Pentair 85002300 skimmer extension collar for ring seatPentair Extension Collar for Ring Seat, 85002300 In stock$2099
Pentair 85002300 skimmer extension collar for ring seat
Shop all Pentair

Pentair Extension Collar for Ring Seat, 85002300

Ask a questionMPN 85002300
$2099
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Raises the ring seat Lifts the skimmer collar and lid up toward the finished deck level.
  • Stacks Each additional extension collar adds 2" to the total height of the stack.
  • 3" tall on its own Total height of a single collar is 3", tapering from a 9-3/8" top outside diameter to a 9" bottom.
  • Stepped to nest The bottom section is 1-7/8" tall on the outside and 2" on the inside, the top section 1-1/8" outside and 1" inside, which is what lets collars stack.
  • For Admiral skimmers Listed with the Pentair American Products Admiral in ground skimmer parts.
  • Genuine Pentair Factory part 85002300.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Pentair Extension Collar for Ring Seat, 85002300, SKU AMP-251-1267. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Pentair Extension Collar for Ring Seat, 85002300
Pentair

Extension Collar for Ring Seat, 85002300

$2099
Pentair Three Port Diverter Valve 2" x 2.5", 263028
Pentair

Three Port Diverter Valve 2" x 2.5", 263028

$5799
Pentair Chemical Resistant 1-1/2" x 2" Check Valve, R172288
Pentair

Chemical Resistant 1-1/2" x 2" Check Valve, R172288

$7499
Pentair Sinking Pool Water Thermometer with ABS Case and 3-Foot Cord, R141036
Pentair

Sinking Pool Water Thermometer with ABS Case and 3-Foot Cord, R141036

$1699
Pentair Replacement Handle for FullFloXF Backwash Valve, 270187Z
Pentair

Replacement Handle for FullFloXF Backwash Valve, 270187Z

$5099
Pentair 2 in. Multiport Valve Diverter Gasket, 271148Z
Pentair

2 in. Multiport Valve Diverter Gasket, 271148Z

$3699
Pentair Genuine OEM Six-Way HiFlow Valve Clamp with Screw and Nut, 152165
Pentair

Genuine OEM Six-Way HiFlow Valve Clamp with Screw and Nut, 152165

$3099
Subtotal

Similar products

Other products people compare with this one.

Pentair 85000600 Admiral skimmer ring seat assembly, 9 inch plastic ring Pentair Admiral Skimmer Ring Seat Assembly, 85000600$2099 Waterway 519-6560 skimmer extension ring collar for Renegade VL skimmers Waterway Skimmer Extension Ring Collar, 519-6560$1999 Pentair 513031 ring for lid, skimmer lid seat ring Pentair Ring for Lid, 513031$2799 CMP 25526-000-000 4 in. skimmer extension collar for Sta-Rite SwimQuip U-3 skimmers CMP 4 in. Skimmer Extension Collar for Sta-Rite SwimQuip U-3 Skimmers, Replaces WC37-503P, 25526-000-000$1299 Pentair 516259 white extra deep deck collar for Bermuda pool skimmers Pentair White Extra Deep Deck Collar for Bermuda Pool Skimmers, 516259$2199 Pentair R36031 90 degree elbow assembly for R211100 Vac-Mate Pentair Elbow Assembly for R211100 Vac-Mate, R36031$1399 Pentair R36033 retainer bar for the R211100 Vac-Mate vacuum skimmer attachment Pentair Retainer Bar for R211100 Vac-Mate, R36033$1499 Pentair R38013B circular floating weir for Admiral S10 in-ground skimmers Pentair OEM Floating Weir for Admiral Skimmers, R38013B$2499 Waterway 519-6570 Skim-Pro pool skimmer lid extension ring Waterway Skim-Pro Pool Skimmer Extension Ring, 519-6570$1399 Pentair 513352 weir door for HydroSkim skimmers Pentair Weir Door for HydroSkim Skimmers, 513352$1299
SkimPro SP-HP-1080 skimmer basket with vented tower and handle for Hayward 1080 skimmers SkimPro Skimmer Basket with Vented Tower for Hayward® 1080 Skimmers, SP-HP-1080$2499 Pentair 08650-0007Z U-3 skimmer basket with handle Pentair U-3 Skimmer Basket with Handle, 08650-0007Z$2199 Hayward SPX1091C skimmer basket with handle for the SP1091 skimmer Hayward Basket with Handle for SP1091 Skimmer, SPX1091C$2199 Hayward SP1084F white snap-on face plate cover for SP1084 skimmers Hayward Snap-On Face Plate Cover for SP1084 Skimmers, White, SP1084F$1899 Aladdin B-38 replacement part for the Pentair S-10 Admiral skimmer Aladdin Pentair S-10 Admiral Skimmer Basket Floating Weir$2099 Aquador 1090 skimmer winterizing face plate and cover for Hayward SP1090 Aquador Face Plate and Cover for Winterizing Pools, Compatible with Hayward® SP1090 Skimmers$2699 Jedco AGL150 Lid'l Seal winterizing lid for the AG150 skimmer Jedco Lid'l Seal Replacement Lid for AG150, AGL150$1799 Hayward SPX1084L skimmer face plate for SP1076 and SP1084 Auto-Skim vinyl skimmers Hayward CYC Face Plate for SP1076 and SP1084 Skimmers, SPX1084L$2099 Hayward SPX1096A2 skimmer basket support ring for SP1090 and SP1092 skimmers Hayward Skimmer Basket Support Ring, SPX1096A2$1399 Hayward SPX1082D plastic skimmer basket support ring Hayward Basket Support Ring, SPX1082D$1399

