Hayward SX160Z1 tank o-ring for Pro Series S160T sand filterHayward O-Ring for Pro Series S160T Sand Filter, SX160Z1 In stock$1099
Hayward SX160Z1 tank o-ring for Pro Series S160T sand filter
Shop all Hayward

Hayward O-Ring for Pro Series S160T Sand Filter, SX160Z1

Ask a questionMPN SX160Z1
$1099
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Hayward part SX160Z1 The factory tank o-ring for the Pro Series S160T, not a generic ring off a size chart.
  • Fits the S160T Sized for the two piece top mount Pro Series S160T sand filter.
  • Seals tank to head This is the ring the filter relies on to hold pressure where the two halves meet.
  • The first thing to change on a leak Water weeping from the tank seam under pressure usually means a flattened or split o-ring.
  • Cheap insurance during a rebuild Worth replacing any time the filter is opened for a media change or an internals repair.
  • Sold as a single ring One o-ring, so order the count you need if you are servicing more than one filter.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Hayward O-Ring for Pro Series S160T Sand Filter, SX160Z1, SKU HAY-051-2179. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Hayward O-Ring for Pro Series S160T Sand Filter, SX160Z1
Hayward

O-Ring for Pro Series S160T Sand Filter, SX160Z1

$1099
Hayward SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit
Hayward

SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit

$15899
Hayward Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA
Hayward

Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA

$14799
Hayward OEM O-Ring, 6-3/4" ID, GMX600F
Hayward

OEM O-Ring, 6-3/4" ID, GMX600F

$2699
Hayward Vari-Flo 1.5" Side Mount Multiport Valve for Sand Filters, SP0710X62
Hayward

Vari-Flo 1.5" Side Mount Multiport Valve for Sand Filters, SP0710X62

$18899
Hayward 2" Top Mount Backwash Valve with Clamp, Fits Pro Series Sand Filters S310T / S310T2, SP071620T
Hayward

2" Top Mount Backwash Valve with Clamp, Fits Pro Series Sand Filters S310T / S310T2, SP071620T

$25399
Hayward Lateral Hub Assembly (S244S, S220S), SX242MA1S
Hayward

Lateral Hub Assembly (S244S, S220S), SX242MA1S

$13099
Subtotal

Similar products

Other products people compare with this one.

Hayward SX180LA drain cap assembly for Pro-Series sand filters Hayward Drain Cap Assembly for Pro-Series Sand Filters, 2006 to Current, SX180LA$1499 Hayward SX202S corrugated cardboard sand shield for sand filters Hayward Sand Shield, Corrugated Cardboard Design, SX202S$1399 Hayward SX180HG drain cap and gasket for sand filters 2005 and prior Hayward Drain Cap and Gasket, 2005 and Prior, SX180HG$1399 Hayward SX200H bottom drain screen for S-200 and S-240 sand filters Hayward Bottom Drain Screen, SX200H$1399 Hayward SPX1091Z2PAK2 insert adapter, 1-1/2 inch MIP to 1-1/2 inch hose barb Hayward 1-1/2" MIP x 1-1/2" Barb Hose Adapter, SPX1091Z2PAK2$1599 Hayward SX144Z1 1-1/2 in. ribbed hose for Pro Series S144T sand filter Hayward 1-1/2 in. Ribbed Hose for Pro Series S144T Sand Filter, SX144Z1$1899 Hayward SX200J Pro Series sand filter support stand skirt Hayward Pro Series Sand Filter Support Stand, SX200J$15899 Hayward SX200Z5 air relief o-ring, 13/16 in. O.D., for S200, ProSeries and ProSeries Plus sand filters Hayward Air Relief O-Ring, 13/16 in. O.D., for S200, ProSeries and ProSeries Plus Sand Filters, SX200Z5$342 Hayward GMX600NM two piece Vari-Flo valve clamp for Pro Series sand filters Hayward Valve Clamp for Pro-Series, GMX600NM$6099 Hayward SX160Z5 22 inch hose for Pro Series filters Hayward Hose, 22 Inch Long for Pro Series Filters, SX160Z5$6199
Hayward Sand Filter Tank O-Ring S240 | SX240Z1 Hayward Sand Filter Tank O-Ring S240 | SX240Z1$7899 Hayward SX200Z7 tank O-ring for S200 sand filters Hayward Tank O-Ring, S200 Series, SX200Z7$5199 Hayward SX200K access cover, dome lid for S200 and S240 sand filters Hayward S200/S240 Sand Filter Access Cover, SX200K$7799 Hayward SX244K Pro Series sand filter top closure dome Hayward Top Closure Dome, Pro Series, SX244K$8699 Hayward SX310DA2 folding lateral assembly with center pipe for the S310T sand filter Hayward Folding Lateral Assembly With Center Pipe for S310T Sand Filters, SX310DA2$16799 Hayward SX200Z14 1 inch o-ring for S200, S240 and S160T sand filters Hayward O-Ring, 1 in. O.D., After 1980, SX200Z14$399 Hayward SX244PX bulkhead fitting for Pro Series sand filters S210S, S244S, S310S and S311S Hayward Bulkhead Fitting for S210S/S244S/S310S/S311S, SX244PX$5899 Hayward FILTER SUPPORT STAND | SX164B Hayward FILTER SUPPORT STAND | SX164B$9599 Hayward SX180K filter base with screws and washers for S180T and S166T sand filters Hayward Filter Base with Screws and Washers, S180T/S166T, SX180K$14999 Hayward SX200AA1T filter tank bottom with drain assembly for the S200 sand filter Hayward Filter Tank Bottom with Drain Assembly S200, SX200AA1T$74799

