Pentair 274494 valve adapter o-ring, 2-3/8 in. inside diameter, 3/16 in. cross sectionPentair O-Ring, Valve Adapter 2-3/8" ID, 3/16" Cross Section, 274494 In stock$599
Pentair 274494 valve adapter o-ring, 2-3/8 in. inside diameter, 3/16 in. cross section
Shop all Pentair

Pentair O-Ring, Valve Adapter 2-3/8" ID, 3/16" Cross Section, 274494

Ask a questionMPN 274494
$599
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Exact size 2-3/8 in. inside diameter, 3/16 in. cross section, the #2-332 size.
  • Wide fit Listed for the Tagelus filter, top and side mount valves, the FullFloXF backwash valve, FNS filters, Nautilus and Nautilus Plus DE filters.
  • Also called the bulkhead adapter o-ring The same ring appears under that name in Pentair parts listings.
  • Two part numbers Shown as 274494 and as 274494Z, both referring to this ring.
  • Seals the valve to the tank This is the joint between the valve adapter and the filter, and a hardened ring makes it weep under pressure.
  • Silicone lubricant only Petroleum grease swells the rubber and shortens the life of the seal.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Pentair O-Ring, Valve Adapter 2-3/8" ID, 3/16" Cross Section, 274494, SKU PAC-061-3050. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Pentair O-Ring, Valve Adapter 2-3/8" ID, 3/16" Cross Section, 274494
Pentair

O-Ring, Valve Adapter 2-3/8" ID, 3/16" Cross Section, 274494

$599
Pentair Genuine OEM High Flow Manual Air Relief Valve, 98209800
Pentair

Genuine OEM High Flow Manual Air Relief Valve, 98209800

$3999
Pentair Genuine OEM Clamp Kit with Tension Control, 190003
Pentair

Genuine OEM Clamp Kit with Tension Control, 190003

$31099
Pentair 2" Valve Kit Multiport, Side Mount DE Filters SM20-2, 261152
Pentair

2" Valve Kit Multiport, Side Mount DE Filters SM20-2, 261152

$30799
Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400
Pentair

Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400

$40599
Pentair OEM Tank O-Ring 20-7/8" ID (7/16" Thick), 39010200Z
Pentair

OEM Tank O-Ring 20-7/8" ID (7/16" Thick), 39010200Z

$6299
Pentair 60 Sq Ft Element Assembly Complete, 59023300
Pentair

60 Sq Ft Element Assembly Complete, 59023300

$45899
Subtotal

Similar products

Other products people compare with this one.

Pentair 192323 genuine OEM standpipe o-ring gasket Pentair Genuine OEM Standpipe O-Ring, 192323$799 Pentair 273513 rubber air bleeder screw o-ring for pool filters Pentair O-Ring for Air Bleeder, 273513$342 Pentair 154492 genuine OEM 2 inch bulkhead o-ring for pool filters Pentair Genuine OEM 2" Bulkhead O-Ring, 154492$1199 Pentair 273512Z Triton air bleeder with O-ring Pentair Triton Air Bleeder with O-Ring, 273512Z$1799 Pentair 59000600 FNS Plus stand pipe o-ring, size 2-137 Pentair FNS Plus Stand Pipe O-Ring, 59000600$1899 Pentair 195830 2 inch all purpose plug with o-ring for the FNS24 D.E. filter Pentair 2" FNS24 All Purpose Plug with O-Ring, 195830$2199 Pentair 195008 genuine OEM FNS tank o-ring for FNS D.E. filters Pentair Genuine OEM FNS Tank O-Ring, 195008$4599 Pentair 071442Z filter tank o-ring for 18 inch pool filter tank Pentair OEM Filter Tank O-Ring, 18 Inch Tank, 071442Z$5299 Pentair 190141 two inch DE filter bulkhead with o-ring Pentair Genuine OEM Filter Bulkhead with O-Ring, 190141$11099 Pentair 53004800Z stainless steel washer for Nautilus DE filter clamp Pentair Stainless Steel Washer, 7/8 in. OD for Nautilus DE Filter Clamp, 53004800Z$949
Pentair 192013 stainless steel nut, 5/16 inch-16, for PacFab FNS and Nautilus DE filters Pentair Genuine OEM Nut 5/16"-16 Stainless Steel, 4 Required, 192013$1299 Pentair 194988 clamp spring for Nautilus DE filter Pentair Clamp Spring for Nautilus DE Filter, 1-1/2 in. x 1-1/8 in., 194988$1355 Pentair 98725800 filter template for FNS Plus DE filters Pentair Template for FNS Plus Filter, 98725800$1399 Pentair 154412 internal bulkhead locknut, 2 inch Pentair Genuine OEM 2" Internal Bulkhead Locknut, 154412$1599 Pentair 194989Z machined metal nut for PacFab Nautilus DE filters Pentair Nut Machined, 194989Z$1799 Pentair 070428Z clamp bolt for Purex and Nautilus Plus stainless DE filters Pentair Clamp Bolt for Purex and Nautilus Plus Stainless DE Filters, 070428Z$1799 Pentair 76033 tank clamp knob for PacFab Nautilus DE filters Pentair Tank Clamp Knob, 76033$1899 Pentair 194997Z machined clamp nut for FNS, INS and Quad DE filters Pentair Genuine OEM Machined Nut, 194997Z$1999 Pentair 154747 spacer washer for PacFab Nautilus DE filters Pentair 154747 Genuine OEM Spacer Washer$2199 Pentair 172855 genuine OEM strainer air vent, 3/4 inch air relief screen Pentair Genuine OEM Strainer Air Vent, 172855$2999

