Waterway 310-4200 Executive 3 HP pool pump impellerWaterway Executive 3 HP Impeller, 310-4200 In stock$3299
Waterway 310-4200 Executive 3 HP pool pump impeller
Shop all Waterway

Waterway Executive 3 HP Impeller, 310-4200

Ask a questionMPN 310-4200
$3299
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Genuine Waterway part The factory 310-4200 impeller, not a generic copy.
  • Sized for 3 HP Waterway builds a different impeller for each Executive horsepower, and this is the 3 HP one.
  • Executive series Listed on both the 48 frame and the 56 frame Executive pump breakdowns.
  • Restores lost flow Worn or chipped vanes bleed off head pressure long before the motor sounds unhealthy.
  • Threads onto the motor shaft The impeller screws onto the shaft behind the seal plate, so the shaft seal is worth replacing at the same time.
  • Correct horsepower matters Fitting the wrong impeller changes the flow curve and can overload or underwork the motor.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Waterway Executive 3 HP Impeller, 310-4200, SKU WWP-85-4200. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Waterway Executive 3 HP Impeller, 310-4200
Waterway

Executive 3 HP Impeller, 310-4200

$3299
Waterway 6 in. Pump Trap Assembly, 2 in. x 2 in. Ports, 310-6600
Waterway

6 in. Pump Trap Assembly, 2 in. x 2 in. Ports, 310-6600

$7099
Waterway 3/8" Drain Plug, Black, 715-1201
Waterway

3/8" Drain Plug, Black, 715-1201

$499
Waterway Hi-Flo Pump Drain Plug O-Ring, 805-0111
Waterway

Hi-Flo Pump Drain Plug O-Ring, 805-0111

$399
Waterway Pump Union, 2" Nut x 1-1/2" Slip or 2" Spigot, 400-9230
Waterway

Pump Union, 2" Nut x 1-1/2" Slip or 2" Spigot, 400-9230

$799
Waterway O-Ring for 6" Trap Cover, 805-0436
Waterway

O-Ring for 6" Trap Cover, 805-0436

$799
Waterway Union Gasket 2", 711-4010
Waterway

Union Gasket 2", 711-4010

$1099
Subtotal

Similar products

Other products people compare with this one.

Waterway 310-4180 Executive 5 HP closed face impeller Waterway Executive 5 HP Impeller, 310-4180$3299 Waterway 310-4190 4 HP impeller for Executive pool pumps Waterway 4 HP Impeller, 310-4190$3299 Waterway 310-4010 impeller for the 1-1/2 HP Hi Flo pump Waterway Impeller 1.5HP (Hi Flo), 310-4010$3199 Waterway 310-4030 impeller for the 2 HP Hi Flo pump Waterway Impeller 2HP Hi Flo, 310-4030$2699 Waterway 310-8030 1.5 HP E-Series impeller Waterway 1.5 HP E-Series Impeller, 310-8030$3699 Waterway 310-3990 3/4 HP impeller for Hi-Flo pool pumps Waterway Impeller 3/4 HP Hi-Flo, 310-3990$3099 Waterway WATERWAYS IMPELLER, 1HP, HI-FLO "C" | 310-4000 Waterway WATERWAYS IMPELLER, 1HP, HI-FLO "C" | 310-4000$2899 Waterway Waterways Face Plate Executive | 311-1210 Waterway Waterways Face Plate Executive | 311-1210$4099 Waterway 315-1240 volute with inserts for Executive 48-Frame pump Waterway Executive Volute with Inserts for 48-Frame Pump Wet Ends, 315-1240$2399 Hayward SPX3021R impeller ring, 2-3/4 in. OD, for 3/4 to 3 HP pumps Hayward 3/4 HP to 3 HP Impeller Ring, 2-3/4 in. OD, SPX3021R$1799
Polaris R0536400 impeller for the PB4-60 new style booster pump Polaris Genuine Replacement PB4-60 Booster Pump Impeller, R0536400$3499 Polaris P15 3/4 hp impeller for old style PB4-60 booster pump Polaris Genuine OEM Booster Pump Impeller, Old Style PB4-60$4199 Jandy R0446500 diffuser and impeller hardware O-ring kit Jandy Diffuser and Impeller Hardware O-Ring Kit, R0446500$3799 Hayward SPX3005R impeller ring, 2-3/8 in. outside diameter, for Super II pumps Hayward 0.75 HP to 1.5 HP Impeller Ring, 2-3/8 in. OD, SPX3005R$1699 Jandy R0515400 reverse thread impeller screw with O-ring Jandy Impeller Screw with O-Ring, R0515400$1699 Pentair LA05LZ new style impeller for the Letro booster pump Pentair New Style Impeller, Letro Booster Pump, LA05LZ$4499 Sta-Rite 37337-6080 impeller screw for Dyna-Pro pumps Sta-Rite Impeller Screw for Dyna-Pro, 37337-6080$3399 Waterway 319-4100 new style 6 inch easy lock pump trap lid assembly Waterway 6" Trap Lid, Easy Lock, New Style, 319-4100$4099 Waterway 319-3260 old style 6 inch trap easy lock pump lid Waterway 6" Trap Easy Lock Lid, 319-3260$4199 Waterway 319-2170 six inch pump trap body with 1-1/2 inch FPT inlet Waterway Trap Body 1.5" FPT / 1.5" x 2" Union, 319-2170$4599

