FD, H300FD, H350FD and H400FD.
  • Pool, spa and ASME Covers the Universal H-Series Low NOx pool and spa heaters as well as the ASME versions.
  • A common no fire fault A heater that runs its blower and then locks out often has a failed vacuum switch or a blocked sensing line.
  • Safety device It is part of the ignition safety chain, so it is replaced, never bypassed.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Hayward Blower Vacuum Switch, FDXLBVS1930, SKU HAY-151-0021. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Hayward Blower Vacuum Switch, FDXLBVS1930
Hayward

Blower Vacuum Switch, FDXLBVS1930

$4999
Hayward Heat Exchanger Assembly for H250FD, FDXLHXA1250
Hayward

Heat Exchanger Assembly for H250FD, FDXLHXA1250

$1,10299
Hayward Natural Gas Valve Kit, FD Series, FDXLGSV0003
Hayward

Natural Gas Valve Kit, FD Series, FDXLGSV0003

$41899
Hayward H-Series Bezel & Keypad Assembly, FDXLBKP1930
Hayward

H-Series Bezel & Keypad Assembly, FDXLBKP1930

$12299
Hayward HDF400 Thermistor, FDXLTER1931
Hayward

HDF400 Thermistor, FDXLTER1931

$6199
Hayward Flame Sensor, Low NOx/Universal, IDXLFLS1930
Hayward

Flame Sensor, Low NOx/Universal, IDXLFLS1930

$8899
Hayward Front Header Assembly, FDXLFHA1930
Hayward

Front Header Assembly, FDXLFHA1930

$30399
Subtotal

Similar products

Other products people compare with this one.

Hayward FDXLWPS1930 H-Series pressure switch Hayward H-Series Pressure Switch, FDXLWPS1930$5199 Hayward CHXTSW1930 system on/off switch for CZ, HM2 and H-Series pool heaters Hayward H-Series System On/Off Switch CZ/HM2/H-Series, CHXTSW1930$3299 Hayward CHXTSW1931 3 way toggle system switch for H-Series pool heaters Hayward 3 Way Toggle System Switch, H-Series, CHXTSW1931$3499 Hayward FDXLVPS1930 H-Series Low NOx indoor vent pressure switch kit Hayward H-Series Low NOx Indoor Vent Pressure Switch Kit, FDXLVPS1930$7299 Hayward IDXBLG1930 blower gasket for H-Series above ground pool heaters Hayward H-Series Above Ground Blower Gasket, IDXBLG1930$3399 Hayward FDXLEGL1930 exhaust gas temperature limit for H-Series pool heaters Hayward Exhaust Gas Temperature Limit for H-Series Heaters, FDXLEGL1930$3699 Hayward FDXLTER1930 thermistor for Universal H-Series FD pool heaters Hayward Thermistor, FD, FDXLTER1930$5899 Hayward HAXNUT1930 H-Series ED1 and ED2 union nut Hayward ED1/ED2 Union Nut, 2 Pack, HAXNUT1930$3399 Hayward HAXNIP1930 CPVC flange pipe nipples for H-Series heaters, set of 2 Hayward CPVC Flange Pipe Nipples for H-Series, HAXNIP1930$6499 Hayward FDXLFOR1930 FD header o-ring kit for pool heaters Hayward FD Header O-Ring Kit, FDXLFOR1930$4099
Hayward HAXHLI1930 135F hi-limit switch for H-Series pool heaters Hayward 135F Hi-Limit, H-Series, HAXHLI1930$5799 Hayward FDXLBPK1930 bypass cartridge kit for Universal H-Series Low NOx pool heaters Hayward H-Series Low NOx Bypass Cartridge Kit, FDXLBPK1930$5799 Hayward HAXTRK1930 pilot tube kit for H Series pool heaters Hayward H Series Pilot Tube Kit, HAXTRK1930$4299 Hayward FDXLBON1930 natural gas burner orifice kit for Universal H-Series FD heaters Hayward Natural Gas Burner Orifice Kit, FD, FDXLBON1930$5999 Hayward FDXLHMB1930 header mounting base kit for Universal H-Series Low NOx heaters Hayward Header Mounting Base Kit, FDXLHMB1930$6799 Hayward FDXLHDW1930 header hardware kit for Universal H-Series Low NOx heaters Hayward Header Hardware Kit, FDXLHDW1930$6699 Hayward FDXLBOP1930 H-Series liquid propane burner orifice kit Hayward H-Series Liquid Propane Burner Orifice Kit, FDXLBOP1930$5999 Hayward Bezel Top Gasket Kit FD Models | FDXLGSK1932 Hayward Bezel Top Gasket Kit FD Models | FDXLGSK1932$4599 Hayward Complete Set Of Fuses | IDXL2FSK1930 Hayward Complete Set Of Fuses | IDXL2FSK1930$7099 Hayward IDXLBVS1930 H-Series blower vacuum switch Hayward H-Series Blower Vacuum Switch, IDXLBVS1930$7999

