Sta-Rite 25010-0200 air relief valve assembly for PLD and PTM filter systemsSta-Rite Air Relief Valve Assembly for PLD and PTM Filter Systems, 25010-0200 In stock$4299
Sta-Rite 25010-0200 air relief valve assembly for PLD and PTM filter systems
Shop all Sta-Rite

Sta-Rite Air Relief Valve Assembly for PLD and PTM Filter Systems, 25010-0200

Ask a questionMPN 25010-0200
$4299
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Genuine part Factory air relief valve assembly, part number 25010-0200.
  • Complete assembly Supplied as the assembly rather than a loose stem or seal.
  • Bleeds trapped air Air pockets in the tank cut filtration and can pressurize the lid, so the relief valve has to open and close reliably.
  • PLD and PTM systems Listed for the Sta-Rite PLD and PTM filter systems.
  • Also listed for PLM and Posi-Flo II The same valve appears in the Posi-Flo II PTM and System 2 Modular Media PLM parts listings.
  • Common leak point A relief valve that drips at pressure or refuses to seat is a simple fix that stops an ongoing water loss.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Sta-Rite Air Relief Valve Assembly for PLD and PTM Filter Systems, 25010-0200, SKU STA-051-2720. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Sta-Rite Air Relief Valve Assembly for PLD and PTM Filter Systems, 25010-0200
Sta-Rite

Air Relief Valve Assembly for PLD and PTM Filter Systems, 25010-0200

$4299
Sta-Rite 170145 System 3 S7M120 Large and Small Cartridge Set, 25021-0200S and 25022-0201S
Pentair

Sta-Rite 170145 System 3 S7M120 Large and Small Cartridge Set, 25021-0200S and 25022-0201S

$46499
Filbur Sta-Rite S7D75 Full Filter Grid Set (11 Grids), FS-3037
Unicel Filter Cartridges

Filbur Sta-Rite S7D75 Full Filter Grid Set (11 Grids), FS-3037

$24599
Pentair Genuine OEM Valve Body O-Ring for Cristal-Flo II and Sand Dollar Filters, 272541
Pentair

Genuine OEM Valve Body O-Ring for Cristal-Flo II and Sand Dollar Filters, 272541

$1199
Pentair Genuine OEM Triton II Air Relief Tee Assembly, 154689Z
Pentair

Genuine OEM Triton II Air Relief Tee Assembly, 154689Z

$3499
Pentair Genuine OEM Sand Filter Drain Cap, 154712
Pentair

Genuine OEM Sand Filter Drain Cap, 154712

$3399
Sta-Rite 21 in. Filter Tank O-Ring, System 3, 24850-0008Z
Sta-Rite

21 in. Filter Tank O-Ring, System 3, 24850-0008Z

$7099
Subtotal

Similar products

Other products people compare with this one.