Product details

The Waterway 310-4200 is the 3 HP impeller for the Executive pump. It is the genuine Waterway part and appears on both the 48 frame and 56 frame Executive breakdowns.

What the impeller does

The impeller is the only moving part in the wet end. It spins with the motor shaft and throws water outward, and its vane profile is what produces the flow and the head pressure the rest of the system depends on. Vanes wear, chip and pack with grit, and the loss is gradual, so a pool that once turned over easily quietly stops keeping up.

Match the horsepower

Waterway uses a different impeller for each Executive horsepower rating. This one is the 3 HP part. Putting a mismatched impeller on a motor changes where the pump sits on its curve, so confirm the rating on the pump before ordering.

While the wet end is open

The impeller threads onto the motor shaft in front of the shaft seal, and the seal has to be disturbed to remove it. Replacing the seal during the same teardown saves opening the pump twice.

From Pool School

How to Prime a Pool PumpFrom the breaker to a full pot, each manufacturer's time limit, and what to check when it won't catch prime. Read Replace the Pool Pump Motor or the Whole Pump?The manufacturers' tests first, what each repair replaces, and the federal motor rule. Read
Specifications
Brand Waterway
Manufacturer part number 310-4200
UPC 806105063342
Type Pump impeller
Horsepower 3 HP
Series Waterway Executive
Fits Waterway Executive 48 frame and 56 frame pumps
Shipping weight 0.3 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Waterway

A Waterway pump and filter on an equipment pad beside an infinity pool. Engineered for pool, spa and bath. Waterway

Waterway equipment

Waterway Power Defender Variable Speed Pump 1.65HP 230V, PD-165 Waterway 150 Sq. Ft. 1.5 HP 2 Speed Clearwater Cartridge Filter System, 522-5167-6S Waterway Complete Renegade Vinyl Skimmer, Wide Mouth, 9 in. Throat, White, 540-8500 Waterway 3/4 HP Booster Pump, SG3810430-1PDA
Shop Waterway equipment

Waterway parts

Waterway Renegade Pool Skimmer Basket, 542-3240 Waterway 6 in. Pump Trap Assembly, 2 in. x 2 in. Ports, 310-6600 Waterway Adjustable Spa Jet, Gunite, 210-3400 Waterway Poly Gunite Jet Assembly 1.5" x 2" Tee Body, 210-3700
Shop Waterway parts
Pool filters: a Waterway cartridge filter and pumpFittings and valves: a white Waterway PVC fitting
Waterway makes pumps, filters, skimmers, jets, valves and fittings for pools, spas and baths.Shop all Waterway

