Sta-Rite C105-137PDA impeller for 2 HP full rate and 2-1/2 HP up rate pumpsSta-Rite Impeller for 2 HP Full Rate and 2-1/2 HP Up Rate Pumps, C105-137PDA$9799
Sta-Rite C105-137PDA impeller for 2 HP full rate and 2-1/2 HP up rate pumps
Shop all Sta-Rite

Sta-Rite Impeller for 2 HP Full Rate and 2-1/2 HP Up Rate Pumps, C105-137PDA

Ask a questionMPN C105-137PDA
$9799
Out of stock
Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

  • Horsepower specific Sized for 2 HP full rate and 2-1/2 HP up rate pumps, not a universal impeller.
  • Sta-Rite part Carried under part number C105-137PDA.
  • Max-E-Glas and Dura-Glas Listed within the Sta-Rite Max-E-Glas and Dura-Glas pump parts group.
  • Restores lost flow A worn or blocked impeller shows up as weak returns and poor skimming even with a clean filter.
  • Match before you order Impellers are matched to horsepower and rating, so read the pump label rather than guessing.
  • Check the seal at the same time The shaft seal has to come out to change an impeller, so plan on replacing it.
Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.
(888) 751-8084CallChat with a techChatEmail usEmail

Send us a message

A pool professional will get back to you, usually the same business day.

About Sta-Rite Impeller for 2 HP Full Rate and 2-1/2 HP Up Rate Pumps, C105-137PDA, SKU STA-101-7167. We will include it with your message.

We use your details to answer this message and nothing else.

Frequently bought together

Current item Sta-Rite Impeller for 2 HP Full Rate and 2-1/2 HP Up Rate Pumps, C105-137PDA
Sta-Rite

Impeller for 2 HP Full Rate and 2-1/2 HP Up Rate Pumps, C105-137PDA

$9799
Sta-Rite Pump Tank Body Housing Assembly, IntelliPro, 17307-0110S
Sta-Rite

Pump Tank Body Housing Assembly, IntelliPro, 17307-0110S

$30499
Pentair Genuine OEM High Flow Diffuser O-Ring, 355030
Pentair

Genuine OEM High Flow Diffuser O-Ring, 355030

$1799
Sta-Rite Tank Body Assembly for Max-E-Glas II and Dura-Glas II, C176-59PZ
Sta-Rite

Tank Body Assembly for Max-E-Glas II and Dura-Glas II, C176-59PZ

$29699
Sta-Rite Max-E-Pro Seal Plate, C103-194PZ
Pentair

Sta-Rite Max-E-Pro Seal Plate, C103-194PZ

$7099
Sta-Rite Max-E-Glas/Dura-Glas Diffuser .75HP / 2.5HP Full Rated, C1-200PAZ
Sta-Rite

Max-E-Glas/Dura-Glas Diffuser .75HP / 2.5HP Full Rated, C1-200PAZ

$4399
Sta-Rite Seal Plate Kit for Max-E-Pro, Max-E-Glas II and Dura-Glas II C203-194P
Sta-Rite

Seal Plate Kit for Max-E-Pro, Max-E-Glas II and Dura-Glas II C203-194P

$17199
Subtotal

Similar products

Other products people compare with this one.

