Century B2983 full rated two speed pool pump motor, 1.5 HP 1.47 SF 230VCentury Full-Rated Two-Speed Motor, 1.5 HP 1.47 SF 230V (B2983) In stock$58899
Century B2983 full rated two speed pool pump motor, 1.5 HP 1.47 SF 230V
Shop all Century Motors

Century Full-Rated Two-Speed Motor, 1.5 HP 1.47 SF 230V (B2983)

Ask a questionMPN B2983
$58899
FREE Delivery
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Two speeds 3450 rpm on high and 1725 rpm on low, with energy efficient windings at both speeds.
  • Full rated 1.5 HP 1.5 HP with a 1.47 service factor, drawing 10.0 A on high and 1.6 A on low at 230V.
  • Built for the pad Open drip proof enclosure, sealed ball bearings, class F insulation, thermal protection and a 50 C ambient rating.
  • Threaded stainless shaft 303 stainless steel 1/2 in. threaded shaft, 0.625 in. diameter, on a Y56Y rolled steel frame.
  • Fits common pumps Listed for the Hayward TriStar SP3200 and SP3200EE and Pentair SuperFlo pumps.
  • Not for California This motor does not meet California Title 20 and cannot be shipped to or installed in California; the Century V-Green EVO models are the compliant alternative.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Century Full-Rated Two-Speed Motor, 1.5 HP 1.47 SF 230V (B2983), SKU MGT-60-2983. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Century Full-Rated Two-Speed Motor, 1.5 HP 1.47 SF 230V (B2983)
Century Motors

Century Full-Rated Two-Speed Motor, 1.5 HP 1.47 SF 230V (B2983)

$58899
Century 1-1/2 HP 3450 RPM 56Y Frame Square Flange Pool Pump Motor, 115/230V, B2854V1
Century Motors

Century 1-1/2 HP 3450 RPM 56Y Frame Square Flange Pool Pump Motor, 115/230V, B2854V1

$35099
Century VGreen Evo Variable Speed 1.65 THP Square Flange Pool Pump Motor, 230/115 V, 48Y Frame, EVQ165
Century Motors

Century VGreen Evo Variable Speed 1.65 THP Square Flange Pool Pump Motor, 230/115 V, 48Y Frame, EVQ165

$63899
Century 56Y Frame ODP Square Flange Pool & Spa Pump Motor 2HP 230V, B2855
Century Motors

Century 56Y Frame ODP Square Flange Pool & Spa Pump Motor 2HP 230V, B2855

$42499
Century 1.65 HP Square Flange Pool and Spa Pump Motor, 3450 RPM 48Y, Threaded Shaft, HSQ165
Century Motors

Century 1.65 HP Square Flange Pool and Spa Pump Motor, 3450 RPM 48Y, Threaded Shaft, HSQ165

$35099
Century 1 HP Square Flange Pool Pump Motor, 1 Phase, 60 Hz, 230/115 V, 3450 RPM, 56Y Frame, B2853V1
Century Motors

Century 1 HP Square Flange Pool Pump Motor, 1 Phase, 60 Hz, 230/115 V, 3450 RPM, 56Y Frame, B2853V1

$32999
Century 1 HP Pump Motor, 230/115 Volt, 3450 RPM, Round Flange, 56J Frame, ODP, UST1102
Century Motors

Century 1 HP Pump Motor, 230/115 Volt, 3450 RPM, Round Flange, 56J Frame, ODP, UST1102

$29699
Subtotal

Similar products

Other products people compare with this one.

