Hayward VVX3000CKITWH V-Flex upgrade kit for PoolVac and Navigator cleaners, concrete, whiteHayward V-Flex Upgrade Kit, Concrete, White, VVX3000CKITWH In stock$12899
Hayward VVX3000CKITWH V-Flex upgrade kit for PoolVac and Navigator cleaners, concrete, white
Shop all Hayward

Hayward V-Flex Upgrade Kit, Concrete, White, VVX3000CKITWH

Ask a questionMPN VVX3000CKITWH
$12899
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • V-Flex turbine Swaps the old turbine for the patented variable vane design that opens for larger debris.
  • Fewer clogs The vanes adjust as debris passes, so the cleaner stops jamming on leaves and larger material.
  • Suits variable speed pumps The design holds suction across a wide flow range, which matters on a low speed setting.
  • Bearing free A-frame The kit includes the bearing free A-frame and retainer, so there are fewer parts to wear.
  • Wear parts included Four replacement shoes, two replacement wings and the suction inlet throat come in the kit.
  • For concrete pools, white This version is the concrete surface kit in white.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Hayward V-Flex Upgrade Kit, Concrete, White, VVX3000CKITWH, SKU HAY-201-3001. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Hayward V-Flex Upgrade Kit, Concrete, White, VVX3000CKITWH
Hayward

V-Flex Upgrade Kit, Concrete, White, VVX3000CKITWH

$12899
Hayward TigerShark Drive Track, Soft Thread, RCX23002
Hayward

TigerShark Drive Track, Soft Thread, RCX23002

$4699
Hayward Wheel Tube Assembly, Set of 2, RCX26003
Hayward

Wheel Tube Assembly, Set of 2, RCX26003

$7399
Hayward TigerShark Cord 55 Ft, RCX50061
Hayward

TigerShark Cord 55 Ft, RCX50061

$19799
Hayward Genuine OEM Standard Leaf Canister, W560
Hayward

Genuine OEM Standard Leaf Canister, W560

$7599
Hayward AquaVac TigerShark Roller Bearing Guide, RCX26001
Hayward

AquaVac TigerShark Roller Bearing Guide, RCX26001

$4099
Hayward Impeller, TigerShark, RCX11000
Hayward

Impeller, TigerShark, RCX11000

$2499
Subtotal

Similar products

Other products people compare with this one.

Hayward VVX3000SCKITWH V-Flex upgrade kit plus for concrete pools, white Hayward V-Flex Upgrade Kit Plus, Concrete, White, VVX3000SCKITWH$13999 Hayward HSXVV3000SAC PoolVac V-Flex turbine kit with turbine and bearings Hayward PoolVac V-Flex Turbine Kit with Turbine and 2 Turbine Bearings, HSXVV3000SAC$7199 Hayward PVGXH792KIT 2 wheel lower body conversion kit in white Hayward PVGXH792KIT 2X Lower Body Conversion Kit$16999 Hayward AXV621417WHP Navigator A-frame and pod combo tune-up kit Hayward Navigator A-Frame and Pod Combo Tune-Up Kit, AXV621417WHP$11899 Hayward Navigator & Pool Vac Ultra Body Lower Middle AD PV White | AXV050CWH Hayward Navigator & Pool Vac Ultra Body Lower Middle AD PV White | AXV050CWH$9399 Hayward Aqua Vac Tigershark Cartridge Refill Set | RCX70101 Hayward Aqua Vac Tigershark Cartridge Refill Set | RCX70101$8299 Hayward RCX70101PAK2 TigerShark replacement filter elements Hayward TigerShark Replacement Filter Elements, RCX70101PAK2$7899 Hayward RCX97007 TigerShark handle assembly in dark gray Hayward TigerShark Handle Assembly, AV (Dark Gray), RCX97007$6599 Hayward RCX26011 foam roller with tube for TigerShark robotic cleaners Hayward Foam Roller with Tube Replacement, TigerShark Cleaners, RCX26011$11699 Hayward AXV070 clear cone gear for select Hayward pool cleaners Hayward Cone Gear, Clear, AXV070$10099
Hayward PVXS11PK2-234 metallic blue Super Hump wheel tread for AquaNaut cleaners Hayward Metallic Blue AquaNaut Super Hump Replacement Tires, PVXS11PK2-234$6599 Hayward AXV414604WHP wing and shoe maintenance kit in white for Navigator and Pool Vac Hayward Wing and Shoe Maintenance Kit for Navigator and Pool Vac, White, AXV414604WHP$4399 Hayward AXV434WHP white flap kit with two flaps and front and rear springs Hayward Flap Kit, White, 2 Flaps with Front and Rear Springs, AXV434WHP$3399 Hayward AXV604WHP white wing kit for Navigator pool cleaner Hayward OEM Wing Kit, White, AXV604WHP$2399 Hayward AXV604-237 gray wing kit for Navigator V-Flex and PoolVac pool cleaners Hayward Wing Kit for Navigator V-Flex and PoolVac Pool Cleaners, AXV604-237$1799 Hayward AXV602P turbine kit for Navigator and Pool Vac XL cleaners Hayward Navigator / Pool Vac Turbine Kit, AXV602P$6099 Hayward PVGXH884KIT PoolCleaner 2 Wheel Limited next generation conversion kit Hayward PoolCleaner 2 Wheel Limited Next Generation Conversion Kit, PVGXH884KIT$20199 Hayward AXV621DAT A-frame and turbine kit for Navigator and Pool Vac cleaners Hayward A-Frame Turbine Kit, AXV621DAT$5599 Hayward Navigator & Pool Vac Ultra Open Lower Body White | AXV230DWH Hayward Navigator & Pool Vac Ultra Open Lower Body White | AXV230DWH$5399 Hayward AXV621D white A-frame kit for Navigator and Pool Vac pool cleaners Hayward A-Frame Kit, AXV621D$5299