Pentair 355086Z high flow impeller for SuperFlo, SuperMax and Challenger pumps Pentair SuperFlo and SuperMax Impeller, 1.5 HP Full Rated / 2 HP Up Rated, High Flow, 355086Z$5999 Sta-Rite C19-37AZ V clamp for the pump tank body Sta-Rite Tank Body V Clamp, C19-37AZ$11799 Pentair 355074Z high flow pump impeller, 1 HP full rated and 1.5 HP up rated Pentair Super Flo/Max Impeller, 1 HP Full Rated / 1.5 HP Up Rated, High Flow, 355074Z$5699 Pentair 351157 1.5 inch black union kit for SuperMax and SuperFlo pumps Pentair 1.5" Black Union Kit for SuperMax and SuperFlo, 351157$8199 Pentair 355093Z impeller, 2 HP full rated and 2-1/2 HP up rated high flow Pentair Impeller, 2 HP Full Rated / 2-1/2 HP Up Rated, High Flow, 355093Z$5499 Sta-Rite C3-185PZ 6 inch Dyna-Glas trap lid assembly Sta-Rite Dyna-Glas Trap Lid Assembly, C3-185PZ$7599 Sta-Rite 17307-0111S Max-E-Pro trap cover lid assembly Sta-Rite Max-E-Pro Trap Cover Lid Assembly, 17307-0111S$8199 Sta-Rite PKG 189 union connection kit, 2 inch by 2 inch FPT Sta-Rite Union Connection Kit 2" x 2" FPT, PKG 189$5399 Sta-Rite C104-79P pump base with motor pad for 3 HP models Sta-Rite Base with Motor Pad, 3 HP Only, C104-79P$6099 Pentair 400023Z WhisperFlo XF 5 HP impeller assembly Pentair WhisperFlo XF 5 HP Impeller, 400023Z$13399
Pentair 355618Z SuperFlo and SuperMax diffuser, 1-1/2 HP thru 2 HP Pentair SuperFlo and SuperMax Diffuser, 1-1/2 HP Thru 2 HP, 355618Z$9499 Pentair 356012Z seal plate for SuperFlo, Pinnacle and Sta-Rite SuperMax pumps Pentair SuperFlo Seal Plate, 356012Z$8399 Pentair 400011Z diffuser for the 5 HP WhisperFlo XF pump Pentair WhisperFlo XF 5 HP Diffuser, 400011Z$11499 Pentair 350094 Superflo pump base Pentair Superflo Pump Base, 350094$9299 Pentair 355617Z diffuser for SuperFlo and SuperMax pumps, 1/2 HP through 1 HP Pentair SuperFlo Diffuser, 1/2 HP Thru 1 HP, 355617Z$8899 Sta-Rite PKG 115 trap and basket assembly for Dura-Glas and Max-E-Glas pumps Sta-Rite Trap Basket Assembly for Dura-Glas and Max-E-Glas Pumps, PKG 115$15899 Sta-Rite C108-33P strainer basket for Dura-Glas and Max-E-Glas pumps Sta-Rite Strainer Basket for Dura-Glas and Max-E-Glas Pumps, C108-33P$2099 Sta-Rite C1-271P pump diffuser for 1-1/2 HP through 3 HP pumps Sta-Rite Diffuser for 1-1/2 HP to 3 HP Pumps, C1-271P$4299 Sta-Rite C1-271P1Z diffuser for Max-E-Pro series pumps Sta-Rite Diffuser 1/2 HP to 1-1/2 HP for Max-E-Pro Series Pumps, C1-271P1Z$4299 SuperPro GO-KIT38-9 gasket, o-ring and seal kit for Sta-Rite MAX-E-GLAS II and DURA-GLAS II pumps SuperPro Pump Rebuild Kit for Sta-Rite MAX-E-GLAS II and DURA-GLAS II, GO-KIT38-9$3899

Product details

This is the Sta-Rite C105-137PDA impeller, sized for 2 horsepower full rate and 2-1/2 horsepower up rate pumps. It is listed within the Sta-Rite Max-E-Glas and Dura-Glas pump parts group.

What the impeller does

The impeller is what actually moves water. Its vanes are narrow, so debris that gets past the basket lodges in them, and years of running wears the vanes down. Either way the symptom is the same: weak returns, poor skimming, and a pump that sounds normal while shifting far less water than it should.

Fitting it

Impellers are matched to horsepower and rating, so read the pump label instead of going by the size of the motor. Getting the impeller off means disturbing the shaft seal, so replace that at the same time. Reusing an old seal is the usual reason a freshly rebuilt pump starts weeping between the motor and the wet end.

From Pool School

How to Prime a Pool PumpFrom the breaker to a full pot, each manufacturer's time limit, and what to check when it will not catch prime. Read Replace the Pool Pump Motor or the Whole Pump?The manufacturers' tests first, what each repair replaces, and the federal motor rule. Read
Specifications
Brand Sta-Rite
Manufacturer part number C105-137PDA
UPC 788379733568
Type Pump impeller
Rating 2 HP full rate, 2-1/2 HP up rate
Part type Pool pump part
Parts group Sta-Rite Max-E-Glas and Dura-Glas pump parts
Shipping weight 0.4 lb
Ships Parcel

Request a quote

Need a volume price, a freight quote, or pricing in writing before you order? We reply the same business day.