Product details

This is the Pentair 85002300 extension collar for the ring seat, the piece that lifts an Admiral in ground skimmer up to meet the finished deck. Each collar stands 3" tall on its own, and each one added to a stack raises the total height by 2".

The measurements

The top measures 9-3/8" on the outside and 9-1/8" on the inside. The bottom measures 9" outside and 8-3/4" inside. The stepped profile is what makes stacking work: the bottom section is 1-7/8" tall on the outside and 2" on the inside, and the top section is 1-1/8" outside and 1" inside.

When you need one

Deck work, a new pour, a lifted coping course or a skimmer that ended up sitting low all leave the ring seat below the surface it is supposed to finish flush with. Collars are the fix, and because they stack in 2" steps, an installation that is off by more than one collar can still be brought up to level. Measure your existing ring seat against the diameters above before ordering.

Specifications
Brand Pentair
Manufacturer part number 85002300
UPC 788379625498
Type Extension collar for ring seat
Top outside diameter 9-3/8"
Top inside diameter 9-1/8"
Bottom outside diameter 9"
Bottom inside diameter 8-3/4"
Total height 3"
Bottom section height 1-7/8" outside, 2" inside
Top section height 1-1/8" outside, 1" inside
Stacking Each extension collar adds 2" to the total height of the stack
Fits Pentair American Products Admiral in ground skimmer
Shipping weight 0.45 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Pentair

Your trusted source for all things pool. Pentair

Pentair equipment

Pentair SuperFlo VS 1.5 HP Variable Speed Pool Pump, 2.2 THP, EC-342001 Pentair MasterTemp 400 Natural Gas Pool Heater, EC-462028 Pentair Clean & Clear Plus 420 sq ft Cartridge Pool Filter, EC-160301 Pentair IntelliConnect Control & Monitoring System with Wi-Fi, EC-523317
Shop Pentair equipment

Genuine Pentair parts

Pentair Genuine OEM Seal Kit for WhisperFlo and IntelliFlo Pool Pumps, 356198 Pentair Genuine OEM High Flow Manual Air Relief Valve, 98209800 Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400 Pentair Genuine OEM MasterTemp/Max-E-Therm 6-Button Control Board Kit, 461105Z
Shop Pentair parts
Pool lighting: a backyard pool and spa lit in blue and green at nightPool water treatment: three people floating on rings in clear blue water, seen from abovePool cleaners: a toddler in flower sunglasses laughing in a yellow ring, held by her mother
Pentair makes pumps, filters, heaters, salt chlorinators, cleaners, lighting and automation for pools and spas.Shop all Pentair

