SuperPro 81060BU side mount pool filter pressure gauge with indicator needleSuperPro Side Mount Pressure Gauge with Indicator, 81060BU In stock$1799
SuperPro 81060BU side mount pool filter pressure gauge with indicator needle
Shop all American Granby

SuperPro Side Mount Pressure Gauge with Indicator, 81060BU

Ask a questionMPN 81060BU
$1799
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Side mount The fitting comes out of the bottom of the gauge, for valves and tanks with a downward facing 1/4 in. port.
  • Indicator needle Set it at clean filter pressure and the gap tells you when to backwash or clean the cartridge.
  • Fits most filters Used on Hayward Pro Series sand filters, Pentair Tagelus, Sta-Rite Cristal-Flo and System 2, Jacuzzi DVK-6 and DVK-7 valves and many more.
  • 1/4 in. fitting The common gauge size on pool filter valves and tanks.
  • Cheap insurance A dead or sticking gauge hides a dirty filter. Swap it as soon as the needle stops returning to zero.
  • Back mount version If your port faces sideways out of the valve rather than down, use the back mount gauge instead.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About SuperPro Side Mount Pressure Gauge with Indicator, 81060BU, SKU SPG-06-1001. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item SuperPro Side Mount Pressure Gauge with Indicator, 81060BU
American Granby

SuperPro Side Mount Pressure Gauge with Indicator, 81060BU

$1799
SuperPro Back Mount Pressure Gauge with Indicator, 80960BU
American Granby

SuperPro Back Mount Pressure Gauge with Indicator, 80960BU

$1399
Hayward SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit
Hayward

SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit

$15899
Hayward Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA
Hayward

Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA

$15299
DE Pool Filter Grid Replacement Set Complete
Filbur

DE Pool Filter Grid Replacement Set Complete

$10399
Jandy Replacement Bottom Tank Assembly for CL & DEV Model Filters, R0466500
Jandy

Replacement Bottom Tank Assembly for CL & DEV Model Filters, R0466500

$69499
Pentair Genuine OEM HiFlow Valve 1.5 in. 6-Way Clamp Style, 262506
Pentair

Genuine OEM HiFlow Valve 1.5 in. 6-Way Clamp Style, 262506

$20999
Subtotal

Similar products

Other products people compare with this one.

Pentair 190058 pool filter pressure gauge with indicator Pentair Genuine OEM Pressure Gauge with Indicator, 190058$1599 SuperPro O-429-9 generic tank o-ring for Hayward filters, replaces DEX2400K SuperPro Tank O-Ring (Generic) for Select Hayward Filters, O-429-9$1499 Hayward ECX1322A air relief valve with o-ring for pool filters Hayward Air Relief Valve with O-Ring, ECX1322A$1899 Hayward CCX1000V manual air relief assembly with o-ring Hayward Air Relief Assembly with O-Ring, CCX1000V$2599 Hayward CX250Z14A Star Clear 1/2 inch drain plug with O-ring Hayward Star Clear 1/2 in. Drain Plug with O-Ring, CX250Z14A$1899 Jacuzzi 4626-16 drain cap with gasket Jacuzzi Drain Cap with Gasket, 4626-16$1299 SuperPro 805-0268 volute housing o-ring, size 268 SuperPro Volute O-Ring #268, 805-0268$1299 SuperPro O-342-9 lid o-ring for Commander Series filters SuperPro Lid O-Ring for Commander Series Filters, O-342-9$1099 Waterway 600-0200 air release valve with o-ring for Pro Clean cartridge filters Waterway Air Release Valve with O-Ring, 600-0200$1099 Sta-Rite 32185-7074 drain cap with gasket for Posi-Clear cartridge filters Sta-Rite Drain Cap with Gasket for Posi-Clear Filters, 32185-7074$1399
Waterway 500-7310 screen and sock assembly with clamp for Clearwater filters Waterway Screen/Sock Assembly with Clamp, 500-7310$2099 SuperPro O-231V-9 lid o-ring listed for CLX200K SuperPro Lid O-Ring for CLX200K, O-231V-9$1299 SuperPro O-484-9 generic filter tank o-ring for Sta-Rite PLM filters SuperPro Generic Filter Tank O-Ring for Sta-Rite PLM, After 2/97, O-484-9$1599 Sta-Rite 24206-0103S air release valve with o-ring for PXC, System:2 PLDE and Posi-Clear filters Sta-Rite Air Release Valve with O-Ring for PXC, System:2 PLDE and Posi-Clear Filters, 24206-0103S$2199 SuperPro O-413-9 o-ring, 11-1/2 by 11-7/8 inches with a 3/16 inch cross section SuperPro O-Ring 11-1/2" x 11-7/8" x 3/16", O-413-9$1099 Waterway 519-7441 gauge lock-nut for Clearwater II filters Waterway Gauge Lock-Nut, 519-7441$2099 Waterway 417-2201 2 1/2 inch tailpiece with piston o-ring groove Waterway 2 1/2" Tailpiece with Piston O-Ring Groove, 417-2201$1199 SuperPro 79200400 GASKET NICHE 10 HOLE - PAPER | G-110-9 SuperPro 79200400 GASKET NICHE 10 HOLE - PAPER | G-110-9$1099 Hayward .75" Drain Plug with O-Ring GM Series | GMX152Z4A Hayward .75" Drain Plug with O-Ring GM Series | GMX152Z4A$1499 SuperPro WC9-3 O-RING BLACK | O-239-9 SuperPro WC9-3 O-RING BLACK | O-239-9$1299

Product details

The SuperPro 81060BU is a side mount pressure gauge for pool filters, with a 1/4 in. fitting on the bottom of the gauge and a set indicator needle on the face. It threads into the gauge port on sand, DE and cartridge filters and their multiport valves.

