The Pentair 476223Z is the ignition control module replacement kit for Pentair MasterTemp and Sta-Rite Max-E-Therm pool heaters. It is the genuine Pentair part, also listed under the earlier number 476223.

What the module does

The ignition control module runs the heater's lighting sequence: it confirms the safeties are satisfied, energizes the igniter, opens the gas valve and watches for flame. When it fails, the heater typically runs the blower and then locks out without ever firing.

Diagnosing before you buy

A no-ignition fault can also come from the igniter, the air flow switch, the terminal board or the gas supply. Rule those out first; if the sequence stalls at the module, this kit is the fix.

Specifications
Brand Pentair
Manufacturer part number 476223Z
Also listed as 476223
UPC 788379888237
Type Ignition control module replacement kit
Fits Pentair MasterTemp and Sta-Rite Max-E-Therm heaters
Shipping weight 2 lb
Ships Parcel