Century STS1152R energy efficient two speed pool pump motor, 1.5 x 1/4 HP, 230V Century Energy Efficient Two Speed Pump Motor, Full Rated, 1.5 x 1/4 HP, 230V, STS1152R$60199 Century SQS1202R 2 HP two-speed square flange pool pump motor, 230V, 48Y frame Century Motors 2 HP Two-Speed Square Flange Pool Pump Motor, 230V, 48Y, Full Rated, SQS1202R$74099 Century B2858 1.5 HP full rated pool pump motor, front right view Century 1.5 HP Full Rated Pool Pump Motor, 115/230V, Single Speed, B2858$48599 Century SQS1102R square flange 1 HP two speed 230V pool pump motor Century Square Flange Full Rated 1 HP 2 Speed 230V Pool Pump Motor SQS1102R$55899 Century SQS1152R square flange 1.5 HP two speed 230V pool pump motor Century Square Flange Full Rated 1.5 HP 2 Speed 230V Pool Pump Motor, SQS1152R$60399 Century B2982 1 HP two speed full rated pool pump motor, 230 V, Y56Y frame Century 1 HP Pool Motor, 2 Speed, Energy Efficient Full Rate, 230V, B2982$47499 Century B2979 2 HP two speed 230V round flange threaded shaft pool pump motor Century Threaded Shaft 2 HP 2 Speed 230V Full Rate Motor B2979$62499 Century ST1152 energy efficient full rated 1.5 HP pool pump motor, front view Century Energy Efficient Pump Motor, Full Rated, 1.5 HP, 115/230V, ST1152$42299 Century SQ1202 energy efficient 2 HP 230V pool pump motor Century Energy Efficient Motor, Full Rated, 2 HP, 230V, SQ1202$51199 Century B985 square flange two speed pool pump motor, 230V Century Square Flange 2 HP Two Speed Pool Pump Motor, 230V, B985$68899
Century QC1072 full rated 3/4 HP 48Y frame pool pump motor, 115/230V Century Motor, Full Rated, 48Y Frame, .75 HP, 3450 RPM, 115/230V, QC1072$37699 Century B122 1 HP keyed full rated pool and spa pump motor, 115/230V Century Keyed Full Rated Pool and Spa Pump Motor, 1 HP, 115/230V, B122$33199 Century ST1072 full rated 0.75 HP pool pump motor, 115/230V Century Pump Motor, Full Rated, 0.75 HP, 115/230v, ST1072$29799 Century B2975 1 HP 2-speed full-rate 56J pool pump motor, 230V Century 1 HP 2-Speed Full-Rate 56J Motor, 230V, B2975$49799 Century QC1102 1 HP full rated 48Y square flange pool pump motor Century Energy Efficient Motor Full Rated 1 HP, 115/208 (QC1102)$39199 Century B130 full rate 2 HP 230V 56J frame threaded shaft pool pump motor Century Threaded Full Rate 2HP 230V Pool Pump Motor, B130$48299 Century B2748 square flange full rated 2 HP pool and spa pump motor Century Square Flange Full-Rated Pool and Spa Pump Motor, 2 HP, B2748$54099 Century E-Plus B2841V1 1 HP square flange pool pump motor Century E-Plus B2841V1 Square Flange Full-Rated Pool Pump Motor, 1 HP$39199 Century USQ1152 up rated 1.5 HP square flange pool pump motor, front view Century Up Rated Pool Pump Motor, 1.5 HP, 115/230V, Square Flange, USQ1152$36999 Century B229SE 1.5 HP threaded shaft up rated pool pump motor Century B229SE Threaded Up Rated 1.5 HP Pool Pump Motor, 115/230V$35499

Product details

The Century B2983 is a full rated two speed pool pump motor: 1.5 HP with a 1.47 service factor on high, running 3450 rpm on high and 1725 rpm on low from a 230V single phase 60 Hz supply. It is listed as a replacement motor for the Hayward TriStar SP3200 and SP3200EE and for Pentair SuperFlo pumps.

Two speeds, one motor

Low speed runs everyday filtration at 1.6 A while high speed delivers 10.0 A worth of flow for vacuuming, spa jets or backwashing. Both windings are energy efficient. Electrically it is PSC on low speed and capacitor start, capacitor run on high, with two and four pole operation.

Construction

Open drip proof rolled steel frame in the Y56Y size, sealed ball bearings at both ends, class F insulation with thermal protection and a 50 C ambient rating for continuous duty. The 1/2 in. threaded shaft is 303 stainless steel, 0.625 in. in diameter with a 0.91 in. extension. Overall length is 13.90 in. with a 9.50 in. frame. Rotation is counterclockwise viewed from the pump end. UL recognized and CSA listed.

California

This motor does not meet California Title 20 and cannot be sold, shipped or installed in California. Century offers six CEC compliant V-Green EVO models, EVC130, EVC165, EVC225, EVQ130, EVQ165 and EVQ225, for pools in that state.

Specifications
Brand Century
Manufacturer part number B2983
UPC 786674031242
Horsepower 1.5/.19 HP
Voltage 230 V
Phase and frequency 1 phase, 60 Hz
Speed 3450/1725 rpm
Service factor 1.47
Current SF 10.0/1.6 A
Frame Y56Y
Enclosure Open drip proof
Electrical type PSC low speed, cap start/cap run high speed
Rotation Counterclockwise, pump end
Bearings Sealed ball, both ends
Insulation and protection Class F, thermally protected
Shaft 303 stainless steel, 1/2 in. threaded, 0.625 in. diameter, 0.91 in. extension
Overall length 13.90 in.
Shipping weight 35 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

Questions and answers

What people ask about this product, answered by our pool techs.

Can this motor ship to California?
No. It is not California Title 20 compliant and cannot be sold, shipped or installed in California. Century makes six CEC compliant V-Green EVO models, EVC130, EVC165, EVC225, EVQ130, EVQ165 and EVQ225, for that market.
What does full rated mean?
A full rated motor delivers its nameplate horsepower with the service factor on top, here 1.5 HP at 1.47 SF. An up rated motor of the same size would carry a higher HP label with a lower service factor for the same actual output.
Which pumps does it fit?
It is listed for the Hayward TriStar SP3200 and SP3200EE and the Pentair SuperFlo. Match the Y56Y frame, threaded shaft and 230V rating to your pump before ordering, and reuse or replace the shaft seal at the same time.
How much does it draw on low speed?
1.6 A at 230V on low, against 10.0 A on high, at service factor load. Low speed turns at 1725 rpm, half the 3450 rpm of high.