Product details

The Hayward VVX3000CKITWH converts a PoolVac or Navigator suction cleaner to the V-Flex variable vane turbine. It is the concrete surface version, in white.

What V-Flex changes

The patented V-Flex turbine uses variable vanes that adjust as debris passes through. Larger material that would jam a fixed vane turbine goes through instead, which is what makes the cleaning close to clog free. The same design keeps suction up at lower flows, so the cleaner still works properly on a variable speed pump running an economical setting.

What is in the box

The kit is a full refresh, not just a turbine. It includes the V-Flex turbine kit, a bearing free A-frame kit with retainer, four replacement shoes, two replacement wings and the suction inlet throat. Between them, those parts cover most of what actually wears on a cleaner of this type, so an older unit comes out running close to new.

Fewer moving parts

The bearing free A-frame removes a wear item outright. Less to maintain, and one less thing to fail mid season.

Specifications
Brand Hayward
Manufacturer part number VVX3000CKITWH
UPC 610377302852
Type V-Flex upgrade kit
Surface Concrete
Color White
Fits Hayward PoolVac and Navigator pool cleaners
Kit contents V-Flex Turbine kit, bearing free A-Frame kit and retainer, replacement shoes (x4), replacement wings (x2), suction inlet (throat)
Shipping weight 1.75 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Hayward

This industry builds more than pools. We build moments. Hayward

Hayward equipment

Hayward Super Pump 1 HP Max Rated 115/230V, W3SP2607X10 Hayward AquaRite Salt System Complete, 40,000 Gallon Pools, W3AQR15 Hayward TracVac Suction Wall Climbing Pool Cleaner for In-ground Pools up to 40 ft, W3HSCTRACCU Hayward Pro-Grid 60 Sqft DE Pool Filter, Valve Not Included, W3DE6020
Shop Hayward equipment

Genuine Hayward parts

Hayward TurboCell T-15 Salt Cell for Inground Pools up to 40,000 Gallons, W3T-CELL-15 Hayward Genuine OEM SP1082 Skimmer Basket, SPX1082CA Hayward Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA Hayward H-Series Bezel & Keypad Assembly, FDXLBKP1930
Shop Hayward parts
Pool cleaners: Hayward TracVac and PoolCleaner suction cleaners lined up on a pool deckPool automation: the Hayward app on a phone held up in front of an infinity poolPool water features: two bubblers in a tiled spa, a woman relaxing on a lounger behind
Hayward makes pumps, filters, heaters, salt systems, cleaners, lighting and automation for residential pools.Shop all Hayward

