Hayward CZXELE7623 C-Spa heating element, 5500W 240VHayward C-Spa Heating Element, 5500W 240V, 5.5 kW, CZXELE7623 In stock$9899
Hayward CZXELE7623 C-Spa heating element, 5500W 240V
Shop all Hayward

Hayward C-Spa Heating Element, 5500W 240V, 5.5 kW, CZXELE7623

Ask a questionMPN CZXELE7623
$9899
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Rated 5500W at 240V The 5.5 kW element, so the replacement matches the original output.
  • C-Spa element Hayward part CZXELE7623, listed for the C-Spa electric heater.
  • Genuine Hayward The factory element rather than a generic coil cut to length.
  • Element only Supplied as the heating element. Gaskets, sensors and the housing are separate items.
  • Matched rating matters Fitting an element of a different wattage changes the load on the circuit and the heater control.
  • Common failure point Elements are the wear item in an electric spa heater and are replaced rather than repaired.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Hayward C-Spa Heating Element, 5500W 240V, 5.5 kW, CZXELE7623, SKU CFZ-151-1624. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Hayward C-Spa Heating Element, 5500W 240V, 5.5 kW, CZXELE7623
Hayward

C-Spa Heating Element, 5500W 240V, 5.5 kW, CZXELE7623

$9899
Hayward Heat Exchanger Assembly for H250FD, FDXLHXA1250
Hayward

Heat Exchanger Assembly for H250FD, FDXLHXA1250

$1,20799
Hayward Natural Gas Valve Kit, FD Series, FDXLGSV0003
Hayward

Natural Gas Valve Kit, FD Series, FDXLGSV0003

$41899
Hayward H-Series Bezel & Keypad Assembly, FDXLBKP1930
Hayward

H-Series Bezel & Keypad Assembly, FDXLBKP1930

$12299
Hayward HDF400 Thermistor, FDXLTER1931
Hayward

HDF400 Thermistor, FDXLTER1931

$5899
Hayward Flame Sensor, Low NOx/Universal, IDXLFLS1930
Hayward

Flame Sensor, Low NOx/Universal, IDXLFLS1930

$8899
Hayward Front Header Assembly, FDXLFHA1930
Hayward

Front Header Assembly, FDXLFHA1930

$30399
Subtotal

Similar products

Other products people compare with this one.

Coates Heater 5.5kW Element 240V for 6ILS Heater | 20005155 Coates 5.5 kW 240V Heating Element for 6ILS Series Electric Heaters, 20005155$10599 Coates 20005061 threaded heating element 5.5kW 240V with gasket Coates Electric Heater 5.5kW 240V Threaded Element with Gasket, 20005061$7099 Hayward CZXHLC3105 high limit switch for C-Spa XI Series heaters Hayward C-Spa XI Series High Limit Switch, CZXHLC3105$10999 Hayward FDXLBVS1930 blower vacuum switch for Universal H-Series Low NOx heaters Hayward Blower Vacuum Switch, FDXLBVS1930$4999 Raypak 015095F polymer return header for 206A, 266A, 336A and 406A heaters Raypak Polymer Return Header for 206A/266A/336A/406A Pool and Spa Heater, 015095F$13799 Hayward FDXLFWP1930 field wiring panel kit for Universal H-Series heaters Hayward Field Wiring Panel Kit, FD, FDXLFWP1930$9799 Hayward FDXLPRM1930 polymer return manifold for Universal H-Series and FD Series heaters Hayward Polymer Return Manifold, Universal H-Series and Low NOx FD Series Heaters, FDXLPRM1930$8499 Hayward FDXLIGN1930 Universal H-Series ignitor kit Hayward Universal H-Series Ignitor Kit, FDXLIGN1930$13099 Hayward IDXL2VPS1930 Low NOx air pressure switch Hayward Air Pressure Switch, Low NOx, After 09/04, IDXL2VPS1930$10299 Hayward FDXLTER1930 thermistor for Universal H-Series FD pool heaters Hayward Thermistor, FD, FDXLTER1930$5899
Hayward FDXLHLI1930 high limit kit for Universal H-Series Low NOx pool heaters Hayward High Limit Kit, FDXLHLI1930$7699 Hayward HAXNIP1930 CPVC flange pipe nipples for H-Series heaters, set of 2 Hayward CPVC Flange Pipe Nipples for H-Series, HAXNIP1930$6499 Hayward FDXLWPS1930 H-Series pressure switch Hayward H-Series Pressure Switch, FDXLWPS1930$5199 Hayward FDXLGSK1930 H-Series Low NOx air side gasket kit Hayward H-Series Low NOx Air Side Gasket Kit, FDXLGSK1930$9499 Hayward IDXLVPS1930 H-Series vent pressure switch Hayward H-Series Vent Pressure Switch, IDXLVPS1930$12799 Hayward HAXTLK1930 temperature limiter kit for H-Series pool heaters Hayward Temperature Limiter Kit, HAXTLK1930$11899 Hayward HAXTST1930 thermostat kit with knob for H-Series pool heaters Hayward Thermostat Kit, H-Series/Induced Draft, with Knob, HAXTST1930$9599 Hayward HAXFCT1930 flow control thermostat for H-Series pool heaters Hayward Flow Control Thermostat, HAXFCT1930$7999 Hayward HAXBRN1930 burner tube for H-Series pool heaters Hayward Burner Tube for H-Series Heaters, HAXBRN1930$12699 Hayward CHXTRF1930 dual voltage transformer for pool heaters Hayward Dual Voltage Transformer, CHXTRF1930$8599