Customer reviews

More from Waterway

Waterway 550-4407 Crystal Water filter tank body, gray, with label Waterway Tank Body, Crystal Water, Gray, with Label, 550-4407$45699 Waterway 310-6600 6 in. pump trap assembly with 2 in. x 2 in. ports, front view Waterway 6 in. Pump Trap Assembly, 2 in. x 2 in. Ports, 310-6600$7099 Waterway 550-0701B lock ring for Pro Clean Plus 125 and 150 sq ft filters Waterway Lock Ring, Pro Clean Plus, 550-0701B$9099 Waterway 522-5167-6S ClearWater II 150 sq. ft. cartridge filter system with 1.5 HP Hi-Flo II two speed pump Waterway 150 Sq. Ft. 1.5 HP 2 Speed Clearwater Cartridge Filter System, 522-5167-6S$89999 Waterway ClearWater II 520-5147-6S 100 sq ft cartridge filter system with 1.5 HP pump Waterway 100 SqFt ClearWater II Cartridge Filter System for Above Ground Pool 1.5HP, 520-5147-6S$74599 Waterway 542-3240 Renegade pool skimmer basket Waterway Renegade Pool Skimmer Basket, 542-3240$2199 Waterway 210-3700 poly gunite jet assembly with 1.5 inch by 2 inch tee body Waterway Poly Gunite Jet Assembly 1.5" x 2" Tee Body, 210-3700$2199 Waterway 210-3400 adjustable gunite spa jet Waterway Adjustable Spa Jet, Gunite, 210-3400$3199 Waterway 550-0621 tank lid with lock ring and pressure gauge for Pro Clean Plus 125 and 150 sq ft filters Waterway Tank Lid with Lock Ring, Pro Clean Plus 125/150 sq ft, 550-0621$25499 Waterway 218-1447 gray wall fitting escutcheon for vinyl liner pool returns Waterway Wall Fitting Escutcheon, Gray, for In-Ground Vinyl Liner Return Fittings, 218-1447$699
Waterway 229-8127 thread-in 5-scallop twin roto Poly Storm gunite jet internal in gray Waterway Thread-in 5-Scallop Twin Roto Poly Storm Gunite Jet Internal, Gray, 229-8127$1999 Waterway 805-0000 Crystal Water filter tank o-ring Waterway Crystal Water Tank O-Ring, 805-0000$3299 Waterway 400-4030 1-1/2 inch union, male pipe thread by female slip Waterway 1-1/2" x 1-1/2" S Union MPT, 400-4030$1399 Waterway 540-8500 Renegade wide mouth vinyl liner skimmer, 9 in. throat, white Waterway Complete Renegade Vinyl Skimmer, Wide Mouth, 9 in. Throat, White, 540-8500$16299 Waterway 640-1900 V 10 inch Tru Flo cover and frame in white Waterway 10" Tru Flo Cover and Frame, White, 640-1900 V$3899 Waterway 505-1970 filter collar valve wrench for split-nut threaded sand filters Waterway Filter Collar Valve Wrench, 505-1970$2199 Waterway 210-6090 Roto Deluxe Jet in white Waterway Roto Deluxe Jet, White, 210-6090$3299 Waterway 600-9600 valve lid diverter assembly with spider gasket Waterway Lid Diverter Assembly with Gasket, 600-9600$9699 Waterway 400-5080 2 in. union, male pipe thread by female slip Waterway 2" Union, Male Pipe Thread by Female Slip, 400-5080$1399 Waterway 640-4740 V universal grate, 12 in. x 12 in., white Waterway Universal Grate, 12 in. x 12 in., White, 640-4740 V$6699

Questions and answers

What people ask about this product, answered by our pool techs.

Which pump does this fit?
The Waterway Executive at 3 HP. It appears on both the Executive 48 frame and Executive 56 frame parts breakdowns.
Can I use it on a different horsepower Executive?
No. Waterway matches the impeller to the horsepower, so a 3 HP impeller belongs on a 3 HP pump. Fitting the wrong one changes the flow curve.
How do I know the impeller is the problem?
Weak flow with a clean basket and clean filter, or a pump that primes but will not build pressure, usually points at a worn, cracked or blocked impeller.
Should I replace anything else while I am in there?
The shaft seal is behind the impeller and has to come off to get the impeller off, so most techs change the seal in the same job.
