Product details

The Waterway Iron Might is a single speed circulation pump for spas and hot tubs, running on 115V with a 48 frame motor. It is the complete pump, model CP-1/8-1N11A.

Circulation, not jets

A circulation pump has a different job from a jet pump. It moves water quietly and continuously through the heater, the filter and any ozone or sanitizer equipment, around the clock. That is why the Iron Might delivers 40 GPM on only 1.3 amps: the priority is running all day at a cost you can ignore, not producing pressure at the jets.

The rating on the label

This pump carries two horsepower figures. It is listed at 1/15 HP and was previously sold as 1/8 HP. The output is the same, only the rating changed, so a pump bought under either number does the same work.

Build and plumbing

The housing uses a side discharge for better flow and easier routing at the pack, with 1-1/2 inch intake and discharge. Viton seals handle water carrying sanitizer and ozone better than standard materials. Union assemblies are available separately to suit different plumbing. The pump carries a one year warranty.

Specifications
Brand Waterway
Manufacturer part number 3410030-1E
UPC 806105066459
Model CP-1/8-1N11A
Type Iron Might circulation pump, single speed
Horsepower 1/15 HP, previously rated 1/8 HP with the same output
Voltage 115V
Frequency 60 Hz
Current 1.3 amps
Motor frame 48 frame
Flow 40 GPM
Intake and discharge 1-1/2"
Discharge position Side discharge
Seals Viton
Warranty One year
Shipping weight 13.55 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Waterway

Waterway 550-4407 Crystal Water filter tank body, gray, with label Waterway Tank Body, Crystal Water, Gray, with Label, 550-4407$45699 Waterway 310-6600 6 in. pump trap assembly with 2 in. x 2 in. ports, front view Waterway 6 in. Pump Trap Assembly, 2 in. x 2 in. Ports, 310-6600$7099 Waterway 550-0701B lock ring for Pro Clean Plus 125 and 150 sq ft filters Waterway Lock Ring, Pro Clean Plus, 550-0701B$9099 Waterway 522-5167-6S ClearWater II 150 sq. ft. cartridge filter system with 1.5 HP Hi-Flo II two speed pump Waterway 150 Sq. Ft. 1.5 HP 2 Speed Clearwater Cartridge Filter System, 522-5167-6S$89999 Waterway ClearWater II 520-5147-6S 100 sq ft cartridge filter system with 1.5 HP pump Waterway 100 SqFt ClearWater II Cartridge Filter System for Above Ground Pool 1.5HP, 520-5147-6S$74599 Waterway 542-3240 Renegade pool skimmer basket Waterway Renegade Pool Skimmer Basket, 542-3240$2199 Waterway 210-3700 poly gunite jet assembly with 1.5 inch by 2 inch tee body Waterway Poly Gunite Jet Assembly 1.5" x 2" Tee Body, 210-3700$2199 Waterway 210-3400 adjustable gunite spa jet Waterway Adjustable Spa Jet, Gunite, 210-3400$2999 Waterway 550-0621 tank lid with lock ring and pressure gauge for Pro Clean Plus 125 and 150 sq ft filters Waterway Tank Lid with Lock Ring, Pro Clean Plus 125/150 sq ft, 550-0621$25499 Waterway 218-1447 gray wall fitting escutcheon for vinyl liner pool returns Waterway Wall Fitting Escutcheon, Gray, for In-Ground Vinyl Liner Return Fittings, 218-1447$699
Waterway 229-8127 thread-in 5-scallop twin roto Poly Storm gunite jet internal in gray Waterway Thread-in 5-Scallop Twin Roto Poly Storm Gunite Jet Internal, Gray, 229-8127$1999 Waterway 805-0000 Crystal Water filter tank o-ring Waterway Crystal Water Tank O-Ring, 805-0000$3299 Waterway 400-4030 1-1/2 inch union, male pipe thread by female slip Waterway 1-1/2" x 1-1/2" S Union MPT, 400-4030$1599 Waterway 540-8500 Renegade wide mouth vinyl liner skimmer, 9 in. throat, white Waterway Complete Renegade Vinyl Skimmer, Wide Mouth, 9 in. Throat, White, 540-8500$16299 Waterway 640-1900 V 10 inch Tru Flo cover and frame in white Waterway 10" Tru Flo Cover and Frame, White, 640-1900 V$3899 Waterway 505-1970 filter collar valve wrench for split-nut threaded sand filters Waterway Filter Collar Valve Wrench, 505-1970$1999 Waterway 210-6090 Roto Deluxe Jet in white Waterway Roto Deluxe Jet, White, 210-6090$3299 Waterway 600-9600 valve lid diverter assembly with spider gasket Waterway Lid Diverter Assembly with Gasket, 600-9600$9699 Waterway 400-5080 2 in. union, male pipe thread by female slip Waterway 2" Union, Male Pipe Thread by Female Slip, 400-5080$1899 Waterway 640-4740 V universal grate, 12 in. x 12 in., white Waterway Universal Grate, 12 in. x 12 in., White, 640-4740 V$6699

Questions and answers

What people ask about this product, answered by our pool techs.

Is it 1/15 HP or 1/8 HP?
Both numbers appear on this pump. It is listed at 1/15 HP and was previously rated 1/8 HP, with the same output either way. Nothing about the pump changed, only the rating.
How much power does it use?
1.3 amps at 115V, which is what allows it to run continuously without a meaningful hit on the power bill.
What size are the connections?
1-1/2 inch on both the intake and the discharge, and union assemblies are available separately.
Is this a jet pump?
No. It is a circulation pump, built for continuous low draw flow through the heater and filter. It does not have the output to drive spa jets.