Product details

The Hayward FDXLBVS1930 is the blower vacuum switch for Universal H-Series Low NOx pool and spa heaters and the ASME versions, covering models H150FD, H200FD, H250FD, H300FD, H350FD and H400FD. It is the genuine Hayward part.

What it proves

Before the heater is allowed to ignite, it has to know the combustion blower is really moving air. The vacuum switch is what confirms that. It reads the pressure the blower creates and closes a contact, and only then does the ignition sequence continue.

The fault it causes

When the switch fails, or the small hose that feeds it is cracked or plugged, the heater will start its blower and then lock out without firing. Before condemning the switch, check that hose and look for a restriction in the vent, because a blocked flue produces the same symptom. Once the switch itself is proven faulty it gets replaced, not bypassed; it is part of the safety chain that keeps the heater from firing into a dead blower.

Specifications
Brand Hayward
Manufacturer part number FDXLBVS1930
UPC 610377079907
Type Blower vacuum switch
Fits Hayward Universal H-Series Low NOx pool and spa heaters and ASME heaters
Models H150FD, H200FD, H250FD, H300FD, H350FD, H400FD
Shipping weight 0.2 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Hayward

This industry builds more than pools. We build moments. Hayward

Hayward equipment

Hayward Super Pump 1 HP Max Rated 115/230V, W3SP2607X10 Hayward AquaRite Salt System Complete, 40,000 Gallon Pools, W3AQR15 Hayward TracVac Suction Wall Climbing Pool Cleaner for In-ground Pools up to 40 ft, W3HSCTRACCU Hayward Pro-Grid 60 Sqft DE Pool Filter, Valve Not Included, W3DE6020
Shop Hayward equipment

Genuine Hayward parts

Hayward TurboCell T-15 Salt Cell for Inground Pools up to 40,000 Gallons, W3T-CELL-15 Hayward Genuine OEM SP1082 Skimmer Basket, SPX1082CA Hayward Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA Hayward H-Series Bezel & Keypad Assembly, FDXLBKP1930
Shop Hayward parts
Pool cleaners: Hayward TracVac and PoolCleaner suction cleaners lined up on a pool deckPool automation: the Hayward app on a phone held up in front of an infinity poolPool water features: two bubblers in a tiled spa, a woman relaxing on a lounger behind
Hayward makes pumps, filters, heaters, salt systems, cleaners, lighting and automation for residential pools.Shop all Hayward