Customer reviews

More from Hayward

Hayward SP0714T Vari-Flo XL 1.5 in. top mount multiport valve kit, front view Hayward SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit$15899 Hayward CL200EF in-line automatic pool chlorinator, 9 lb tablet feeder Hayward CL200EF In-Line Automatic Pool Chlorinator, 9 lb Chemical Feeder$12899 Hayward GLX-CTL-RITE AquaRite salt system power center, control box only Hayward AquaRite Salt System Power Center (Requires Salt Cell), GLX-CTL-RITE$1,42099 Hayward SPX0714BA Vari-Flo XL valve key cover handle assembly for SP0714T Hayward Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA$15299 Hayward FDXLHXA1250 heat exchanger assembly for the H250FD Universal H-Series low NOx heater Hayward Heat Exchanger Assembly for H250FD, FDXLHXA1250$1,28999 Hayward TurboCell T-15 W3T-CELL-15 salt cell, replacement for AquaRite systems Hayward TurboCell T-15 Salt Cell for Inground Pools up to 40,000 Gallons, W3T-CELL-15$1,09900 Web Price Paralevel Startup Kit, part number 004-760-2921-00 Hayward Paralevel Startup Kit, 004-760-2921-00$5999 Hayward GLX-PCB-PRO main PCB for Goldline ProLogic and AquaPlus controls Hayward Main PCB Replacement for Goldline ProLogic Automation and Chlorination After 10/2008, GLX-PCB-PRO$1,07599 Hayward SP10841 Auto-Skim skimmer for vinyl and fiberglass pools, white with square lid Hayward Auto-Skim Skimmer for Vinyl/Fiberglass Pools, 1.5" FPT, Square Lid, White, SP10841$19199 Hayward SPX0714L cover o-ring for SP0714T Vari-Flo XL valve Hayward Cover O-Ring for SP0714T Vari-Flo XL Valve, SPX0714L$1799
Paramount 005422901500 two lamp UV kit with boot and o-ring for HydraPure and Ultra UV2 sanitizers Paramount 2-Lamp Kit with Boot and O-Ring for HydraPure and Ultra UV2 Sanitizers, 005422901500$26899 Hayward W3T-CELL-9 TurboCell T-9 salt cell with 15 ft cord Hayward TurboCell T-9 Salt Cell for Inground Pools up to 25,000 Gallons, Genuine AquaRite Replacement, W3T-CELL-9$89900 Web Price Hayward SP0710X62 Vari-Flo 1.5 in. side mount multiport valve for Pro Series sand filters Hayward Vari-Flo 1.5" Side Mount Multiport Valve for Sand Filters, SP0710X62$19399 Hayward SPX1082CA genuine OEM skimmer basket, 7 in. top diameter Hayward Genuine OEM SP1082 Skimmer Basket, SPX1082CA$2499 Hayward SPX1091Z7 1-1/2 in. combo hose adapter, 2 pack Hayward 1-1/2" Combo Hose Adapter for Filters, Pumps, Skimmers and Chlorine Feeders (2 Pack), SPX1091Z7$1099 Hayward SPX0740BA key cover and handle assembly for SP740DE multiport valve Hayward OEM Key Cover and Handle Assembly for SP740DE, SPX0740BA$20399 Hayward CX200XRE 200 sq. ft. replacement filter cartridge for the SwimClear C200S Hayward Genuine OEM SwimClear C200S Filter Cartridge, CX200XRE$20899 Hayward HLXPROUPG Pro Logic Retrofit Kit, OmniPL Hayward Pro Logic Retrofit Kit, OmniPL, HLXPROUPG$1,99900 Web Price Hayward SP071620T 2 in. top mount backwash valve with clamp for Pro Series S310T and S310T2 Hayward 2" Top Mount Backwash Valve with Clamp, Fits Pro Series Sand Filters S310T / S310T2, SP071620T$26199 Hayward FDXLGSV0003 natural gas valve kit for Universal H-Series FD heaters Hayward Natural Gas Valve Kit, FD Series, FDXLGSV0003$41899

Questions and answers

What people ask about this product, answered by our pool techs.

Which cleaners does this upgrade?
Hayward PoolVac and Navigator suction side cleaners.
What is V-Flex?
A patented variable vane turbine. The vanes move to let larger debris pass instead of jamming, and the design keeps suction up across a range of flows.
What is in the kit?
The V-Flex turbine kit, a bearing free A-frame kit and retainer, four replacement shoes, two replacement wings and the suction inlet throat.
Does the concrete version matter?
Yes. This kit is the concrete surface version in white. Vinyl pools use a different shoe and wing set.
Ask your own question