Why the indicator matters

A filter's clean pressure is the reading right after a backwash or cartridge clean. Set the indicator needle there and the gauge shows you how far pressure has climbed since. Once the live needle is 8 to 10 psi above the indicator, it is time to clean the filter, no notebook required.

Fit

Side mount means the stem comes out of the bottom, for ports that face down. It is the gauge found on Hayward Pro Series and S200 series sand filters, Pentair Tagelus, Sta-Rite Cristal-Flo and System 2 filters, Jacuzzi DVK-6 and DVK-7 dial valves and a long list of others. If your port faces sideways, the back mount version is the one you need.

Replace it when

The needle no longer drops to zero with the pump off, sticks, or the face has fogged. A gauge that reads wrong is worse than no gauge, because it lets a dirty filter go unnoticed.

Specifications
Brand SuperPro
Manufacturer part number 81060BU
UPC 729360610017
Type Pressure gauge with indicator
Mount Side (bottom)
Fitting 1/4 in.
Part type Pool filter part
Shipping weight 0.15 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from American Granby

Boss PLB103C clear silicone sealant, 3 oz. tube Boss Clear Silicone Sealant Tube, 3 oz., PLB103C$1599 SuperPro 80960BU 2 in. back mount pressure gauge with indicator SuperPro Back Mount Pressure Gauge with Indicator, 80960BU$1399 Poolguard PGRM-2 in-ground pool alarm with in-house remote receiver Poolguard PGRM-2 In-Ground Pool Alarm$25899 Aquamoto FullFlow 2 in. black PVC sweep 90 degree street elbow, slip by spigot Aquamoto FullFlow 2" PVC Sweep 90 Degree Street Elbow Slip x SPG, Black, 21006-004-000$1399 Maytronics 3883645 Dolphin robotic pool cleaner drive pulley bearing Maytronics Dolphin Drive Pulley Bearing, 3883645$2999 CMP FullFlow 21005-004-000 2 inch black PVC sweep 90 degree elbow, slip x slip CMP FullFlow 2" PVC Sweep 90 Degree Elbow Slip x Slip, Black, 21005-004-000$1399 SuperPro 25802-150-000 1-1/2 inch slip x slip PVC ball valve with union SuperPro 1-1/2" Slip x Slip PVC Ball Valve with Union, 25802-150-000$3099 Pentair 475002 3 inch PVC direct air intake duct kit for Sta-Rite Max-E-Therm heaters Pentair 3" PVC Direct Air Intake Duct Kit for Max-E-Therm Heater, 475002$32899 Pentair 600095 stainless steel IntelliBrite face ring assembly with clamp and gasket Pentair Stainless Steel IntelliBrite LED Pool Light Face Ring Assembly with Gasket, 600095$10599 Swimline Liberty pattern 12' round 54 inch uni-bead above ground pool liner Swimline 12' Round Liberty 54" Uni-Bead Liner, Heavy Gauge, LI1254LTU25z$40599
Coral Seas Yellow Out 4 lb chlorine shock enhancing pool treatment Coral Seas Yellow Out Swimming Pool Chlorine Shock Enhancing Treatment, 4 lbs, 17614COR$4099 American Granby HMIP150 replacement handle for a 1.5 inch ball valve American Granby Handle for 1.5 Inch Ball Valve, HMIP150 HANDLE$899 Pentair 360320 quick disconnect hose connector kit for Kreepy Krauly Racer cleaners Pentair Quick Disconnect Hose Connector Kit for Racer, 360320$1299 Infusion VRFTHBK black venturi return line inlet fitting Infusion Venturi Return Line Inlet Fitting, Black, VRFTHBK$2399 SuperPro HTST520-1/2 Teflon thread seal tape, 1/2 inch roll SuperPro Teflon Tape 1/2"$799 Marlig Industries Fix a Leak 32 oz bottle Marlig Industries Fix a Leak, 32 oz Bottle, FAL32$4699 American Granby HMIP200 replacement handle for a 2 inch ball valve American Granby Handle for 2" Ball Valve$1099 SuperPro 83060BU steel pressure gauge, 2 inch face, 60 psi, 1/4 inch bottom mount SuperPro Pressure Gauge, Steel, 2", 60 psi, 1/4" Bottom Mount, 83060BU$1499 American Granby HWP208 blue 1-1/2 inch winter pipe freeze plug with nylon wingnut American Granby 1-1/2" #8 Blue Winter Pipe Freeze Plug with Nylon Wingnut, HWP208$899 American Granby RFK18 rope and float kit with blue and white floats for 18 ft pools American Granby Rope and Float Kit for 18 ft Pools, RFK18$3199

Questions and answers

What people ask about this product, answered by our pool techs.

Will it fit my filter?
If your filter or valve has a downward facing 1/4 in. gauge port, yes. It is used across Hayward, Pentair, Sta-Rite, Jandy, Jacuzzi and Waterway sand, DE and cartridge filters. If the port faces out to the side, order the back mount version instead.
What is the indicator for?
It is a second needle you set by hand. Put it on the reading right after a backwash or cartridge clean; when the live needle climbs 8 to 10 psi above it, the filter needs cleaning.
Is a side mount gauge the same as a bottom mount gauge?
Yes. Side mount means the threaded stem comes out of the bottom of the gauge body, as opposed to a back mount gauge where the stem comes out of the back.
How do I know my old gauge is bad?
With the pump off it should read zero. If it stays up, bounces, or the needle is stuck, replace it.