Customer reviews

More from Pentair

Pentair SuperFlo VS EC-342001 1.5 HP variable speed pool pump, front view Pentair SuperFlo VS 1.5 HP Variable Speed Pool Pump, 2.2 THP, EC-342001$1,48900 Pentair SuperFlo EC-348190 single speed pool pump, 1 HP, 115/230V Pentair SuperFlo 1 HP Single Speed Pool Pump, 1.1 THP, 115/208-230V, EC-3481905.0 (1) $74800 Pentair WhisperFlo VS EC-011533 2.6 THP variable speed pool pump, top view Pentair WhisperFlo VS / VST 2.6 THP Variable Speed Pool Pump, 115/208-230V, EC-011533$1,79900 Pentair 262506 HiFlow 1.5 in. six way clamp style multiport valve Pentair Genuine OEM HiFlow Valve 1.5 in. 6-Way Clamp Style, 262506$20399 Pentair EC-520556 IntelliChlor 110/220V power center Pentair 110/220V IntelliChlor Salt Chlorine Generator Power Center, EC-520556$79900 Web Price Pentair 523769 IntelliChlor Plus and LT replacement sensor board Pentair IntelliChlor Plus and LT Replacement Sensor Board, 523769$39399 Pentair 350305S 3.2 kW 10 pole variable speed motor for IntelliFloXF and IntelliFlo 2 VST pumps Pentair 3.2 kW IntelliFloXF VSF, VSF, VS+SVRS, i1, i2 Motor, 350305S$78199 Pentair 523735-EC IntelliChlor Plus40 salt chlorine generator cell Pentair IntelliChlor Plus40 Salt Chlorine Generator Replacement Cell, 40,000 Gallons, 523735-EC$1,81900 Web Price Pentair Rainbow 320 in-line chlorinator R171096, front view Pentair Rainbow 320 In-Line Chlorinator, R171096$14699 Pentair 190003 tank clamp kit with tension control for Clean and Clear Plus, FNS Plus and Quad DE filters Pentair Genuine OEM Clamp Kit with Tension Control, 190003$30199
Pentair IntelliChlor LT25 salt chlorine generator cell 523747-EC Pentair IntelliChlor LT25 Salt Chlorine Generator Cell, 25,000 Gallons, 523747-EC$1,14900 Pentair IntelliFlo VS+SVRS variable speed pool pump, EC-011057 Pentair IntelliFlo VS+SVRS Variable Speed Pool Pump, 3 HP Max, 3.95 THP, 230V, EC-011057$2,39900 Pentair 170145 cartridge pack for Sta-Rite System 3 S7M120, inner and outer cartridges Sta-Rite 170145 System 3 S7M120 Large and Small Cartridge Set, 25021-0200S and 25022-0201S$48299 Pentair 261055 SM-20-3 2 in. side mount multiport valve kit, front view Pentair 2 in. Multiport Valve Kit for Side Mount Sand Filters, SM-20-3, 261055$29999 Pentair 523770 IntelliChlor Plus replacement controller (HMI), black Pentair IntelliChlor Plus Controller Replacement (HMI), Black, 5237705.0 (1) $38399 Pentair 261152 SM20-2 2 in. side mount multiport valve kit for DE filters Pentair 2" Valve Kit Multiport, Side Mount DE Filters SM20-2, 261152$29799 Pentair 357149 WhisperFlo and IntelliFlo volute housing replacement kit, front view Pentair WhisperFlo and IntelliFlo Volute Housing Replacement Kit, 357149$28799 Pentair MicroBrite Color LED pool light EC-620425, 12 volt, 14 watt, with 100 ft cord Pentair MicroBrite Color LED Pool Light 12 Volt, 14 Watt with 100' Cord, EC-620425$61900 Pentair 59023400 FNS Plus 48 sq ft complete DE grid assembly Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400$40199 Pentair Amerlite EC-602128 500W 120V inground pool light with stainless steel facering Pentair Amerlite Pool Light for Inground Pools with Stainless Steel Facering, 500W 120V 50' Cord, EC-602128$43900 Web Price

Questions and answers

What people ask about this product, answered by our pool techs.

How much height does one collar add?
A single collar is 3" tall overall, and each extension collar added to a stack raises the total height by 2".
Can I stack more than one?
Yes. The collars are made to stack, with each one adding 2" to the total height.
What are the diameters?
The top measures 9-3/8" outside and 9-1/8" inside. The bottom measures 9" outside and 8-3/4" inside.
Which skimmer is it for?
It is listed with the Pentair American Products Admiral in ground skimmer parts. Measure your existing ring seat against the diameters above before ordering.