Request a quote

Customer reviews

More from Sta-Rite

Pentair 170145 cartridge pack for Sta-Rite System 3 S7M120, inner and outer cartridges Sta-Rite 170145 System 3 S7M120 Large and Small Cartridge Set, 25021-0200S and 25022-0201S$46799 Pentair 461105Z MasterTemp and Max-E-Therm six button control board kit Pentair Genuine OEM MasterTemp/Max-E-Therm 6-Button Control Board Kit, 461105Z$53899 Pentair 272568Z six position top mount clamp valve top assembly Pentair 6-Position Top Mount Clamp Valve Top Assembly, 272568Z$15199 Filbur FS-3037 full 11 grid set for the Sta-Rite System 3 S7D75 DE filter Filbur Sta-Rite S7D75 Full Filter Grid Set (11 Grids), FS-3037$24599 Sta-Rite 08428-0125 SwimQuip white inlet face plate and eyeball kit with screws Sta-Rite Face Plate Inlet Eyeball Kit with Screws, 08428-0125$3499 Sta-Rite 17307-0110S pump tank body assembly for IntelliPro and Max-E-Pro pumps Sta-Rite Pump Tank Body Housing Assembly, IntelliPro, 17307-0110S$30499 Sta-Rite 27002-0300S 300 square foot MOD media replacement filter module for the PLM300 Sta-Rite 300 Sq. Ft. Filter Replacement MOD Media, 27002-0300S$56999 Pentair 170147 large and small cartridge filter pack for the Sta-Rite System:3 S8M150 Pentair Sta-Rite S8M150 Large and Small Cartridge Filter Pack 25021-0202S & 25022-0203S, 170147$76799 Sta-Rite 27001-0020S System 2 black upper tank shell half Sta-Rite System 2 Tank Shell Upper Half, Black, 27001-0020S$28799 Sta-Rite 77707-0054 Max-E-Therm igniter with gasket kit Sta-Rite Max-E-Therm Igniter with Gasket Kit, 77707-0054$9499
Sta-Rite 178745Z 12.5 in. Posi-Clear RP replacement filter lid, top view Sta-Rite 150/200 Sq Ft Posi-Clear RP Replacement Lid, 12.5 in., 178745Z$15499 Sta-Rite C176-59PZ tank body assembly for Max-E-Glas II and Dura-Glas II pumps Sta-Rite Tank Body Assembly for Max-E-Glas II and Dura-Glas II, C176-59PZ$29699 Pentair 474957 combustion chamber assembly for Sta-Rite Max-E-Therm heaters Pentair Combustion Chamber Assembly for Max-E-Therm Heaters, 474957$37299 Pentair Sta-Rite 474061 cupro nickel tube sheet coil assembly kit for MasterTemp 400NA and 400LP Sta-Rite Tube Sheet Coil Assembly Kit for Model 400NA, 400LP MasterTemp Heater, 474061$1,22199 Sta-Rite C103-194PZ Max-E-Pro pump seal plate, front view Sta-Rite Max-E-Pro Seal Plate, C103-194PZ$7099 Sta-Rite 24850-0105 air relief valve and pressure gauge assembly for System 3 filters Sta-Rite Valve and Gauge Assembly for System 3 Filters, 24850-0105$11099 Pentair 08650-0022 hinged weir door assembly for Sta-Rite and SwimQuip U-3 skimmers Pentair Weir Assembly for Sta-Rite U-3 Skimmer, 08650-0022$3899 Pentair 154712 sand filter drain cap Pentair Genuine OEM Sand Filter Drain Cap, 154712$3399 Pentair 356893Z IntelliPro VSF drive kit with keypad, black Pentair IntelliPro VSF Drive Kit with Keypad, Black, 356893Z$1,22699 Sta-Rite 42001-0061S air flow switch for Max-E-Therm SR200, SR333 and SR400 heaters Sta-Rite Max-E-Therm Air Flow Switch, 42001-0061S$15799

Questions and answers

What people ask about this product, answered by our pool techs.

Which pumps does this impeller suit?
Pumps rated 2 horsepower full rate or 2-1/2 horsepower up rate, within the Sta-Rite Max-E-Glas and Dura-Glas parts group. Confirm the rating on your pump label before ordering.
What is the difference between full rate and up rate?
It is how the motor is rated. The same impeller here serves a 2 HP full rate pump and a 2-1/2 HP up rate pump, because their hydraulic output is comparable.
Can I fit a larger impeller for more flow?
No. The impeller has to match the motor rating and the plumbing it was designed around. Fitting the wrong size overloads the motor or starves the pump.
What should I replace while I am in there?
The shaft seal. It has to be disturbed to get the impeller off, and putting the old one back is the most common reason a rebuilt pump leaks at the motor.
Ask your own question
