Pentair 073131Z 3 hp impeller for WhisperFlo WFE-12 and IntelliFlo pumpsPentair Impeller for IntelliFlo and WhisperFlo 3 HP WFE-12, 073131Z In stock$9299
Pentair 073131Z 3 hp impeller for WhisperFlo WFE-12 and IntelliFlo pumps
Shop all Pentair

Pentair Impeller for IntelliFlo and WhisperFlo 3 HP WFE-12, 073131Z

Ask a questionMPN 073131Z
$9299
In stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Genuine Pentair impeller OEM 073131Z, not a generic casting.
  • 3 hp rating the impeller for the 3 hp WhisperFlo WFE-12 and the 3 hp IntelliFlo family.
  • Fits IntelliFlo VS, VS 3050, VS+SVRS and VF one impeller serves the variable speed and variable flow models.
  • Replace the seal with it the shaft seal and the WhisperFlo/IntelliFlo seal and gasket kit are separate and usually changed at the same time.
  • Diffuser matched pairs with the 3 hp black WhisperFlo/IntelliFlo diffuser assembly.
  • UPC 788379664848 check against the old impeller before ordering.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Pentair Impeller for IntelliFlo and WhisperFlo 3 HP WFE-12, 073131Z, SKU PUR-101-2757. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Pentair Impeller for IntelliFlo and WhisperFlo 3 HP WFE-12, 073131Z
Pentair

Impeller for IntelliFlo and WhisperFlo 3 HP WFE-12, 073131Z

$9299
Pentair Genuine OEM Seal Kit for WhisperFlo and IntelliFlo Pool Pumps, 356198
Pentair

Genuine OEM Seal Kit for WhisperFlo and IntelliFlo Pool Pumps, 356198

$3799
Pentair WhisperFlo and IntelliFlo Volute Housing Replacement Kit, 357149
Pentair

WhisperFlo and IntelliFlo Volute Housing Replacement Kit, 357149

$28799
Pentair 3.2 kW IntelliFloXF VSF, VSF, VS+SVRS, i1, i2 Motor, 350305S
Pentair

3.2 kW IntelliFloXF VSF, VSF, VS+SVRS, i1, i2 Motor, 350305S

$78199
Aladdin Seal & Gasket Kit for Pentair WhisperFlo & IntelliFlo Pool Pumps, GO-KIT32-9
Aladdin

Seal & Gasket Kit for Pentair WhisperFlo & IntelliFlo Pool Pumps, GO-KIT32-9

$3499
Pentair Lid O-Ring, 5-3/4" ID, 350013Z
Pentair

Lid O-Ring, 5-3/4" ID, 350013Z

$599
Pentair IntelliFlo3 and IntelliPro3 Pump Rebuild Seal Set Kit, 357872
Pentair

IntelliFlo3 and IntelliPro3 Pump Rebuild Seal Set Kit, 357872

$3499
Subtotal

Similar products

Other products people compare with this one.

Pentair 073130Z impeller for 2 and 2.5 HP WhisperFlo pool pumps Pentair WhisperFlo Impeller, 2 and 2.5 HP (WF-8 & 30, WFDS-8 & 30, WFE-30, WFK-8), 073130Z$9699 Pentair 073127Z WhisperFlo impeller for .75 and 1 HP pumps Pentair WhisperFlo Impeller .75 and 1 HP (WF-3 & 24, WFE-24), 073127Z$9499 Pentair 073126Z 1/2 HP impeller for the WhisperFlo WFE-2 pump Pentair 1/2 HP Impeller for WhisperFlo WFE-2, 073126Z$9099 Pentair 357199Z almond Cam and Ramp strainer lid clamp for WhisperFlo and IntelliFlo pumps Pentair Cam and Ramp Strainer Lid Clamp, Almond, for WhisperFlo and IntelliFlo Pumps, 357199Z$5099 Pentair 070795 clear Lexan pump lid for WhisperFlo and Aquatron metal clamp style pumps Pentair Lexan Cover for WhisperFlo and Aquatron, Older Metal Clamp Style, 070795$5199 Pentair 410028Z 2 in. and 2.5 in. union kit for the 3 HP IntelliFlo3 pool pump Pentair 2 in. and 2.5 in. Union Kit for 3 HP IntelliFlo3 Pool Pump, 410028Z$5299 Pentair 356237Z IntelliFlo 3.0 Energy Star impeller assembly Pentair IntelliFlo 3.0 Energy Star Impeller Assembly, 356237Z$10499 Pentair 073128Z 1000 Series impeller for WhisperFlo WFE-4, WF-4, WF-26 and FE-26 pumps Pentair 1 & 1.5 HP WhisperFlo Impeller, 073128Z$9099 Pentair 072927Z WhisperFlo diffuser assembly for WFE-3 to WFE-8 pumps Pentair WhisperFlo Diffuser, .5 HP to 2 HP, WFE-3-8, 072927Z$7799 Pentair 073129Z 1000 Series WhisperFlo pump impeller Pentair 1.5 HP WhisperFlo Impeller, 073129Z$9099
Pentair 400023Z WhisperFlo XF 5 HP impeller assembly Pentair WhisperFlo XF 5 HP Impeller, 400023Z$13499 Pentair 400006 WhisperFlo XF lid and locking ring assembly Pentair WhisperFlo XF Lid and Locking Ring, 400006$5799 Pentair 356904Z keypad relocation kit for IntelliFlo variable speed pumps, almond Pentair Keypad Relocation Kit for IntelliFlo Variable Speed Pump, Almond, 356904Z$7699 Pentair 410029 3 in. union kit for the 3 HP IntelliFlo3 pool pump Pentair 3" Union Kit for 3 HP IntelliFlo3 Pool Pump, 410029$6299 Pentair 356238Z IntelliFlo 3.0 Energy Star diffuser assembly Pentair IntelliFlo 3.0 Energy Star Diffuser Assembly, 356238Z$9499 Pentair 400011Z diffuser for the 5 HP WhisperFlo XF pump Pentair WhisperFlo XF 5 HP Diffuser, 400011Z$11599 Pentair 356155Z diffuser for the IntelliFlo3 VSF 1.5 HP pool pump Pentair Diffuser for IntelliFlo3 VSF 1.5 HP Pump, 356155Z$5499 Pentair 410020 Whisperflo XF union kit without tap Pentair Whisperflo XF Union Kit, 410020$13699 Pentair 400015Z 3 HP impeller assembly for IntelliFloXF pumps Pentair 3 HP IntelliFloXF VSF, VS Impeller Assembly, 400015Z$11999 Pentair 356156Z diffuser for the 3HP IntelliFlo3 pool pump Pentair Diffuser for 3HP IntelliFlo3 Pool Pump, 356156Z$5499