Product details

The Pentair 274494 is the valve adapter o-ring, 2-3/8 in. inside diameter with a 3/16 in. cross section. Pentair also lists it as the bulkhead adapter o-ring, references it under the standard #2-332 size, and it appears in parts listings as 274494Z.

Where it goes

It seals the adapter joint between the valve and the filter tank. Pentair lists it for the Tagelus filter, top and side mount valves, the FullFloXF backwash valve, FNS filters, and the Nautilus and Nautilus Plus DE filters, which is why the same small ring turns up in so many different parts diagrams.

Why it fails

An o-ring is a round rubber gasket that is squeezed between two faces to hold pressure. Chlorine, heat and constant compression harden it and take the spring out of the rubber. Once it has taken a set it no longer fills its groove, and the joint begins to seep whenever the pump runs.

Fitting

Clean the groove and both sealing faces, seat the ring square without stretching it, and lubricate with a silicone based o-ring lubricant. Petroleum grease attacks the rubber and will cost you the new ring.

Specifications
Brand Pentair
Manufacturer part number 274494
Alternate part number 274494Z
UPC 788379695392
Type Valve adapter o-ring
Also called Bulkhead adapter o-ring
Size reference #2-332
Inside diameter 2-3/8 in.
Cross section 3/16 in.
Part type Pool pump part
Fits Pentair Tagelus filter, top and side mount valve, FullFloXF backwash valve, FNS filter, Nautilus, Nautilus Plus D.E.
Shipping weight 0.02 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Pentair

Your trusted source for all things pool. Pentair

Pentair equipment

Pentair SuperFlo VS 1.5 HP Variable Speed Pool Pump, EC-342001 Pentair MasterTemp 400 Natural Gas Pool Heater, EC-462028 Pentair Clean & Clear Plus 420 sq ft Cartridge Pool Filter, EC-160301 Pentair IntelliConnect Control & Monitoring System with Wi-Fi, EC-523317
Shop Pentair equipment

Genuine Pentair parts

Pentair Genuine OEM Seal Kit for WhisperFlo and IntelliFlo Pool Pumps, 356198 Pentair Genuine OEM High Flow Manual Air Relief Valve, 98209800 Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400 Pentair Genuine OEM MasterTemp/Max-E-Therm 6-Button Control Board Kit, 461105Z
Shop Pentair parts
Pool lighting: a backyard pool and spa lit in blue and green at nightPool water treatment: three people floating on rings in clear blue water, seen from abovePool cleaners: a toddler in flower sunglasses laughing in a yellow ring, held by her mother
Pentair makes pumps, filters, heaters, salt chlorinators, cleaners, lighting and automation for pools and spas.Shop all Pentair