Product details

Hayward SX160Z1 is the tank o-ring for the Pro Series S160T sand filter. It seals the joint between the filter tank and the top mount section, which is the one place on the filter that has to hold system pressure against a removable joint.

When you need it

Water weeping or spraying from the seam where the two halves of the filter meet is the classic symptom. Over years of heat, chlorine and compression the ring flattens, hardens or splits, and once it stops sealing no amount of retightening the clamp will hold it.

Fitting it

Shut the pump down and relieve pressure at the air relief before opening anything. Clean the groove and both sealing faces properly, since grit and old ring residue will hold the new seal open. A thin film of silicone lubricant made for pool o-rings helps it seat and makes the next service easier.

It is worth changing this ring any time the filter is opened for a media change, so a job you have already done does not have to be repeated for a two dollar part.

Specifications
Brand Hayward
Manufacturer part number SX160Z1
UPC 610377054461
Type Tank o-ring
Part type Pool filter part
Fits Hayward Pro Series S160T sand filter
Shipping weight 0.2 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Hayward

This industry builds more than pools. We build moments. Hayward

Hayward equipment

Hayward Super Pump 1 HP Max Rated 115/230V, W3SP2607X10 Hayward AquaRite Salt System Complete, 40,000 Gallon Pools, W3AQR15 Hayward TracVac Suction Wall Climbing Pool Cleaner for In-ground Pools up to 40 ft, W3HSCTRACCU Hayward Pro-Grid 60 Sqft DE Pool Filter, Valve Not Included, W3DE6020
Shop Hayward equipment

Genuine Hayward parts

Hayward TurboCell T-15 Salt Cell for Inground Pools up to 40,000 Gallons, W3T-CELL-15 Hayward Genuine OEM SP1082 Skimmer Basket, SPX1082CA Hayward Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA Hayward H-Series Bezel & Keypad Assembly, FDXLBKP1930
Shop Hayward parts
Pool cleaners: Hayward TracVac and PoolCleaner suction cleaners lined up on a pool deckPool automation: the Hayward app on a phone held up in front of an infinity poolPool water features: two bubblers in a tiled spa, a woman relaxing on a lounger behind
Hayward makes pumps, filters, heaters, salt systems, cleaners, lighting and automation for residential pools.Shop all Hayward