Sta-Rite 24800-0121 air bleed assembly for PLM model cartridge filters Sta-Rite Air Bleed Assembly for PLM Models, 24800-0121$2899 Sta-Rite 24800-0120 air bleed assembly for pool filters Sta-Rite Air Bleed Assembly, 24800-0120$3599 Sta-Rite WC9-3 black tank o-ring for Posi-Flo II PTM cartridge filters Sta-Rite Black Tank O-Ring for Posi-Flo II PTM Cartridge Filters, WC9-3$3999 Sta-Rite 35505-1425 bulkhead assembly o-ring, 3-3/4 inch inside diameter Sta-Rite O-Ring 3-3/4" ID, for Bulkhead Assembly, 35505-1425$2799 Sta-Rite 25021-0003 air bleed tube for System 3 cartridge filters Sta-Rite System 3 Cartridge Filter Air Bleed Tube, 25021-0003$2499 Sta-Rite 24900-0503 drain plug for System 3 filters Sta-Rite Drain Plug for System 3 Models, 24900-0503$3899 Sta-Rite 27001-0060S tank o-ring for filters built before 2/97 Sta-Rite O-Ring for Tank Before 2/97, 27001-0060S$6099 Sta-Rite 24900-0504 adapter bushing for System 3 filters Sta-Rite Adapter Bushing for System 3 Filters, 24900-0504$2799 Sta-Rite 24752-0050 bulkhead retaining nut for System 3 filter tanks Sta-Rite 4.5" x 1.25" Bulkhead Retaining Nut, 24752-0050$3799 Sta-Rite 24850-0105 air relief valve and pressure gauge assembly for System 3 filters Sta-Rite Valve and Gauge Assembly for System 3 Filters, 24850-0105$11099
Sta-Rite 27001-0030S upper tank shell half with air relief valve for System 2 PLM300 Sta-Rite Tank Upper Half with Air Relief Valve for System 2 PLM300, 27001-0030S$46999 Sta-Rite 24850-0200 clamp assembly for System 3 pool filters Sta-Rite Clamp Assembly For System 3 Filters, 24850-0200$13899 Sta-Rite 25021-0101 baffle and bulkhead fitting for System 3 cartridge filters Sta-Rite Baffle and Bulkhead Fitting for System 3 Cartridge Filters, 25021-0101$7699 Sta-Rite 25021-0100Z System:3 elbow and bulkhead assembly Sta-Rite System:3 Elbow and Bulkhead Assembly, 25021-0100Z$10599 Sta-Rite 35505-1424 adapter to tank O-ring, 2-3/8 inch inside diameter Sta-Rite O-Ring, 2-3/8" ID, Adapter to Tank, PLM/PLD, 35505-1424$1699 Sta-Rite 27001-0022 drain plug assembly, 1-1/2 inch Sta-Rite Drain Plug Assembly 1-1/2", 27001-0022$1599 Sta-Rite 24850-0009Z 25 in. filter tank O-ring for System 3 filters Sta-Rite 25 in. Filter Tank O-Ring, S8D110, 24850-0009Z$7699 Sta-Rite 35505-1429 O-ring for System 3 cartridge filters Sta-Rite O-Ring for System 3 Cartridge Filters, 35505-1429$1399 Sta-Rite U9-362 Buna-N union o-ring for 1-1/2 inch and 2 inch unions Sta-Rite Union O-Ring, 1-1/2 inch and 2 inch, U9-362$899 Sta-Rite 27001-0054S Posi-Lok position lock ring for System 2 modular filters Sta-Rite Position Lock Ring, Modular Filter, 27001-0054S$21699

Product details

The Sta-Rite 25010-0200 is the complete air relief valve assembly for PLD and PTM filter systems. The same valve is listed in the Posi-Flo II PTM and System 2 Modular Media PLM parts listings.

Why the filter needs it

Air gets into the tank every time the system is opened, primed or restarted. It gathers at the top, where it takes up volume that should be full of water. That means less media in contact with flow, less filtration for the same run time and a pressure gauge that no longer tells you the truth about the filter. Opening the relief valve on startup pushes that air out until water shows, and then it has to close and stay closed.

When to replace it

A valve that drips once the system is up to pressure, one that will not seat no matter how far it is turned, or one that has seized in place. Those are all wear at the seal and the seat, and they are fixed by changing the assembly rather than tightening it further.

Fitting

Shut the pump off and let the system pressure drop to zero before removing the old valve. Working on a pressurized filter is how lids and valve bodies get launched.

Specifications
Brand Sta-Rite
Manufacturer part number 25010-0200
UPC 788379828929
Type Air relief valve assembly
Fits Sta-Rite PLD and PTM filter systems
Also listed for Posi-Flo II PTM-50, PTM-70, PTM-100, PTM-135 and System 2 Modular Media PLM100, PLM150
Shipping weight 0.02 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Sta-Rite