Product details

The Pentair 073131Z is the genuine 3 hp impeller for the WhisperFlo WFE-12 and the IntelliFlo VS, VS 3050, VS+SVRS and VF pumps. One part number covers both pump lines because they share the same wet end at 3 hp.

When to replace

Reduced flow at the same speed, a rattle from the wet end, or a broken vane found when the pump is opened for a seal change all point to the impeller. Debris drawn past the basket is the usual cause of vane damage.

Do the seal at the same time

Getting to the impeller means pulling the seal plate, so the shaft seal and the seal and gasket kit should be replaced in the same visit. The impeller screw is a left hand thread, 1/4-20 x 1, and is a separate part. The 3 hp diffuser assembly is also separate and worth inspecting while the pump is apart.

From Pool School

How to Prime a Pool PumpFrom the breaker to a full pot, each manufacturer's time limit, and what to check when it won't catch prime. Read Replace the Pool Pump Motor or the Whole Pump?The manufacturers' tests first, what each repair replaces, and the federal motor rule. Read

Where this part goes

27 Key 27 on the Pentair IntelliFlo PumpFor the VS or 2 VST, before October 2020 (VS or 2 VST, before October 2020), VSF, before October 2020 (VSF, before October 2020), VS+SVRS, before October 2020 (VS+SVRS, before October 2020).See it on the diagramAll Pentair IntelliFlo Pump Parts 75 parts and the drawing28 Key 28 on the Pentair WhisperFlo PumpFor the WF-12 (3 HP).See it on the diagramAll Pentair WhisperFlo Pump Parts 73 parts and the drawing
Specifications
Brand Pentair
Manufacturer part number 073131Z
UPC 788379664848
Type Pump impeller
Horsepower 3 hp
Fits Pentair WFE-12, WhisperFlo High Performance Pump, IntelliFlo VS, IntelliFlo VS 3050, IntelliFlo VS + SVRS, IntelliFlo VF
Part type Pool pump part
Shipping weight 0.3 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

From Pentair

Your trusted source for all things pool. Pentair

Pentair equipment

Pentair SuperFlo VS 1.5 HP Variable Speed Pool Pump, 2.2 THP, EC-342001 Pentair MasterTemp 400 Natural Gas Pool Heater, EC-462028 Pentair Clean & Clear Plus 420 sq ft Cartridge Pool Filter, EC-160301 Pentair IntelliConnect Control & Monitoring System with Wi-Fi, EC-523317
Shop Pentair equipment

Genuine Pentair parts

Pentair Genuine OEM Seal Kit for WhisperFlo and IntelliFlo Pool Pumps, 356198 Pentair Genuine OEM High Flow Manual Air Relief Valve, 98209800 Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400 Pentair Genuine OEM MasterTemp/Max-E-Therm 6-Button Control Board Kit, 461105Z
Shop Pentair parts
Pool lighting: a backyard pool and spa lit in blue and green at nightPool water treatment: three people floating on rings in clear blue water, seen from abovePool cleaners: a toddler in flower sunglasses laughing in a yellow ring, held by her mother
Pentair makes pumps, filters, heaters, salt chlorinators, cleaners, lighting and automation for pools and spas.Shop all Pentair