Customer reviews

More from Hayward

Hayward SP0714T Vari-Flo XL 1.5 in. top mount multiport valve kit, front view Hayward SP0714T Vari-Flo XL 1.5 in. Top Mount Multiport Valve Kit$15899 Hayward CL200EF in-line automatic pool chlorinator, 9 lb tablet feeder Hayward CL200EF In-Line Automatic Pool Chlorinator, 9 lb Chemical Feeder$12499 Hayward GLX-CTL-RITE AquaRite salt system power center, control box only Hayward AquaRite Salt System Power Center (Requires Salt Cell), GLX-CTL-RITE$1,37799 Hayward SPX0714BA Vari-Flo XL valve key cover handle assembly for SP0714T Hayward Genuine OEM Vari-Flo XL Filter Valve Key Cover Handle Assembly, SPX0714BA$14799 Hayward FDXLHXA1250 heat exchanger assembly for the H250FD Universal H-Series low NOx heater Hayward Heat Exchanger Assembly for H250FD, FDXLHXA1250$1,28299 Hayward TurboCell T-15 W3T-CELL-15 salt cell, replacement for AquaRite systems Hayward TurboCell T-15 Salt Cell for Inground Pools up to 40,000 Gallons, W3T-CELL-15$1,09900 Web Price Paralevel Startup Kit, part number 004-760-2921-00 Hayward Paralevel Startup Kit, 004-760-2921-00$5799 Hayward GLX-PCB-PRO main PCB for Goldline ProLogic and AquaPlus controls Hayward Main PCB Replacement for Goldline ProLogic Automation and Chlorination After 10/2008, GLX-PCB-PRO$1,07599 Hayward SP10841 Auto-Skim skimmer for vinyl and fiberglass pools, white with square lid Hayward Auto-Skim Skimmer for Vinyl/Fiberglass Pools, 1.5" FPT, Square Lid, White, SP10841$19299 Hayward SPX0714L cover o-ring for SP0714T Vari-Flo XL valve Hayward Cover O-Ring for SP0714T Vari-Flo XL Valve, SPX0714L$1799
Paramount 005422901500 two lamp UV kit with boot and o-ring for HydraPure and Ultra UV2 sanitizers Paramount 2-Lamp Kit with Boot and O-Ring for HydraPure and Ultra UV2 Sanitizers, 005422901500$26899 Hayward W3T-CELL-9 TurboCell T-9 salt cell with 15 ft cord Hayward TurboCell T-9 Salt Cell for Inground Pools up to 25,000 Gallons, Genuine AquaRite Replacement, W3T-CELL-9$89900 Web Price Hayward SP0710X62 Vari-Flo 1.5 in. side mount multiport valve for Pro Series sand filters Hayward Vari-Flo 1.5" Side Mount Multiport Valve for Sand Filters, SP0710X62$18899 Hayward SPX1082CA genuine OEM skimmer basket, 7 in. top diameter Hayward Genuine OEM SP1082 Skimmer Basket, SPX1082CA$2399 Hayward SPX1091Z7 1-1/2 in. combo hose adapter, 2 pack Hayward 1-1/2" Combo Hose Adapter for Filters, Pumps, Skimmers and Chlorine Feeders (2 Pack), SPX1091Z7$899 Hayward SPX0740BA key cover and handle assembly for SP740DE multiport valve Hayward OEM Key Cover and Handle Assembly for SP740DE, SPX0740BA$19799 Hayward CX200XRE 200 sq. ft. replacement filter cartridge for the SwimClear C200S Hayward Genuine OEM SwimClear C200S Filter Cartridge, CX200XRE$20299 Hayward HLXPROUPG Pro Logic Retrofit Kit, OmniPL Hayward Pro Logic Retrofit Kit, OmniPL, HLXPROUPG$1,99900 Web Price Hayward SP071620T 2 in. top mount backwash valve with clamp for Pro Series S310T and S310T2 Hayward 2" Top Mount Backwash Valve with Clamp, Fits Pro Series Sand Filters S310T / S310T2, SP071620T$25399 Hayward FDXLGSV0003 natural gas valve kit for Universal H-Series FD heaters Hayward Natural Gas Valve Kit, FD Series, FDXLGSV0003$41899

Questions and answers

What people ask about this product, answered by our pool techs.

Which o-ring is this?
The tank o-ring, the seal between the body of the S160T tank and the top mount section above it.
Will it fit other Hayward filters?
It is specified for the Pro Series S160T. Hayward uses different ring sizes across the Pro Series, so match the part number to your filter rather than the look of the ring.
My filter weeps at the seam. Is this the fix?
Usually. A tank o-ring that has flattened, hardened or split will pass water under pressure. Clean the groove out fully before the new ring goes in.
Should I lubricate it?
A thin film of a silicone based lubricant made for pool o-rings helps it seat and makes the next teardown easier. Keep petroleum products away from it.