Customer reviews

More from Pentair

Pentair SuperFlo VS EC-342001 1.5 HP variable speed pool pump, front view Pentair SuperFlo VS 1.5 HP Variable Speed Pool Pump, EC-342001$1,48900 Pentair SuperFlo EC-348190 single speed pool pump, 1 HP, 115/230V Pentair SuperFlo 1 HP Single Speed Pool Pump, 115/230V, EC-348190$74800 Pentair WhisperFlo VS EC-011533 2.6 THP variable speed pool pump, top view Pentair WhisperFlo VS 2.6 THP Variable Speed Pool Pump, 115/208-230V, EC-011533$1,79900 Pentair 262506 HiFlow 1.5 in. six way clamp style multiport valve Pentair Genuine OEM HiFlow Valve 1.5 in. 6-Way Clamp Style, 262506$20999 Pentair EC-520556 IntelliChlor 110/220V power center Pentair 110/220V IntelliChlor Salt Chlorine Generator Power Center, EC-520556$79900 Web Price Pentair 523769 IntelliChlor Plus and LT replacement sensor board Pentair IntelliChlor Plus and LT Replacement Sensor Board, 523769$40499 Pentair 350305S 3.2 kW 10 pole variable speed motor for IntelliFloXF and IntelliFlo 2 VST pumps Pentair 3.2 kW IntelliFloXF VSF, VSF, VS+SVRS, i1, i2 Motor, 350305S$78199 Pentair 523735-EC IntelliChlor Plus40 salt chlorine generator cell Pentair IntelliChlor Plus40 Salt Chlorine Generator Replacement Cell, 40,000 Gallons, 523735-EC$1,81900 Web Price Pentair Rainbow 320 in-line chlorinator R171096, front view Pentair Rainbow 320 In-Line Chlorinator, R171096$14999 Pentair 190003 tank clamp kit with tension control for Clean and Clear Plus, FNS Plus and Quad DE filters Pentair Genuine OEM Clamp Kit with Tension Control, 190003$31099
Pentair IntelliChlor LT25 salt chlorine generator cell 523747-EC Pentair IntelliChlor LT25 Salt Chlorine Generator Cell, 25,000 Gallons, 523747-EC$1,15699 Pentair IntelliFlo VS+SVRS variable speed pool pump, EC-011057 Pentair IntelliFlo VS+SVRS Variable Speed Pool Pump, EC-011057$2,39900 Pentair 170145 cartridge pack for Sta-Rite System 3 S7M120, inner and outer cartridges Sta-Rite 170145 System 3 S7M120 Large and Small Cartridge Set, 25021-0200S and 25022-0201S$47999 Pentair 261055 SM-20-3 2 in. side mount multiport valve kit, front view Pentair 2 in. Multiport Valve Kit for Side Mount Sand Filters, SM-20-3, 261055$30899 Pentair 523770 IntelliChlor Plus replacement controller (HMI), black Pentair IntelliChlor Plus Controller Replacement (HMI), Black, 523770$39599 Pentair 261152 SM20-2 2 in. side mount multiport valve kit for DE filters Pentair 2" Valve Kit Multiport, Side Mount DE Filters SM20-2, 261152$30799 Pentair 357149 WhisperFlo and IntelliFlo volute housing replacement kit, front view Pentair WhisperFlo and IntelliFlo Volute Housing Replacement Kit, 357149$29699 Pentair MicroBrite Color LED pool light EC-620425, 12 volt, 14 watt, with 100 ft cord Pentair MicroBrite Color LED Pool Light 12 Volt, 14 Watt with 100' Cord, EC-620425$61900 Pentair 59023400 FNS Plus 48 sq ft complete DE grid assembly Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400$40599 Pentair Amerlite EC-602128 500W 120V inground pool light with stainless steel facering Pentair Amerlite Pool Light for Inground Pools with Stainless Steel Facering, 500W 120V 50' Cord, EC-602128$43900 Web Price

Questions and answers

What people ask about this product, answered by our pool techs.

What size is this o-ring?
2-3/8 in. inside diameter with a 3/16 in. cross section, which is the standard #2-332 size.
Is the part number 274494 or 274494Z?
Both are used for this ring. The listing carries 274494 as the part number and 274494Z appears in Pentair parts references for the same o-ring.
Which equipment uses it?
It is listed for the Pentair Tagelus filter, top and side mount valves, the FullFloXF backwash valve, FNS filters, and Nautilus and Nautilus Plus DE filters.
My valve leaks at the tank. Is this the part?
It is where to start. The valve adapter o-ring hardens and flattens with age and stops sealing the joint. Clean the faces, fit a new ring with silicone lubricant, and if it still weeps look at the adapter itself.