Customer reviews

More from Pentair

Pentair SuperFlo VS EC-342001 1.5 HP variable speed pool pump, front view Pentair SuperFlo VS 1.5 HP Variable Speed Pool Pump, 2.2 THP, EC-342001$1,48900 Pentair SuperFlo EC-348190 single speed pool pump, 1 HP, 115/230V Pentair SuperFlo 1 HP Single Speed Pool Pump, 1.1 THP, 115/208-230V, EC-3481905.0 (1) $74800 Pentair WhisperFlo VS EC-011533 2.6 THP variable speed pool pump, top view Pentair WhisperFlo VS / VST 2.6 THP Variable Speed Pool Pump, 115/208-230V, EC-011533$1,79900 Pentair 262506 HiFlow 1.5 in. six way clamp style multiport valve Pentair Genuine OEM HiFlow Valve 1.5 in. 6-Way Clamp Style, 262506$20399 Pentair EC-520556 IntelliChlor 110/220V power center Pentair 110/220V IntelliChlor Salt Chlorine Generator Power Center, EC-520556$79900 Web Price Pentair 523769 IntelliChlor Plus and LT replacement sensor board Pentair IntelliChlor Plus and LT Replacement Sensor Board, 523769$39399 Pentair 350305S 3.2 kW 10 pole variable speed motor for IntelliFloXF and IntelliFlo 2 VST pumps Pentair 3.2 kW IntelliFloXF VSF, VSF, VS+SVRS, i1, i2 Motor, 350305S$78199 Pentair 523735-EC IntelliChlor Plus40 salt chlorine generator cell Pentair IntelliChlor Plus40 Salt Chlorine Generator Replacement Cell, 40,000 Gallons, 523735-EC$1,81900 Web Price Pentair Rainbow 320 in-line chlorinator R171096, front view Pentair Rainbow 320 In-Line Chlorinator, R171096$14699 Pentair 190003 tank clamp kit with tension control for Clean and Clear Plus, FNS Plus and Quad DE filters Pentair Genuine OEM Clamp Kit with Tension Control, 190003$30199
Pentair IntelliChlor LT25 salt chlorine generator cell 523747-EC Pentair IntelliChlor LT25 Salt Chlorine Generator Cell, 25,000 Gallons, 523747-EC$1,14900 Pentair IntelliFlo VS+SVRS variable speed pool pump, EC-011057 Pentair IntelliFlo VS+SVRS Variable Speed Pool Pump, 3 HP Max, 3.95 THP, 230V, EC-011057$2,39900 Pentair 170145 cartridge pack for Sta-Rite System 3 S7M120, inner and outer cartridges Sta-Rite 170145 System 3 S7M120 Large and Small Cartridge Set, 25021-0200S and 25022-0201S$46799 Pentair 261055 SM-20-3 2 in. side mount multiport valve kit, front view Pentair 2 in. Multiport Valve Kit for Side Mount Sand Filters, SM-20-3, 261055$29999 Pentair 523770 IntelliChlor Plus replacement controller (HMI), black Pentair IntelliChlor Plus Controller Replacement (HMI), Black, 5237705.0 (1) $38399 Pentair 261152 SM20-2 2 in. side mount multiport valve kit for DE filters Pentair 2" Valve Kit Multiport, Side Mount DE Filters SM20-2, 261152$29799 Pentair 357149 WhisperFlo and IntelliFlo volute housing replacement kit, front view Pentair WhisperFlo and IntelliFlo Volute Housing Replacement Kit, 357149$28799 Pentair MicroBrite Color LED pool light EC-620425, 12 volt, 14 watt, with 100 ft cord Pentair MicroBrite Color LED Pool Light 12 Volt, 14 Watt with 100' Cord, EC-620425$61900 Pentair 59023400 FNS Plus 48 sq ft complete DE grid assembly Pentair Genuine OEM FNS Plus Element Assembly Complete, 48 Sq Ft, 59023400$40199 Pentair Amerlite EC-602128 500W 120V inground pool light with stainless steel facering Pentair Amerlite Pool Light for Inground Pools with Stainless Steel Facering, 500W 120V 50' Cord, EC-602128$43900 Web Price

Questions and answers

What people ask about this product, answered by our pool techs.

Which pumps use this impeller?
The 3 hp WhisperFlo WFE-12, and the IntelliFlo VS, VS 3050, VS+SVRS and VF variable speed and variable flow pumps.
Is the impeller screw included?
The impeller screw is a separate part, a 1/4-20 x 1 left hand thread screw. Left hand means it loosens clockwise, which catches people out on the first pump.
What else should I replace while the pump is apart?
The shaft seal, and the o-rings and gaskets in the WhisperFlo/IntelliFlo seal and gasket kit. A worn diffuser is also worth checking; the 3 hp diffuser assembly is a separate part.
Is this a genuine Pentair part?
Yes. It is Pentair part 073131Z.