Product details

The Hayward CZXELE7623 is the 5500 watt, 240V heating element, rated 5.5 kW, for the Hayward C-Spa electric spa heater. It is the Brand OEM element, supplied on its own.

Match the rating

Hayward lists the C-Spa XI 5.5 as a 240V, 5.5 kW heater producing 18,766 BTU per hour. Its owner manual rates it at 23 amps on a 30 amp breaker, with 1-1/2 inch water connections. The control and the circuit are sized to that load, so fit an element with the same wattage and voltage. A different wattage changes the current the heater draws.

Why elements fail

Hayward warns that an element can blister or burn off if the heater is powered while air sits around it. After you clean or change a cartridge filter, run the circulation system for at least five minutes to purge and bleed the air before power goes back on to the heater. Do that after fitting the new element as well.

What is included

The element only. Gaskets, sensors and the heater housing are separate items. Isolate power at the breaker and drain the heater before you open it.

Specifications
Brand Hayward
Manufacturer part number CZXELE7623
UPC 610377009140
Type Spa heater element
Power 5500W
Voltage 240V
Rating 5.5 kW
Shipping weight 1.7 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Hayward

This industry builds more than pools. We build moments. Hayward

Hayward equipment

Hayward Super Pump 1 HP Max Rated 115/230V, W3SP2607X10 Hayward AquaRite Salt System Complete, 40,000 Gallon Pools, W3AQR15 Hayward TracVac Suction Wall Climbing Pool Cleaner for In-ground Pools up to 40 ft, W3HSCTRACCU Hayward Pro-Grid 60 Sqft DE Pool Filter, Valve Not Included, W3DE6020
Shop Hayward equipment

Genuine Hayward parts

Hayward TurboCell T-15 Salt Cell for Inground Pools up to 40,000 Gallons, W3T-CELL-15 Hayward Genuine OEM SP1082 Skimmer Basket, SPX1082CA Hayward Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA Hayward H-Series Bezel & Keypad Assembly, FDXLBKP1930
Shop Hayward parts
Pool cleaners: Hayward TracVac and PoolCleaner suction cleaners lined up on a pool deckPool automation: the Hayward app on a phone held up in front of an infinity poolPool water features: two bubblers in a tiled spa, a woman relaxing on a lounger behind
Hayward makes pumps, filters, heaters, salt systems, cleaners, lighting and automation for residential pools.Shop all Hayward