Pentair 170145 cartridge pack for Sta-Rite System 3 S7M120, inner and outer cartridges Sta-Rite 170145 System 3 S7M120 Large and Small Cartridge Set, 25021-0200S and 25022-0201S$46499 Pentair 461105Z MasterTemp and Max-E-Therm six button control board kit Pentair Genuine OEM MasterTemp/Max-E-Therm 6-Button Control Board Kit, 461105Z$53899 Pentair 272568Z six position top mount clamp valve top assembly Pentair 6-Position Top Mount Clamp Valve Top Assembly, 272568Z$15199 Filbur FS-3037 full 11 grid set for the Sta-Rite System 3 S7D75 DE filter Filbur Sta-Rite S7D75 Full Filter Grid Set (11 Grids), FS-3037$24599 Sta-Rite 08428-0125 SwimQuip white inlet face plate and eyeball kit with screws Sta-Rite Face Plate Inlet Eyeball Kit with Screws, 08428-0125$3499 Sta-Rite 17307-0110S pump tank body assembly for IntelliPro and Max-E-Pro pumps Sta-Rite Pump Tank Body Housing Assembly, IntelliPro, 17307-0110S$30499 Sta-Rite 27002-0300S 300 square foot MOD media replacement filter module for the PLM300 Sta-Rite 300 Sq. Ft. Filter Replacement MOD Media, 27002-0300S$56999 Pentair 170147 large and small cartridge filter pack for the Sta-Rite System:3 S8M150 Pentair Sta-Rite S8M150 Large and Small Cartridge Filter Pack 25021-0202S & 25022-0203S, 170147$76799 Sta-Rite 27001-0020S System 2 black upper tank shell half Sta-Rite System 2 Tank Shell Upper Half, Black, 27001-0020S$28799 Sta-Rite 77707-0054 Max-E-Therm igniter with gasket kit Sta-Rite Max-E-Therm Igniter with Gasket Kit, 77707-0054$9499
Sta-Rite 178745Z 12.5 in. Posi-Clear RP replacement filter lid, top view Sta-Rite 150/200 Sq Ft Posi-Clear RP Replacement Lid, 12.5 in., 178745Z$15499 Sta-Rite C176-59PZ tank body assembly for Max-E-Glas II and Dura-Glas II pumps Sta-Rite Tank Body Assembly for Max-E-Glas II and Dura-Glas II, C176-59PZ$29699 Pentair 474957 combustion chamber assembly for Sta-Rite Max-E-Therm heaters Pentair Combustion Chamber Assembly for Max-E-Therm Heaters, 474957$37399 Pentair Sta-Rite 474061 cupro nickel tube sheet coil assembly kit for MasterTemp 400NA and 400LP Sta-Rite Tube Sheet Coil Assembly Kit for Model 400NA, 400LP MasterTemp Heater, 474061$1,22199 Sta-Rite C103-194PZ Max-E-Pro pump seal plate, front view Sta-Rite Max-E-Pro Seal Plate, C103-194PZ$7099 Sta-Rite 24850-0105 air relief valve and pressure gauge assembly for System 3 filters Sta-Rite Valve and Gauge Assembly for System 3 Filters, 24850-0105$11099 Pentair 08650-0022 hinged weir door assembly for Sta-Rite and SwimQuip U-3 skimmers Pentair Weir Assembly for Sta-Rite U-3 Skimmer, 08650-0022$3899 Pentair 154712 sand filter drain cap Pentair Genuine OEM Sand Filter Drain Cap, 154712$3399 Pentair 356893Z IntelliPro VSF drive kit with keypad, black Pentair IntelliPro VSF Drive Kit with Keypad, Black, 356893Z$1,22699 Sta-Rite 42001-0061S air flow switch for Max-E-Therm SR200, SR333 and SR400 heaters Sta-Rite Max-E-Therm Air Flow Switch, 42001-0061S$15799

Questions and answers

What people ask about this product, answered by our pool techs.

Which filters does this fit?
Sta-Rite lists it for the PLD and PTM filter systems. The same valve also appears in the Posi-Flo II PTM-50, 70, 100 and 135 and System 2 Modular Media PLM100 and PLM150 parts listings.
What does the air relief valve do?
It lets trapped air escape from the top of the filter tank. Air pushed into the tank on startup takes up space the water should occupy, so filtration drops and pressure readings become unreliable until it is bled out.
Mine drips constantly, is that normal?
No. A relief valve should hold once it is closed. A steady drip means the seat or the seal is worn, which is what this assembly replaces.
Is it a full assembly or just the seal?
It is the complete air relief valve assembly.
Ask your own question
