Sta-Rite Diffuser 1 HP for Dyna-Glas, Dyna-Max and Dyna-Jet Pumps, C1-270PC In stock$4499
Sta-Rite Diffuser 1 HP for Dyna-Glas, Dyna-Max and Dyna-Jet Pumps, C1-270PC
30 day returns · Easy, with prepaid labels provided
Quick overview
- Sta-Rite part C1-270PC The diffuser used in the 1 HP Dyna-Glas, Dyna-Max and Dyna-Jet wet end.
- Matched to a 1 HP impeller Diffusers are sized to the impeller they run against, so keep the horsepower the same.
- Seals suction from pressure It is the divider that stops water leaving the impeller from circulating straight back to the suction side.
- Common cause of weak flow A cracked or heat warped diffuser costs pressure and flow with nothing obvious to see from outside.
- Diffuser only Screws, lock washers and o-rings are separate parts, so order them with it if yours are tired.
- Worth doing with the impeller Both parts wear from the same grit, and changing them together saves opening the pump twice.
Need a hand?
Frequently bought together
Diffuser 1 HP for Dyna-Glas, Dyna-Max and Dyna-Jet Pumps, C1-270PC
Similar products
Other products people compare with this one.
Sta-Rite Impeller for Dyna-Glas/Dyna-Max Series and Dyna-Pro/Dyna-Pro E Pumps, C105-236P$5699
Sta-Rite Impeller for 1-1/2 HP Dyna-Max and Dyna-Pro Pumps, C105-236PC$6099
SuperPro Pump Rebuild Kit for Sta-Rite MAX-E-GLAS II and DURA-GLAS II, GO-KIT38-9$4199
Sta-Rite Diffuser 1/2 HP to 1-1/2 HP for Max-E-Pro Series Pumps, C1-271P1Z$4299
Sta-Rite Diffuser 1.5 HP to 2 HP Dyna-Glas/Max, C1-270P$3999
Sta-Rite Diffuser for 1-1/2 HP to 3 HP Pumps, C1-271P$4599
Aladdin Seal & Gasket Kit for Sta-Rite Max-E-Pro Series Pool Pumps, GO-KIT79$3099
Sta-Rite Retaining Ring for CSPH and CCSPH Pumps, S11207$3499
Sta-Rite Dyna-Jet Shaft Seal, 17351-0101S$4099
Sta-Rite Impeller Screw for Dyna-Pro, 37337-6080$3399
Hayward Diffuser for MaxFlo VS and MaxFlo XL Pumps, SPX2300B$5499
Pentair Pump Lid O-Ring for Dura-Glas and Max-E-Glas, 16920-0012$3099
Sta-Rite Dyna-Glas Impeller, 2 HP, C105-236PDA$5899
Hayward Diffuser for All Max-Flo Pumps, SPX2800B$4799
Hayward Impeller for Super Pump and MaxFlo Pumps, 1/2 HP Max Rate, 1/3 HP Full Rate, SPX2600C$4199
Pentair Genuine OEM Seal Kit for WhisperFlo and IntelliFlo Pool Pumps, 356198$3799
Pentair Seal Package for EQ and C Series Pumps, 071725S$5199
Jandy Backplate O-Ring for FHPM and VS-FHP Series Pumps, R0480300$2299
Sta-Rite Trap Cover O-Ring, Max-E-Pro, 6-3/4" ID, 1/4" Thickness, 35505-1440Z$3199
Pentair Seal Kit for WFE and IntelliFlo Pumps, 071734S$3599
Product details
The C1-270PC is the Sta-Rite diffuser for 1 HP Dyna-Glas, Dyna-Max and Dyna-Jet pumps. It is the molded piece that sits directly in front of the impeller inside the wet end.
What the diffuser does
The diffuser guides water off the impeller and forms the divide between the suction side and the pressure side of the pump. It has to sit close to the impeller face to hold that divide. Once it is cracked, warped by a run without water, or worn oversize where the impeller enters it, water loops back to the suction side instead of heading out to the filter. The pump sounds normal and primes normally, but filter pressure and return flow are both down.
Match it to the impeller
A diffuser is sized to the impeller it runs against, so a 1 HP diffuser belongs with a 1 HP impeller. If the impeller is also scored or has worn vanes, replace the pair while the pump is open. They wear from the same grit and doing them together saves a second teardown.
What is in the box
The diffuser only. Its o-ring, the cap screws and the extended tooth lock washers are separate Sta-Rite parts, so it is worth checking those while the wet end is apart.
| Brand | Sta-Rite |
|---|---|
| Manufacturer part number | C1-270PC |
| UPC | 788379733018 |
| Type | Pump diffuser |
| Horsepower | 1 HP |
| Part type | Pool pump part |
| Fits | Sta-Rite Dyna-Glas, Dyna-Max and Dyna-Jet pumps, 1 HP |
| Shipping weight | 0.45 lb |
| Ships | Parcel |