Customer reviews

More from Hayward

Hayward SP0714T Vari-Flo XL 1.5 in. top mount multiport valve kit, front view Hayward SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit$15899 Hayward CL200EF in-line automatic pool chlorinator, 9 lb tablet feeder Hayward CL200EF In-Line Automatic Pool Chlorinator, 9 lb Chemical Feeder$12999 Hayward GLX-CTL-RITE AquaRite salt system power center, control box only Hayward AquaRite Salt System Power Center (Requires Salt Cell), GLX-CTL-RITE$1,16900 Hayward SPX0714BA Vari-Flo XL valve key cover handle assembly for SP0714T Hayward Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA$14799 Hayward FDXLHXA1250 heat exchanger assembly for the H250FD Universal H-Series low NOx heater Hayward Heat Exchanger Assembly for H250FD, FDXLHXA1250$1,10299 Hayward TurboCell T-15 W3T-CELL-15 salt cell, replacement for AquaRite systems Hayward TurboCell T-15 Salt Cell for Inground Pools up to 40,000 Gallons, W3T-CELL-15$1,13499 Paralevel Startup Kit, part number 004-760-2921-00 Hayward Paralevel Startup Kit, 004-760-2921-00$5799 Hayward GLX-PCB-PRO main PCB for Goldline ProLogic and AquaPlus controls Hayward Main PCB Replacement for Goldline ProLogic Automation and Chlorination After 10/2008, GLX-PCB-PRO$1,07599 Hayward SP10841 Auto-Skim skimmer for vinyl and fiberglass pools, white with square lid Hayward Auto-Skim Skimmer for Vinyl/Fiberglass Pools, 1.5" FPT, Square Lid, White, SP10841$19299 Hayward SPX0714L cover o-ring for SP0714T Vari-Flo XL valve Hayward Cover O-Ring for SP0714T Vari-Flo XL Valve, SPX0714L$1899
Paramount 005422901500 two lamp UV kit with boot and o-ring for HydraPure and Ultra UV2 sanitizers Paramount 2-Lamp Kit with Boot and O-Ring for HydraPure and Ultra UV2 Sanitizers, 005422901500$26899 Hayward W3T-CELL-9 TurboCell T-9 salt cell with 15 ft cord Hayward TurboCell T-9 Salt Cell for Inground Pools up to 25,000 Gallons, Genuine AquaRite Replacement, W3T-CELL-9$89900 Web Price Hayward SP0710X62 Vari-Flo 1.5 in. side mount multiport valve for Pro Series sand filters Hayward Vari-Flo 1.5" Side Mount Multiport Valve for Sand Filters, SP0710X62$18899 Hayward SPX1082CA genuine OEM skimmer basket, 7 in. top diameter Hayward Genuine OEM SP1082 Skimmer Basket, SPX1082CA$2399 Hayward SPX1091Z7 1-1/2 in. combo hose adapter, 2 pack Hayward 1-1/2" Combo Hose Adapter for Filters, Pumps, Skimmers and Chlorine Feeders (2 Pack), SPX1091Z7$1099 Hayward SPX0740BA key cover and handle assembly for SP740DE multiport valve Hayward OEM Key Cover and Handle Assembly for SP740DE, SPX0740BA$19799 Hayward CX200XRE 200 sq. ft. replacement filter cartridge for the SwimClear C200S Hayward Genuine OEM SwimClear C200S Filter Cartridge, CX200XRE$20299 Hayward HLXPROUPG Pro Logic Retrofit Kit, OmniPL Hayward Pro Logic Retrofit Kit, OmniPL, HLXPROUPG$1,99900 Web Price Hayward SP071620T 2 in. top mount backwash valve with clamp for Pro Series S310T and S310T2 Hayward 2" Top Mount Backwash Valve with Clamp, Fits Pro Series Sand Filters S310T / S310T2, SP071620T$26299 Hayward FDXLGSV0003 natural gas valve kit for Universal H-Series FD heaters Hayward Natural Gas Valve Kit, FD Series, FDXLGSV0003$41899

Questions and answers

What people ask about this product, answered by our pool techs.

What does the blower vacuum switch do?
It senses that the combustion blower is actually pulling air. Until the switch closes, the heater will not proceed to ignition.
Which heaters does it fit?
Hayward Universal H-Series Low NOx and ASME heaters in models H150FD, H200FD, H250FD, H300FD, H350FD and H400FD.
My heater starts the blower then shuts down. Is this the part?
That symptom points at the vacuum switch circuit. Check the sensing hose and the vent for a blockage first, then replace the switch if it still fails to close.
Can I jumper the switch to get through the weekend?
No. It is a safety device in the ignition chain. Replace it with the Hayward part.