Customer reviews

More from Hayward

Hayward SP0714T Vari-Flo XL 1.5 in. top mount multiport valve kit, front view Hayward Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit, SP0714T$15899 Hayward CL200EF in-line automatic pool chlorinator, 9 lb tablet feeder Hayward In-Line Automatic Pool Chlorinator, 9 lb Chemical Feeder, CL200EF$12999 Hayward GLX-CTL-RITE AquaRite salt system power center, control box only Hayward AquaRite Salt System Power Center (Requires Salt Cell), GLX-CTL-RITE$1,16900 Hayward SPX0714BA Vari-Flo XL valve key cover handle assembly for SP0714T Hayward Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA$14799 Hayward FDXLHXA1250 heat exchanger assembly for the H250FD Universal H-Series low NOx heater Hayward Heat Exchanger Assembly for H250FD, FDXLHXA1250$1,20799 Hayward TurboCell T-15 W3T-CELL-15 salt cell, replacement for AquaRite systems Hayward TurboCell T-15 Salt Cell for Inground Pools up to 40,000 Gallons, W3T-CELL-15$1,13499 Paralevel Startup Kit, part number 004-760-2921-00 Hayward Paralevel Startup Kit, 004-760-2921-00$5799 Hayward GLX-PCB-PRO main PCB for Goldline ProLogic and AquaPlus controls Hayward Main PCB Replacement for Goldline ProLogic Automation and Chlorination After 10/2008, GLX-PCB-PRO$1,07599 Hayward SP10841 Auto-Skim skimmer for vinyl and fiberglass pools, white with square lid Hayward Auto-Skim Skimmer for Vinyl/Fiberglass Pools, 1.5" FPT, Square Lid, White, SP10841$19299 Hayward SPX0714L cover o-ring for SP0714T Vari-Flo XL valve Hayward Cover O-Ring for SP0714T Vari-Flo XL Valve, SPX0714L$1899
Paramount 005422901500 two lamp UV kit with boot and o-ring for HydraPure and Ultra UV2 sanitizers Paramount 2-Lamp Kit with Boot and O-Ring for HydraPure and Ultra UV2 Sanitizers, 005422901500$26899 Hayward W3T-CELL-9 TurboCell T-9 salt cell with 15 ft cord Hayward TurboCell T-9 Salt Cell for Inground Pools up to 25,000 Gallons, Genuine AquaRite Replacement, W3T-CELL-9$89900 Web Price Hayward SP0710X62 Vari-Flo 1.5 in. side mount multiport valve for Pro Series sand filters Hayward Vari-Flo 1.5" Side Mount Multiport Valve for Sand Filters, SP0710X62$18899 Hayward SPX1082CA genuine OEM skimmer basket, 7 in. top diameter Hayward Genuine OEM SP1082 Skimmer Basket, SPX1082CA$2399 Hayward SPX1091Z7 1-1/2 in. combo hose adapter, 2 pack Hayward 1-1/2" Combo Hose Adapter for Filters, Pumps, Skimmers and Chlorine Feeders (2 Pack), SPX1091Z7$899 Hayward SPX0740BA key cover and handle assembly for SP740DE multiport valve Hayward OEM Key Cover and Handle Assembly for SP740DE, SPX0740BA$19799 Hayward CX200XRE 200 sq. ft. replacement filter cartridge for the SwimClear C200S Hayward Genuine OEM SwimClear C200S Filter Cartridge, CX200XRE$20299 Hayward HLXPROUPG Pro Logic Retrofit Kit, OmniPL Hayward Pro Logic Retrofit Kit, OmniPL, HLXPROUPG$1,99900 Web Price Hayward SP071620T 2 in. top mount backwash valve with clamp for Pro Series S310T and S310T2 Hayward 2" Top Mount Backwash Valve with Clamp, Fits Pro Series Sand Filters S310T / S310T2, SP071620T$26299 Hayward FDXLGSV0003 natural gas valve kit for Universal H-Series FD heaters Hayward Natural Gas Valve Kit, FD Series, FDXLGSV0003$41899

Questions and answers

What people ask about this product, answered by our pool techs.

What is the rating of this element?
5500 watts at 240 volts, which is the 5.5 kW rating.
Can I fit a different wattage element?
Match the original rating. A different wattage changes the current the heater draws and what the control and breaker were sized for.
Is this the genuine Hayward part?
Yes. It is Hayward part number CZXELE7623.
Does it include gaskets?
No. This listing is the element by itself.
Ask your own question
